Control Panel Parts - Whirlpool GY396LXPB02 Parts List

For Models: GY396LXPB02, GY396LXPQ02, GY396LXPT02, GY396LXPS02
Illus. Part
No. No. DESCRIPTION
1 Control Panel
8191145 White
8191146 Biscuit
8191147 Black
8191148 S.Steel
3 9757476 Control, Migration
4 9757119 Bracket, Console
5 3196068 Lens, Ind. (2)
6 9757410 Bracket, Control
7 8523265 Housing, Ind. Lt.

CONTROL PANEL PARTS

(Black) (White)
Illus. Part
No. No. DESCRIPTION
8 Endcap
9756614BT Biscuit LH
9756614WH White LH
9756614BL Black LH
9756611BT Biscuit RH
9756611WH White RH
9756611BL Black RH
3196172 Screw
2
(Biscuit) (S.Steel)
Illus. Part
No. No.
9
9756659BL Black
9756659WH White
9756659BT Biscuit
10 3196537 Screw
11 9780271 Screw
12 311865 Screw
DESCRIPTION
Knob
8186751
