ExtremeMobility AP510e
FCC/WR
Installation Guide
9035996-01 Rev AA
Published July 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP510e and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EXTREMEMOBILITY AP510e

Summary of Contents for EXTREMEMOBILITY AP510e

  • Page 1 ExtremeMobility AP510e FCC/WR Installation Guide 9035996-01 Rev AA Published July 2019...
  • Page 2 Copyright © 2019 Extreme Networks, Inc. All rights reserved. Legal Notice Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.

  • Page 3: Table Of Contents

    Providing Feedback to Us..............................4 Getting Help.....................................5 Documentation and Training............................6 Chapter 1: Overview........................7 AP510e Features..................................7 AP510e LEDs Status................................10 Chapter 2: Installation Process....................12 Verifying the Box Contents.............................12 Mounting and Connecting the AP..........................13 Mounting Brackets and Accessories Usage......................13 Mounting the AP on a Dry or Wood Wall/Solid Flat Ceiling................

  • Page 4: Preface

    We are always striving to improve our documentation and help you work better, so we want to hear from you! We welcome all feedback but especially want to know about: • Content errors or confusing or conflicting information. ExtremeMobility AP510e FCC/WR...

  • Page 5: Getting Help

    Any related RMA (Return Material Authorization) numbers Subscribing to Service Notifications You can subscribe to email notifications for product and software release announcements, Vulnerability Notices, and Service Notifications. Go to www.extremenetworks.com/support/service-notification-form. 2 Complete the form with your information (all fields are required). ExtremeMobility AP510e FCC/WR...

  • Page 6: Documentation And Training

    Some software files have been licensed under certain open source licenses. More information is available at: www.extremenetworks.com/support/policies/open-source-declaration/. Training Extreme Networks offers product training courses, both online and in person, as well as specialized certifications. For more information, visit www.extremenetworks.com/education/. ExtremeMobility AP510e FCC/WR...

  • Page 7: Chapter 1: Overview

    The Bluetooth port can be used for a remote antenna in place of the internal antenna. The AP has an extended operating temperature range. The AP510e can be mounted on a dry or wood wall, solid flat ceiling, junction/gang box, and on a suspended or drop ceiling.
  • Page 8 Overview • -20°C to +55°C (-4° F to + 131° F) @ Sea Level. • Enclosure: Plastic with metal base. Figure 1: Top view of AP510e Figure 2: Side view of AP510e ExtremeMobility AP510e FCC/WR...
  • Page 9 Figure 3 on page 9). If you need to power the AP510e with an external 12V DC power supply, you can plug the power cord into the power connector on the back of the AP. There is no wall mount bracket for the 12V DC power supply.

  • Page 10: Ap510E Leds Status

    Radio 1 2x2 (14dBm) 4x4 (16dBm) Radio 2 2x2 (14dBm) 4x4 (16dBm) Dual band Dual 5G AP510e LEDs Status LEDs Status The AP510e LEDs are located on the front face of the AP but are not visibly marked. ExtremeMobility AP510e FCC/WR...
  • Page 11 Overview Figure 4: AP510e LEDs Table 5: AP510e LEDs Status LED Icon LED Color Description AP Status GREEN Normal operational status AMBER Non-operational status GE1 Ethernet AMBER 100 Mbps GREEN 1000 Mbps PURPLE 2.5G/5G GE2 Ethernet AMBER 100 Mbps GREEN...

  • Page 12: Chapter 2: Installation Process

    4 Connect the power supply. Verifying the Box Contents Before you install the AP510e access point, make sure that you have all the necessary parts. Verify that the box contains the following items: Table 6: AP510e Box Contents Quantity Items...

  • Page 13: Mounting And Connecting The Ap

    Use these instructions as guidelines for mounting and connecting the AP510e easily and safely. The AP510e comes with a stainless-steel main mounting bracket (#37201) that can be used to mount the access point on a flat t-bar with flat ceiling tiles, flat surfaces, beams, and some junction/gang boxes.
  • Page 14 ; used d ceiling with main mount mounting with bracket single width. 30518 9/16", 1.5", Protrude WS-MBI- 15/16" d ceiling DCMTR01 mount bracket with varying widths. 30516 Wall WS-MBI- mount WALL04 with bracket single width. Junction installatio ExtremeMobility AP510e FCC/WR...

