Exposure Lights ACTION 1 9 Manual

LIGHT OPERATION

Located on the back of the light unit is the Function Button.
The function button operates the light. The Bi-colour and / or OLED screen informs you of the mode and the battery power status.
· To turn on the light, double click the function button, the light turns on in the brightest mode.
· To switch between the constant settings, press the Function Button once. When the setting is changed the colour of the button
for the first 3 seconds informs you which light mode has been selected. Thereafter the BI-colour LED's indicate your fuel level.
· To turn off the light, press and hold the Function Button for 1 second. The light will go out, release the button and the light
will have switched off.
· To activate strobe from ON mode press and hold the button for two seconds. The light will turn off and then flash. Release
the button after the first flash.
· To activate S.O.S from ON press and hold the button for four seconds. The lights will turn off and then flash, continue to
hold the button for two seconds and then release.

TAP (TAP ACTIVATED POWER)

The ACTION series gain improved functionality with TAP. A simple tap to the light or light mount will change the mode to allow
simple control through the light or the attachment brackets, without the need to locate the button. TAP can be activated and
deactivated as required along with altering sensitivity.
To change any TAP settings, from OFF, press and hold the button for three seconds.
ACTION 1
When you release the Function Button it will go green for two seconds. While it is lit tap the light to select a setting. To turn TAP on in its
most sensitive setting tap the light once, two taps will select medium sensitivity and 3 taps will select the least sensitive setting. To turn
TAP off, following the initial three second hold do not tap the light the light will change from green to double flash red indicating TAP is
deactivated (see website for instructional video).
ACTION 3
Release the function button when the OLED display shows TAP H. Press again, each time adjusting the TAP sensitivity
between high, medium and low. The 3rd press will deactivate TAP (TAP OFF). Having chosen the preferred setting the OLED
screen will confirm the selection by flashing the chosen setting.
Note: OLED screen is only on the ACTION 3
QUICKSTART GUIDE
ACTION SERIES
