- Page 1 ARM programmer and daughter board www.matrixtsl.com EB185...
-
Page 2: Table Of Contents
Contents About this document Board layout General information Circuit description Protective cover Circuit diagram Copyright © Matrix Technology Solutions Ltd. -
Page 3: About This Document
E-blocks and wish to learn how to use them from the The information provided within this document is beginning there are resources available to help. correct at the time of going to press. Matrix TSL reserves • Relevant software and hardware that allow you to use the right to change specifications from time to time. -
Page 4: General Information
‘PSU’ . If This daughter board enables the ARM board to be both using USB power place the jumper on the right hand a development board and a programmer. This means Copyright © Matrix Technology Solutions Ltd. - Page 5 Turn power to the ARM board off using SW 1. Press and hold the PROG button switch down. Turn power on with SW1, and less than half a second after release the PROG button switch. Copyright © Matrix Technology Solutions Ltd.
- Page 6 1. When to re-flash 2. Move SW1 to OFF and replace the TST jumper to Re-flashing is only required if the Matrix ARM OS has been the Default position. deleted or overwritten, or if an updated Matrix OS file has 3.
- Page 7 Also on D0 - Analogue Pin PA18/AD1 Also on D1 - Analogue Pin PA19/AD2 Also on D2 - Analogue Pin PA20/AD3 Also on D3 - Analogue Pin Analogue Pin Analogue Pin Analogue Pin Analogue Pin Copyright © Matrix Technology Solutions Ltd.
-
Page 8: Protective Cover
12mm M3 spacers, anti-slip M3 nuts and 25mm M3 bolts can be used to attached the cover to the board. These are not included but can be bought separately from our website. The order code for the EB003 multimedia board is EB703. Copyright © Matrix Technology Solutions Ltd. -
Page 9: Circuit Diagram
Circuit diagram Copyright © Matrix Technology Solutions Ltd. - Page 10 Circuit diagram Copyright © Matrix Technology Solutions Ltd.
- Page 11 Circuit diagram Copyright © Matrix Technology Solutions Ltd.
- Page 12 Matrix Technology Solutions Ltd. The Factory 33 Gibbet Street Halifax, HX1 5BA, UK t: +44 (0)1422 252380 e: sales@matrixtsl.com www.matrixtsl.com EB185-30-3...
