Additional Battery Unit BUM100RE Instruction Manual
● This manual contains important information regarding the safe use of the BUM100RE. Please read
these instructions before installing and/or using the product.
● Please connect the additional battery unit only after having fully understood the relevant procedures for
the UPS (Uninterruptible Power Supply), found in the UPS Instruction Manual.
Safety precautions
● The safety symbols used in this manual are explained below.
Warning
Caution
: Indicates a prohibited action (something you must not do). For example,
sembly is prohibited.
: Indicates a necessary action (something you must do). For example,
is necessary.
Note that some items described as cautions may result in more serious damage under certain condi-
tions.The information described here is very important and must be strictly observed.
Do not disassemble, repair, or modify the product.
● Doing so may cause an electric shock or a fire.
If liquid leaks from the product, do not touch it.
● Doing so may cause blindness or burns.
● If it touches your eyes or skin, wash it out with lots of clean water and consult your doctor.
Do not use this unit when very high reliability and safety are required as listed
below. This unit is designed and manufactured for use with FA or OA equipment
such as personal computers.
● Medical equipment or system that may cause death directly.
● Applications that directly affect the safety of people (For example, the operation and control of cars and
elevators).
● Applications in which a failure of the unit may cause significant damage to the society and public (For
example, essential computer systems and main communication equipment.)
● Applications with the same level of importance.
The weight of the BUM100RE is 25kg. Carefully consider the weight when
unpacking and transporting this product.
For information about repairs, contact us at __________.
● Injury may result if the unit falls or is dropped.
● If you drop the unit, stop using it and have it inspected and repaired.
Keep plastic bags out of the reach of children.
● Children may suffocate if they put their heads into plastic bags.
This manual contains important information regarding the safe
use of this product.
Please read these instructions before installation and/or use.
Indicates an imminently hazardous situation which, if not handled
properly, may result in death or serious injury.
Indicates a potentially hazardous situation which, if not handled
properly, may result in injury or property damage.
* Property damage means damage to houses/household effects, livestock, and pets.
Warning
Caution
Warning
(product use)
(installation)
1
indicates that disas-
indicates that grounding

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BUM100RE and is the answer not in the manual?

Questions and answers

Summary of Contents for Omron BUM100RE

  • Page 1 Additional Battery Unit BUM100RE Instruction Manual ● This manual contains important information regarding the safe use of the BUM100RE. Please read these instructions before installing and/or using the product. ● Please connect the additional battery unit only after having fully understood the relevant procedures for the UPS (Uninterruptible Power Supply), found in the UPS Instruction Manual. This manual contains important information regarding the safe Safety precautions use of this product.
  • Page 2 Caution (installation) Do not install the unit in other than specified orientations. ● Dropping or toppling the unit may cause injury. ● If you install the unit in an orientation other than specified, the unit cannot be protected from a battery fluid leakage. Use the included vertical stand when positioning the unit vertically. ● Do not use the unit where the maximum temperature exceeds 55°C. ●...
  • Page 3 Caution (battery replacement) Perform replacement on a stable and flat surface. ● Handle the battery carefully so that you do not drop it. ● Dropping the battery may result in injury or burns due to leakage (acid). Use a specified battery for replacement. ● Using a battery other than that which is specified may cause a fire. ● Product models: BUB100RE: 2 required Do not replace the battery in a place where there is flammable gas. ● A spark may occur when connecting the battery, which may cause an explosion or fire. If fluid (dilute sulfuric acid) leaks from the battery, do not touch it.
  • Page 4: Consignes De Sécurité

