Figure 1.2, General Dimensions (-G Models) - Kelly Manufacturing RC Allen Instruments RCA2610 Series Installation & Operation Manual

3.37
20
10
3.37
10
20
3.17
PANEL CUTOUT
REAR MOUNTING
2.75
20
10
2.40
10
20
2.28
PANEL CUTOUT
REAR MOUNTING
Page 4 of 14
RCA2610 Series Installation/Operation Guide
0.08
Ø 0.170 THRU
(4 PLACES)
1.237
(TYP)
2.474
(TYP)
RCA2610-3-G
0.12 1.22
Ø 0.170 THRU
(4 PLACES)
0.928
(TYP)
1.855
(TYP)
RCA2610-2-G

Figure 1.2, General Dimensions (-G Models)

KMC Publication No.1401-3
0.40
1.22
D I
M
2 0
1 0
1 0
2 0
0.40
NOTE
2 0
•
All dimensions in inches.
1 0
•
1 0
Mounting Hardware (both units)
2 0
6-32 screw - 0.5" plus panel thickness
•
Mating Connector (both units)
MS3116E8-4S or equivalent.
KMC
KELLY MANUFACTURING COMPANY
A D
C
B
A GROUND
B 9-32 VDC
C SPARE
D SPARE
A GROUND
B 9-32 VDC
C SPARE
D SPARE
D
A
C
B
Rev D
