FUSE
OPERATION
Double press to turn light on.
Single press to toggle between modes.
Two second hold until single flash will activate DayBright pulse pattern.
Three second hold until two flashes to turn light off.
If the light is left on when the bike is powered down it will turn on immediately when the bike is next
turned on.
NB If the light does not turn on, make sure the light function is active on the bike console.
MAINTENANCE
Inspect and test your light and bracket before every ride.
Keep your light clean and free of dirt, be careful when cleaning any mud or dirt from the lens to
avoid scratching.
Never use a high pressure spray or hose on your light.
Do not use harsh, abrasive or corrosive materials to clean your light.
EXP U G22
EXP U G22
Ultimate Sports Engineering Ltd
Unit 4 Bury Mill Farm
Bury
West Sussex
RH20 1NN
United Kingdom
#ownthenight
For more information please visit:
For more information please visit:
exposurelights.com
exposurelights.com
USER GUIDE
Advertisement
Related Manuals for Exposure Lights FUSE
Summary of Contents for Exposure Lights FUSE
- Page 1 USER GUIDE FUSE OPERATION Double press to turn light on. Single press to toggle between modes. Two second hold until single flash will activate DayBright pulse pattern. Three second hold until two flashes to turn light off. If the light is left on when the bike is powered down it will turn on immediately when the bike is next turned on.
- Page 2 INSTALLATION GUIDE FUSE PLEASE TAKE YOUR E-BIKE AND EXPOSURE E-BIKE LIGHT TO AN AUTHORISED DEALER FOR YOUR MOTOR MANUFACTURER FOR INSTALLATION. MINIMUM TOOLS REQUIRED (AUTHORISED DEALER USE) • Hex keys: 2.5mm and 3mm • Pliers with side cutter • Wire strippers •...
- Page 3 FIT THE BRACKET TO THE BARS Use the appropriate shims: • Pre-installed – 25.4mm Bars • Slim Shim – 31.6mm Bars • No Shim – 35mm Bars The bracket should be fitted to the bars on the drive side (right-hand side when in the saddle) of the stem and pointed down approx.
- Page 4 FIT THE MOTOR SPECIFIC CABLE TO THE BIKE (BOSCH, BROSE AND YAMAHA) PLEASE TAKE YOUR E-BIKE AND EXPOSURE E-BIKE LIGHT TO AN AUTHORISED DEALER FOR YOUR MOTOR MANUFACTURER FOR INSTALLATION. Route the power cable to the motor. Due to the extensive variety of bikes, routing and designs this is a case-by-case choice, if you need advice please contact your local supplier or the bike manufacturer.
- Page 5 WARNING! IF THE NEXT STEPS ARE NOT PERFORMED CORRECTLY YOU MAY DAMAGE YOUR BIKE, LIGHT; OR BOTH. The lights will draw as much power as they require to run the LEDs at their brightest. This means that if the light can draw more power than is available from the bike it may damage the bike motor. Ensure to match the current setting of the light to the power output of the bike.