    Manuel d’instructions de l’unité de batterie BUM100RE Ce manuel contient des informations importantes concernant l’utilisation en toute sécurité du BUM100RE. ● Veuillez lire attentivement ces instructions avant d’installer et/ou d’utiliser le produit. Ne brancher et installer l’unité de batterie qu’après avoir parfaitement compris les procédures pertinentes ●...
  • Page 5 Attention (installation) BUM100RE pèse 25 kg. Faire attention au poids lors du déballage / transport de ce produit. Pour de plus amples informations sur les réparations, nous contacter au __________. ● Des blessures peuvent survenir si l’appareil tombe ou est lâché.
  • Page 6 Caution (use) Lorsque la batterie est morte, la remplacer immédiatement ou cesser d'utiliser l'appareil. ● Continuer à utiliser l’appareil peut provoquer un incendie. * Les valeurs indiquées dans le tableau à gauche reflètent la durée de Température ambiante Durée de vie prévue vie prévue dans les conditions normales d’utilisation mais ne sont pas 25 ºC 8 ans...
  • Page 7 Attention (remplacement de la batterie) Ne pas court-circuiter la batterie avec des objets métalliques. ● Cela peut provoquer un choc électrique, un incendie ou des brûlures. ● Une batterie usagée peut encore contenir de l’énergie électrique. Ne pas jeter la batterie au feu ni la briser. ●...
  • Page 8: Unpacking The Product

    ● Comme l’appareil est lourd, vous risquez de vous blesser, de l’échapper, ou il peut tomber. BUM100RE pèse 25 kg. Faire attention au poids lors du déballage / transport de ce produit. Pour de plus amples informations sur les réparations, nous contacter au __________.
  • Page 9: Installation And Connection

    2. Installation and connection 2-1 Installation Install the additional battery unit. Do not use this unit in any position other than the correct positions indicated in the illustration below. Correct positions Be careful not to get your fingers caught when arranging the unit. Caster at the bottom may be removed when sitting horizontally. BATTERY UNIT Incorrect positions * Do not place the UPS or the additional battery unit on top of each other. The upper unit may fall down by vibration etc.
  • Page 10: Installation

    Installation Installation de l’unité de batterie supplémentaire. Ne pas utiliser cet appareil dans toute position autre que les positions correctes indiquées sur l’illustration ci- dessous. Positions correctes Faire attention à ne pas se coincer les doigts lors de l'installation de l'appareil. Les supports inférieurs peuvent être retirés en position horizontale. BATTERY UNIT Positions incorrectes * Ne pas placer l'ASC ou l'unité de batterie supplémentaire au dessus l'une de l'autre.
  • Page 11 Sans les équerres de soutien, la pince avant ne peut supporter seule le poids de l’ASC. ● Poids de l’ASC : BU100RE: Env.18,5kg BUM100RE: Env.25kg Dans le cas où l'ASC doit être montée sur un rack, la placer sur la partie la plus basse de ce rack.
  • Page 12 ● Items included in the 19-inch rack support angle mounting bracket set Rack rail (front) L ........... 1 Rack rail (front) R ........... 1 Rack rail (rear) ............2 Ear brackets ............2 Rail length fixing screws (M4) ........ 4 Ear bracket mounting flat-head screws (M3)..
  • Page 13 (2) Adjust the length of support angles to suit the server rack, and then securely tighten the screws that were half-tightened in step 1. 2 (3) For EIA standard-compliant installation, use the 8 included EIA rack fixing nuts (M5) and 8 EIA/ JIS rack fixing screws (M5) to securely fasten the front (the side displaying “L” or “R”) and the back of the support angles to the server rack. 3 The screw holes are located at the top and bottom for both front and rear. For JIS standards, use a total of 6 included screws to fix the rack; 1 JIS rack fixing flat-head screw (M5) at a front position of the each of right and left support angles, 2 EIA/JIS rack fixing screws (M5) at 2 rear positions. 3 The screw hole position for the front is at the second screw hole from the top, the rear is at the second screw hole from the bottom.
  • Page 14 (5) Place the unit on the support angles and push it completely into the rack 5 , and use the 2 included EIA/JIS rack fixing screws and unit fixing nuts to securely fasten the ear brackets to the server  rack. 6 Push completely in N I T Use the unit fixing screws to fasten Always use the support angles.
  • Page 15 2-1-2. Stationary installation Perform installation only as shown in the diagrams below. ● Horizontal installation Attach the included rubber feet for horizontal installation with the included M3 screws and position the unit horizontally. For stationary horizontal installation, make sure that this product does not slide or fall. BU100RE BUM100RE BATTERY UNIT When connecting multiple additional battery units, install them at a lower position than the UPS. Do not slide the unit when the rubber feet are touching the floor. ● Upright installation Use the upright stands (2) and M3 flat-head screws (6) included with the product. Secure stands with screws (M6 or M7) on the installation location. BUM100RE BU100RE BUM100RE BUM100RE When connecting multiple additional battery units,...
  • Page 16 (3) Fix the cable holder of the connection cable to the back of the UPS with screws, and connect the battery addition connector and battery addition signal connector at the back of the UPS. BU100RE Cable holder Battery addition signal connector BUM100RE Overcurrent protection switch screw Battery addition connector Additional battery cable * It is mounted diagonally to prevent too much protrusion.
  • Page 17: Replacing The Battery

