  • Page 1 ADF 32...
  • Page 2 English Operating instructions Page 1-5 Deutsch Bedienungsanleitung Seite 6-9 Francais Mode d'emploi Page 10-13 Nederlands Gebruiksaanwijzing Pagina 14-17 Italiano Istruzioni per I'uso Pagina 18-21 Espanol Modo de empleo Pagina 22-25...
  • Page 3 English from the date of initial consumer sale Introduction provided: This colour monitor is suitable for use with (1) reasonable evidence is supplied that the home and personal computers equipped with monitor was purchased within 12 months output socket. prior to the date of the claim. (2) the defect is not due to use of the monitor on an incorrect voltage or contrary to Especially for UK...
  • Page 4 Positioning/Ventilation Connections (rear panel) In order to prevent overheating, ensure that the ventilation openings in the monitor are not covered. The monitor should not be placed near a source of heat nor on a soft surface since this would block the ventilation slots on the bottom.
  • Page 5 Operation Switching on . • Press button (LED lights up). Switching off • Press button again. Picture and sound controls For an optimum adjustment of the video and audio input signals various controls are available. • Open flap O. • The image may be positioned horizontally with knob •...
  • Page 6 Technical specifications* Picture tube : 14 inch, in-line slotted, pitch 0.42 mm Deflection : 90° Monitor input sockets for RGB signals 1) Euroconnector : RGB linear (see specification) 2) DIN connector : RGB TTL (see specification) Monitor input sockets for audio signals 1) Euroconnector f 150 mV - 2 Vrms 2) Phono connector...
  • Page 7 The specification of the Euroconnector is as follows: 2 audio input 0.5 Vrms/ > 10 kOhm 4 earth connection for audio 5 earth connection B input 6 audio input 0.5 Vrms/ > 10 7 B input 0.7 Vpp/75 Ohms 9 earth connection G input 11 G input 0.7 Vpp/75 13 earth connection R input...
  • Page 8 3122 125 90701...
