TO GET THE MOST OUT OF YOUR
ZERO GRAVITY NANO™ WALL CLIMBER
PLEASE READ THESE INSTRUCTIONS FIRST!
IMPORTANT: When the headlights begin to blink,
the battery is running low on power. The car should
be removed from the wall immediately. Otherwise
the vehicle may fall off the wall.

INSTALL BATTERIES

1. Requires 6 1.5-V AA alkaline batteries.
2. Open the battery door with a screwdriver.
3. If used or spent batteries are present,
remove these batteries from the unit by
pulling up on one end of each battery.
4. Install new batteries as shown in the
polarity diagram (+/-) inside the battery
compartment.
5. Replace battery door securely.
6. Do not dispose of batteries in fire.
Batteries may explode or leak.
7. Check your local laws and regulations for
correct recycling and/or battery disposal.
Battery
Compartment Door
CLOSE
OPEN
Six
1.5-V AA
Alkaline
Batteries
Battery
Compartment
Controller/Charger
4. Slide the
Switch to
"Charge". Red
(Charging) light
will stay on.
Controller to
Charge.
CHARGE
• Charging time should take between 30 and 50 minutes depending on how much charge is left in car.
• NOTE: Do notcharge battery immediately after use. Let car battery cool for at least 10 minutes. If charging is not complete
in 50 minutes, replace the charger batteries.
Your Zero Gravity Nano
TM
INSTRUCTION
GUIDE
Zero Gravity Nano
Wall Climber
CHARGING YOUR ZERO GRAVITY NANO™ WALL CLIMBER
1. Switch
car to
"OFF".
OFF
3. Place Car
on Charger/
Controller
and slide
into place.
5. Within 10 seconds the
controller will detect if
the vehicle is in place.
"Red" light flashing:
Vehicle is charging.
"Green" and "Red" light
flashing: Vehicle is charged.
If both the "Red" and
"Green" lights are flashing
the vehicle is charged.
Wall Climber has a pre-installed rechargeable battery inside the vehicle body.
NOTE: USE ON SMOOTH, CLEAN SURFACES ONLY!
FOR INDOOR USE ONLY.
ADULT SUPERVISION RECOMMENDED!
2. Switch
Controller/
Charger to
"OFF".
6. When charged,
turn Controller/
Charger switch to
the "OFF" postion.
1
Controller/Charger
Check to make sure
contents are complete:
• 1 Zero Gravity Nano™
Wall Climber
• 1 Controller/Charger
• 1 Instruction Guide
OFF
OFF

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Zero Gravity Nano Wall Climber and is the answer not in the manual?

Questions and answers

Summary of Contents for Air Hogs Zero Gravity Nano Wall Climber

  • Page 1 NOTE: USE ON SMOOTH, CLEAN SURFACES ONLY! ® FOR INDOOR USE ONLY. ADULT SUPERVISION RECOMMENDED! INSTRUCTION GUIDE TO GET THE MOST OUT OF YOUR ZERO GRAVITY NANO™ WALL CLIMBER PLEASE READ THESE INSTRUCTIONS FIRST! IMPORTANT: When the headlights begin to blink, the battery is running low on power.
  • Page 2 WHILE DRIVING YOUR ZERO GRAVITY NANO™ WALL CLIMBER MAKE SURE TO FOLLOW THESE RULES 1.22 metres 4 feet Stand at least 1.22 metres/ 4 feet from the wall. Do not drive to or off the edge of the wall. Only drive on smooth, clean, dry surfaces.
  • Page 3 DRIVING ON WALLS OR UPSIDE DOWN To drive on walls and upside down you must have switch positioned to the left ( under “W” . ) NOTE: Avoid driving overhead when other people are around. Do not stand underneath when driving overhead. DRIVING ON THE GROUND The fabric air skirts can be adjusted out ward at a 45°...
  • Page 4 Waste Electrical Products should NOT Spin Master Ltd., 450 Front Street West, Toronto, ON M5V 1B6 Canada ®, TM and © 2009 Spin Master Ltd. Air Hogs ® is a be disposed of with household waste. Please recycle Customer Care: 1-800-622-8339 www.spinmaster.com/customercare...
  • Page 5 NOTE : A UTILISER UNIQUEMENT ® SUR UNE SURFACE LISSE ET PROPRE ! POUR INTERIEUR UNIQUEMENT. SUPERVISION D’UN ADULTE RECOMMANDEE ! MODE D’EMPLOI POUR PROFITER AU MAXIMUM DE VOTRE GRIMPEUR DE MURS ZERO GRAVITY NANO VEUILLEZ D’ABORD LIRE LES DIRECTIVES. IMPORTANT : Lorsque les phares commencent à...
  • Page 6 LORSQUE VOUS CONDUISEZ VOTRE GRIMPEUR DE MURS ZERO GRAVITY NANO SUIVEZ ATTENTIVEMENT CES REGLES 1,22 mètres 4 pieds Se tenir à au moins 1,22 mètres/4 pieds du mur. Ne pas conduire vers ou depuis un coin de mur. Ne conduire que sur des surfaces lisses, propres et sèches.
  • Page 7 CONDUITE SUR LES MURS OU A L’ENVERS Pour conduire sur les murs ou à l’envers vous devez mettre l’interrupteur à gauche (sous « W »). NOTE : Éviter de conduire au plafond lorsqu’il y a des personnes autour de vous. Ne pas se tenir juste en dessous de la voiture. CONDUITE AU SOL La jupe d’air peut être ajustée à...
  • Page 8 N’ONT PAS leur place dans les sacs à déchets. Spin Master Ltd., 450 Front Street West, Toronto, ON M5V 1B6 Canada ®, MC et © 2009 Spin Master Ltd. Air Hogs ® est une marque Renseignez-vous auprès de votre organisme local ou de Service consommateurs : 1-800-622-8339 déposée de Spin Master Ltd.
