JAKARTA COFFEE TABLE WITH SHELF ASSEMBLY INSTRUCTIONS
Thank you for purchasing the Jakarta Coffee Table With Shelf.
Please read the instructions carefully to ensure safe operation of this product.
PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of construction.
Carefully open the pack supplied and check the contents against the parts and fittings check list. Do not
destroy any of the packaging until you are certain that you have all the necessary parts for the assembly.
CAUTION: There are small components used in the construction of this unit. These loose items should be
kept away from young children whilst assembling your unit to avoid the danger of choking.
Size:
105 x 55 x 40 cm (WDH)
Colour:
Mango
Finish:
Melamine Veneer
Tools Required
Version 1 - 180520
Page 1 of 6
Number of people
x1
0.5 Hour
Set Up
