1.4 SPECIFICATIONS continued . . .
High Voltage Output Module (Version V only):
Power Input:
• 115 OR 230VAC 50/60Hz single phase
Note: 115 / 230 VAC factory set. Specify when
ordered
• Input Power fused at 5,125A @ 115 VAC
Input Power fused at 5.063A @ 230VAC
• Low Voltage Circuitry fused at 125mA @ 115VAC
Low Voltage Circuitry fused at 63mA @ 230VAC
Output:
• 0 to 24, 45, or 90VDC, all @ 5 Amp with 115VAC In
OR
• 0 to 45 or 90VDC, all @ 5 Amp with 230 VAC In
Signal Input:
• 0-10VDC
Optional Pulse Tachometer Card:
• Input: 0-50kHz, 1-50VDC pulses
Optional Relay Card:
• Max Voltage: 230VAC
• Max Current: 5A (with resistive load)

1.5 ENVIRONMENTAL CONDITIONS

This section applies to equipment designed to be safe at least under the following conditions:
• Indoor use.
• Altitude up to 6500 ft (2000 meters).
• Temperature range: 32° F to 104° F (0° C to 40° C).
• Maximum relative humidity 95% over the temperature range (non-condensing).
• Main supply voltage fluctuations not to exceed +/-10% of the nominal voltage.
• Main supply transient overvoltages according to overvoltage category II of IEC 60364-4-443.
• Pollution Degree 2 in accordance with EN61010-1:2001.

1.6 STANDARD FEATURES

• Flexible, Powerful Configuration. The controller can be utilized in unwind, rewind, or intermediate tension
zones. It can be configured for standard (transducer feedback only) tension control, for line speed follow with
tension trim or for diameter compensated line speed follow with tension trim modes of control. The PID based
control algorithm features adaptive diameter compensation and acceleration compensation capability to
handle a wide array of tension control applications.
• Informative, Intuitive User Interface. The SteadyWeb
display for presenting real time tension and related process information and facilitating controller configuration
and calibration. Illustrated prompts and color graphics make set up a breeze and allow for a short operator
learning curve. Real time information is displayed in a clear and highly configurable manner with operator
selectable use of line graphs, or an analog meter. The menu system is easily navigable and on-screen
information pages are provided for every menu, setting and function, acting as an on-screen manual
• Multiple Stored Setups. Up to 30 Setups can be stored in addition to the ACTIVE Setup. Operator
programmable descriptive Setup names are possible with the controller's alphanumeric naming capability.
Setups can be uploaded and downloaded to a PC via a USB port.
• Anti-Tamper Switch (Operator Lockout) Disables operator access to certain menu functions and settings.
Optional RS232 Card:
• Selectable Baud Rate: 4800, 9600, 14400, 19200
• Modbus RTU Interface, Jumper Configurable Null
Modem or Standard communication
Optional RS485 Card:
• Selectable Baud Rate: 4800, 9600, 14400, 19200
• Modbus RTU Interface
• Jumper Configurable 2 or 4 wire mode
Optional DC Tachometer Card:
• 5-15VDC Input:
• 15-250VDC Input:
Optional Enclosure:
• Steel, powder resin painted, NEMA 1
• Dual Transducer Connectors - Amphenol MS3106A-
10SL-3S
(Ref. Appendix F for further information)
™
6 user interface features a full color 5" touchscreen
0-15VDC
0-250VDC
5
