- Page 1 HARVIL 3-IN-1 FLIP TABLE ASSEMBLY INSTRUCTIONS NGD1018/1022...
- Page 2 THANK YOU! Thank you for your purchase of this Harvil product. We work around the clock and around the globe to ensure that Harvil products maintain the highest possible quality. However, in the rare instance that your product is defective or missing parts, contact your retailer to submit parts requests or warranty claims.
- Page 3 PARTS IDENTIFIER (NOT TO SCALE) ADDITIONAL EQUIPMENT REQUIRED:...
-
Page 4: Assembly Tips
ASSEMBLY TIPS 1. Find a clean, level surface to begin the assembly of your game table. The table will be par- tially assembled upside down and then turned over onto its legs. This is a heavy game and turning it over will require at least two strong adults. 2. - Page 5 ASSEMBLY INSTRUCTIONS 1. Remove the four 1-1/4” WASHER HEAD SCREWS #32 from TABLE BODY #1 that secure the AIR HOCKEY PLAYFIELD #30 during shipping. DO NOT DISCARD THESE SCREWS – They will be used to re - attach the AIR HOCKEY PLAYFIELD. Remove and unpack accessory boxe s from inside the TABLE BODY.
- Page 6 ASSEMBLY INSTRUCTIONS (CONT.) 5. Insert four BARREL NUTS #11 into each SIDE SUPPORT BRACE #15 then attach SIDE SUP- PORT BRACES to each PEDESTAL PANEL as shown with BOLT #4 and 5/16” FLAT WASHER #5. 6. Pull each pre-installed LARGE BOLT #31 outward and tighten the attached nut. Slide one 3/4”...
- Page 7 ASSEMBLY INSTRUCTIONS (CONT.) 7. Attach one PUCK CATCHER #6 to each assembled PEDESTAL PANEL with 1/2” SCREW #7. 8. Attach ACCESSORY RACK B #26 to the PEDESTAL PANEL with corresponding pre-drilled holes using 1/2” SCREW #7. 9. Attach ACCESSORY RACK A #25 to the opposite PEDESTAL PANEL with 1/2” SCREW #7. 10.
- Page 8 ASSEMBLY INSTRUCTIONS (CONT.) 11. To assemble TABLE TENNIS TOP, place TABLE TENNIS TOP #10A and TABLE TENNIS TOP #10B on top of assembled table. Push halves together. 12. Clip each post of the TABLE TENNIS NET #14 to each side of the assembled TENNIS TABLE TOP at the center line.
-
Page 9: Care And Use
CONGRATULATIONS! You have now assembled your Harvil Game Table. Please note the Care and Use instructions below to en- sure years of trouble free use of your game table. CARE AND USE 1. This product is intended for INDOOR use only.
