Complete Ramp-Hold Operating Instructions
Digital Temperature Controller
Program (pg 8)
From IdLE, press 4.
Select stored program (1 - 4).
Enter rate, temperature, and
hold for each segment.
Edit a Program (pg 13)
During firing, press 4.
Change the current segment
temperature. Press Enter.
Change the hold. Press Enter.
The kiln will continue firing.
Alarm (pg 12)
From IdLE or during
firing, press 7.
Enter a temperature. When
alarm sounds during firing,
press Enter.
Enter/Start (pg 8)
Press Enter/Start after each
step in programming a firing.
Press Enter/Start once from
to begin firing.
Options (pg 14-18)
From IdLE, press 0. Press
Enter for option displayed.
Change the thermocouple
temperature. (Pg 14)
(Pg 15)
lect Type K, S or R. (Pg 15)
Select vent
fan or alarm. This is a special op-
tion not on all kilns. (Pg 16)
Shows the factory setting. (Pg 16)
Enter the
rate shown on your electric bill.
(Pg 16)
Enter your kiln's wattage. (Pg 16)
IM-218/12-06
Sentry
See pages 24 - 25 for instructions on upgrading your DTC
100, 600, 800 or 1000 series board to the Sentry.
identification number for output to
a computer. (Pg 17)
Set temperature sensitivity for
FTH, FTC & LTdE error codes.
(Pg 17)
Se-
Check for overheating. (Pg 18)
program tamper-proof. (Pg 18)
technicians. (Pg 18)
(Pg 18)
tics tool. (Pg 18)
Removes thermo-
couple offset and returns the
board to factory defaults. (Pg 18)
2.0
Select
Firing Cost (pg 12)
Press 8 after the kiln
fires to completion.
The cost of the last firing
will appear. (First enter
electrical cost in the
option and kiln
(Pg 17)
wattage in the
tion, pg 16.)
Make a
Multiple-Zone Options
(pg 14)
For
temperature difference be-
tween any two zones. (Pg 14)
Shows temperature of each
Diagnos-
zone. (Pg 14)
Delay (pg 11)
From IdLE, press 3.
Enter time in hours:minutes.
Delays the start of firing.
Add Time (pg 11)
During firing, press 2.
Each additional key press
adds five minutes to a hold.
Present Status (pg 12)
During firing, press 5.
Shows the segment number that
is currently firing and whether the
segment is in ramp or hold.
Program Review (pg 9)
From IdLE or during
firing, press 6.
Shows the program that is
loaded in memory and ready to
fire, or the one that is firing.
Skip Segment (pg 13)
During firing, press 9, then
Enter.
Skips to the next ramp.
Stop/Back (pg 7)
Press during firing or
programming.
Stops a firing.
In Options, takes you back
to
.
op-
During programming, takes
you back one step each
time key is pressed.
Largest