    3. Replacing the battery The battery can be replaced while the UPS is stopped. (power supply output stopped) Caution When performing battery replacement while the unit is installed vertically, replace the upper battery before pack replacing the lower battery pack. G The unit may fall over if the lower battery pack is removed Caution Be sure to replace the batteries of the UPS and additional battery unit at the same time.
  • Page 18 2. Remove the two screws that fix the subpanel. Shift the subpanel to the right by approx. 5 mm, and then pull it toward you and remove it. N I T 3. Rotate the two screws on the right side counterclockwise to loosen for about one rotation. Do not remove these screws. (Doing so may result in the bracket on the back of the panel slided to the left and the panel come off.) 4. Put the tip of the driver into the upper right hole and slide the subpanel to the left.remove it. 5. Pull the right side of the battery fixing plate (it holds the battery so that it won’t slip and drop) toward you for approx. 10 cm, and then pull it to the right for approx. 5 mm to remove it.
  • Page 19 6. Remove the connector of the cable that runs from the battery pack. Pull it while holding the locking mechanism located at the top and bottom of the connector. Replacement battery pack ● Model number BUB100RE (2 required) 7. Remove the battery pack by pulling the L-type hold on the front face of the battery pack. Caution Do not hold the battery pack by the connector or cable. Attention Ne pas tenir la batterie par le connecteur ou le câble. Use the line on the label on top of the battery pack, which is 10 cm from the inner edge of the battery, to gauge how much further you need to pull the battery to remove it. Hold the battery securely with both hands so as not to drop it.
  • Page 20 8. Slowly insert the new battery pack into the unit with careful attention not to drop it. Replacement battery pack ● Model number BUB100RE (2 required) BUB100RE Nominal voltage of total battery strings 36 VDC (12 V×3 PCS) Nominal capacity of each battery 7.2 Ah Type of Battery CSB XTV1272 ● CONTAINS SEALED LEAD-ACID BATTERY. ● BATTERY MUST BE RECYCLED.
  • Page 21 13. Put the tip of the driver into the hole at the bottom right of the battery fixing plate, and slide it all the way to the right. The fixing plate will be temporarily fixed. 14. To mount the subpanel, put the hook inside the subpanel into the slit at the right side of the unit. Fix the subpanel with the two screws that have been removed. N I T N I T 15. To fix the front panel, put the hook at the right side of the front panel to inside the subpanel. Fix the sub- panel with the two screws that have been removed. N I T 16. Make sure the unit is mounted securely to prevent it from falling off. Otherwise injury may result.
  • Page 22 If you do not reset the battery life counter, a battery deterioration alarm may occur faster than the expected battery life. Write the date you start using the battery on the included battery replacement date label, and attach it to BUM100RE. Also, the UPS monitoring software included with the UPS enables to keep a record of the soft- ware usage start date Notes This unit uses a lead acid battery.
  • Page 23 4. Dimensions • BUM100RE <Unit: mm/ Tolerance: ±1mm> BATTERY UNIT • BUM100RE 42.5 42.5 (170) 3-M3 flat-head (8.5) 33.5 33.5 2-Dia. 8 (150) 4-8-dia. 4-8-dia.
  • Page 24 • Rubber feet (300) (60) (360) (20) • Ear brackets 15.5 4-dia. 7x10 M3 flat-head (Oval hole) screw x4 B section view 8-7×10 12.7 44.45 (21.75) (19.8)
  • Page 25 • Support angles After installation of rack rails 2-Dia.6.5 4-M4B.R 4-R3.5 Rack rail (Front right) M5 flat head 3-Dia.9 Rack rail (Front left) flat-head screw K1L-D-11072E □ 3- 9...
