- Page 1 INSTRUCTIONS FOR USE, ASSEMBLY AND MAINTENANCE ERGO15A ORTHOGONAL REACTION ARM Rev. Description Date First release 02/17/2020 Delta Regis_ERGO15A_M_R0.0...
-
Page 2: Model Range
MODEL RANGE Model Part Number FOLDED TORQUE ARM - R 450 ERGO15A-1 FOLDED TORQUE ARM - R 600 ERGO15A-2 We recommend reading this manual and included safety instruction. In advance of any use or intervention on the product. The contents must be clearly understood by the fiinal user. -
Page 3: Preliminary Information
Missing compliance with following paragraphs, will relieve builder of any responsibility in case of accidents, damages or malfunctioning of the machinery. BUILDER IDENTIFICATIONS Builder: Delta Regis Tools, Inc. Address: 7370 Commercial Circle, Fort Pierce, FL 34951- U.S.A. Main phone: 772-465-4302 e-mail: www.deltaregis.com... -
Page 4: Product Specifications
PRODUCT SPECIFICATIONS GENERAL PROPERTIES The torque reaction arms are an excellent support for hand held tool assembly operations, e.g. assembly with electronic tools. They relieves efforts on operator arm, wrist and shoulders caused by repetitive tasks, vibrations, forces and loads. Even a low rate of repetitive actions could cause severe disorders. ERGO15A Torque reaction arms have a wide range of performance and are exceptionally easy to install and use. -
Page 5: General Specifications
GENERAL SPECIFICATIONS... - Page 6 WORKING AREA MODEL RANGE R min tool Model Torque (mm) weight (mm) (mm) (mm) (mm) (Nm) (Kg) ERGO15A-1 (0°) (22,5°) (45°) ERGO15 A2 (0°) (22,5°) (45°)
- Page 7 INSTALLATION (individual protections are mandatory) Lift here Lift here 4 x M5 x 16 mm (24,6 Nm) Mandatory: arm must be assembled in horizontal position p/n 00.00.04.0468 4 x M6 x 25 mm (10 Nm) p/n 00.00.04.0495 4 x washers p/n 00.00.04.0786 12 mm Recommended:...
- Page 8 ARM INCLINATION CHANGE (individual protections are mandatory)
- Page 9 TOOL CLAMP ORIENTATION CHANGE (individual protections are mandatory) 1 X M8 (24,6 Nm)
- Page 10 2.10 INSTALLATION GUIDELINES Fixation torque (bench installation) • reaction should be always installed in front of the operator (considering his preferred hand) • Fix arm to workstation bench or support through attachment screws (see page 7, pic. 7). • Fix the power tool in the tool holder.
- Page 11 ACCESSORIES ENCODER KIT Model Part Number ENCODER KIT XY ERGO-A-EKIT-XY ENCODER KIT XYZ ERGO-A-EKIT-XYZ...
- Page 12 ENCODERS INSTALLATION (individual protections are mandatory) X encoder Z encoder Y encoder Lock x 3 (Hex. key; Allen 1,5) Encoder Encoder p/n 01.01.22.0957 p/n 00.00.03.1191 Shaft (8 Nm) 2 x M4 x 12 mm (1,5 Nm) p/n 00.00.04.2871 p/n 00.00.04.0446 Lock x 3 2 x M3 x 6 mm (1,5 Nm) Nut M6...
-
Page 13: Product Disposal
MAINTEINANCE Maintenance operations must be carried out by qualified and authorized personnel. ●● Prior to start any maintenance operation: disconnect the tool from electric source. ●● Grinded hardened shaft: periodically clean the shaft from dust with a clean and soft cloth. After cleaning swipe the shaft with light lubrication oil to prevent any corrosion. - Page 14 SAFETY This product is designed to fit power tools having the maximum torque equal or lower than those indicated for each arm model. No other use is permitted. This device is intended only for professional use. GENERAL SAFETY ISSUE In order to reduce risk of injuries, any person which should use, install, repair, make servicing, install accessories and even works nearby this device should read and clearly understand this manual in advance of making any kind of activity.
- Page 15 WHEN USING AN E TERNAL BALANCER • Verify that the balancer suspension support has a safety factor of minimum five times the value obtained by the sum of maximum sustained load plus the balancer weight. Example of calcula- tion: Optimal Safety Factor = (Max support load + balancer weight + torque arm weight + tool weight ) x 5 •...
- Page 16 • Proceed with care in unfamiliar surroundings. Be aware of potential hazards created by your work activity RESIDUAL RISKS This paragraph lists the residual risks or dangers against which the reduction achieved, through design and construction, is not fully or partially effective. The description of the residual risk takes into account the following elements: •...
- Page 17 RESIDUAL RISK EXPOSED PERSON There is a possibility of hand/finger shearing Installation operators, users, maintenance between the arm bracket (1) and the mobile operators and third persons stroke limiter (2) present on the middle joint PICTOGRAM/ LABEL PREVENTION MEASURE • Train the exposed persons •...
- Page 18 RESIDUAL RISK EXPOSED PERSON There is the possibility of accidental impact Installation operators, users, maintenance between the horizontal arm (1) and the operators and third persons operator’s body in case it is left free to rotate PICTOGRAM/ LABEL around the axis of the column (2) PREVENTION MEASURE •...
-
Page 19: Limited Warranty
During the validity of warranty period, should the product show any material or functional defect, it must be returned to DELTA REGIS or their agents, together with a short description of the alleged defect. DELTA REGIS shall, at its sole discretion, arrange to repair or replace free of charge such items as are deemed faulty by reason of defective workmanship or materials. -
Page 20: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY According to Enclosure II.A of EC Directive 2006/42/CE on Machinery and other applicable Directives DECLARATION IN ORIGINAL LANGUAGE We, (Company name) Address: (address of the company) As manufacturer, hereby declare under our responsibility that the product(s): ERGO15A —...
