Air Hogs Skywinder Instructions Manual

Spin master ltd. motorized toy vehicle user instruction
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Vertical
Tail Wing
Rudder
Antenna
Horizontal
Tail
Wing
Main
Plane
Wing
Body
Propeller
Propeller
Tip
SKYWINDER™ STUNT PLANE
CONTROLLER
1. Use a Phillips screwdriver
to loosen the screw in the
battery compartment door.
2. Remove the battery door.
3. Insert six 1.5 Volt AA
batteries (not included).
4. Replace battery
compartment door and
refasten the screw.
IMPORTANT:
Be sure to insert the
batteries as indicated
inside compartment with
the correct polarity.
• Battery installation should be performed by an adult.
• Use only batteries recommended. Be careful to install the batteries with the
correct polarity, as indicated.
• Do NOT mix old and new batteries.
• Do NOT mix alkaline, standard, or rechargeable batteries.
• Do NOT attempt to charge non-rechargeable batteries.
• Do NOT short circuit the supply terminals.
• Do NOT overcharge the plane's batteries.
• Exhausted batteries are to be removed, as they will adversely affect the
performance.
• Do not dispose of batteries in fire. Battery may explode or leak.
Stunt Flap
Stunt Flap
Adjustment
Knob
ON/OFF
Switch

BATTERY INSTALLATION

IMPORTANT BATTERY INFORMATION
INSTRUCTIONS
TM
ON/OFF
Switch
Toggle
Thrust
Button
CONTROLLER
Propeller
Propeller
Tip
Training
Stand
Charging
Charger
Port
Base
CHARGER/TRAINER/
DISPLAY STAND
1. Use a Phillips screwdriver
to loosen the screw in the
battery compartment door.
2. Remove the battery door.
3. Insert eight 1.5 Volt D
alkaline batteries
(not included).
4. Replace battery
compartment door and
refasten the screw.
IMPORTANT:
Be sure to insert the
batteries as indicated inside
compartment with the
correct polarity.
• CAUTION: Plane contains a rechargeable cell. If fluid leaks from the plane,
avoid contact with eyes and dispose of the plane. Only use charger supplied
with this package.
• Do NOT use any other source to charge your SkyWinder
• Different types of batteries or new and used batteries are not to be mixed.
• Do not use rechargeable batteries.
• Only batteries of the same or equivalent type as recommended are to be used.
• Rechargeable batteries are to be removed from the toy before being
charged (if removable).
• Rechargeable batteries are only to be charged under adult supervision
(if removable).
TM
Contents:
1 SkyWinder™ Stunt Plane
1 Controller
1 Charger/Trainer/Display Stand
2 Extra Propellers
1 Tool
Charging
Indicator
NO ASSEMBLY
Light
REQUIRED
Land
Button
ON/OFF
Charging
Switch
Light
Ready
Light
CHARGER/TRAINER/DISPLAY STAND
Tool
Charging
Hose
Charge
Nozzle
TM
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Air Hogs Skywinder and is the answer not in the manual?

Questions and answers

Related Manuals for Air Hogs Air Hogs Skywinder

Summary of Contents for Air Hogs Air Hogs Skywinder

  • Page 1: Battery Installation

    Vertical Tail Wing Rudder Stunt Flap Antenna Horizontal Tail Wing Main Plane Wing Body ON/OFF Propeller Propeller Switch SKYWINDER™ STUNT PLANE CONTROLLER 1. Use a Phillips screwdriver to loosen the screw in the battery compartment door. 2. Remove the battery door. 3.
  • Page 2 IMPORTANT: BEFORE YOUR FIRST FLIGHT, YOU MUST CHARGE AND DISCHARGE YOUR AIRPLANE FULLY 1 TIME. YOU MUST ALSO REPEAT THIS STEP WHEN A PROLONGED PERIOD OF TIME HAS PASSED WITHOUT FLYING. FAILURE TO DO THIS WILL RESULT IN SHORTENED LIFESPAN FOR YOUR AIRPLANE. FOR ALL OTHER FLIGHTS, CHARGE THE BATTERIES ONCE ONLY.

  • Page 3: Pre-Flight Check

    SETTING UP YOUR SKYWINDER STEP 3 Turn the plane’s ON/OFF SWITCH to “ON”. 1. Ensure that the STUNT FLAP is LEVEL (or ALIGNED WITH) the HORIZONTAL TAIL WING. CORRECT ALIGNMENT Horizontal Tail Wing Adjustments can be made by turning the STUNT FLAP ADJUSTMENT KNOB. •...
  • Page 4 • Always launch your plane against the wind direction for best performance. • Never fly the plane in high winds. HIGH WINDS WILL LIMIT, AND MAY PREVENT, YOUR ABILITY TO CONTROL THE AIRPLANE. USE IN HIGH WINDS MAY ALSO RESULT IN LOSS OF, OR DAMAGE TO, THE AIRPLANE.
  • Page 5 HOW TO COMPLETE ADVANCED STUNTS ON YOUR AIR HOGS STEP 1 Set plane’s ON/OFF SWITCH to “ON” for power. NOTE: ENGINES WILL NOT START YET (See Step 2). STEP 3 Launch plane against wind. Toss it firmly, level with the ground. STEP 5 –...
  • Page 6 HOW TO COMPLETE ADVANCED STUNTS ON YOUR AIR HOGS STEP 5 – STUNTS continued 2. SIDEWINDER TOGGLE BACK to climb. REMEMBER: When you are finished flying your SKYWINDER™, turn the plane’s ON/OFF SWITCH to “OFF” and the CONTROLLER’S ON/OFF SWITCH to “OFF”. IMPORTANT INFORMATION –...

  • Page 7: Front View

    CHANGING PROPELLERS ON YOUR SKYWINDER™ In case of propeller damage, please use the steps below to replace the damaged propeller: 1. With one hand, grab hold of the PROPELLER. 2. While holding the PROPELLER in place, use your opposite hand to unscrew the removeable PROPELLER TIP with the PROPELLER REPLACEMENT TOOL.

  • Page 8: Fcc Requirements

    (90) days (unless specified in alternate warranties) from the date of purchase. In the event of such a defect within the warranty period, Spin Master Ltd., at our sole option, will repair or replace the product or provide you with another product of equal value. Repair or replacement shipment is free of charge.