  • Page 15: Mounting The Ap On A Dry Or Wood Wall/Solid Flat Ceiling

    2 #30516, WS-MBI-WALL04 bracket, two Phillips pan-head screws, and screw-in anchors. Note The WALL04 bracket and screw-in anchors are used only for dry or wood wall mounting. 3 #37201, stainless-steel main mounting bracket with #37210, flat metal easy-attach adapter. ExtremeMobility AP510e FCC/WR...
  • Page 16 Mounting the access point to a wall using the Main Mounting Bracket The stainless-steel main mounting bracket (#37201) ships with the access point and can be used to mount the access point onto a wall. This is the recommended method of installation for a wall mounting procedure. ExtremeMobility AP510e FCC/WR...
  • Page 17 2 Drill two holes 83 mm (3.270") apart from each other on the wall where you want to mount the access point. 3 Insert the screws into the holes of the mounting bracket and use the screw-in anchors if needed. 4 Insert the Ethernet cable's RJ45 connector into the LAN1 port. ExtremeMobility AP510e FCC/WR...
  • Page 18 5 Insert the access point onto the bracket's four feet and slide it down to lock it in place. Figure 6: Main mounting bracket attachment holes on the access point Label Description Guide posts to attach the security torx locking screw ExtremeMobility AP510e FCC/WR...
  • Page 19 Perform this task after the access point is attached to the main mounting bracket on a dry or wood wall. Line up the security torx locking screw using the rear guides on the access point. 2 Tighten the security torx locking screw using a T8 bit screwdriver. ExtremeMobility AP510e FCC/WR...
  • Page 20 You cannot remove the access point from the main mounting bracket until the security torx locking screw is removed. Mounting the AP to a wall using the WS-MBI-WALL04 bracket Mounting the access point to a flat ceiling requires the WS-MBI-WALL04 (#30516) bracket, two Philips pan-head screws, and two screw-in anchors. ExtremeMobility AP510e FCC/WR...
  • Page 21 Drill the holes and attach the bracket using the screws and screw-in anchors. Note When using the "A" or "B" holes, if the holes are not near the corners of the bracket, you can break off the corner to decrease the bracket's visibility once the access point is installed. ExtremeMobility AP510e FCC/WR...
  • Page 22 The access point can also be mounted onto a wall or a solid flat ceiling by attaching a flat metal easy- attach adaptor to the main mounting bracket. The flat metal easy-attach adaptor (#37210) must be purchased separately. ExtremeMobility AP510e FCC/WR...
  • Page 23 4 Attach the main mounting bracket with the easy-attach adaptor to the access point. 5 Connect the LAN cable to the back of the access point. 6 Hold the access point to the wall, insert the two screws onto the mounting holes of the flat metal easy-attach adaptor. ExtremeMobility AP510e FCC/WR...
  • Page 24 When installing the access point, the “E” logo on it must be pointing up. 5 If the access point is loose, unmount the access point, and decrease the distance between the screw heads and the wall. 6 Remount the access point. ExtremeMobility AP510e FCC/WR...

  • Page 25: Mounting To A Suspended/Drop Ceiling

    T-bar minimum base thickness: N/A; must be structurally sound. • T-bar maximum base thickness: 0.055”. Due to manufacturing variation, some adaptors may be able to accommodate up to 0.060”. • Ceiling tile may protrude up to 0.3" below the T-bar. ExtremeMobility AP510e FCC/WR...
  • Page 26 Remove the ceiling panels around the drop ceiling T-bar rail. 2 Open the movable sliding part of the DCFLUSH bracket to give the stationary and slider T-bar more space. Figure 13: DCFLUSH bracket parts Label Description T-bar Movable sliding part of the DCFLUSH bracket ExtremeMobility AP510e FCC/WR...
  • Page 27 Pre-Installation checklist: • T-bar width must be 9/16” (15 mm), 15/16” (24 mm), 1.5” (38 mm). • T-bar minimum base thickness: N/A; must be structurally sound. • T-bar maximum base thickness is 0.118” (3 mm). ExtremeMobility AP510e FCC/WR...
  • Page 28 4 Tilt the T-bar up slightly in such a way that you are holding the stationary and movable sides of the bracket. 5 Squeeze the bracket parts together until you hear the T-bar locking tab click into place. ExtremeMobility AP510e FCC/WR...

  • Page 29: Mounting The Ap To A Junction/Gang Box

    WS-MBI-WALL04 bracket, which must be purchased separately. Note The junction/gang box models are limited to USA box models when using the #37201 main mounting bracket. Remove the screws holding the junction/gang box coverplate and remove the LAN cable from the coverplate if necessary. ExtremeMobility AP510e FCC/WR...

  • Page 30: Mounting The Access Point To A Beam

    Before attaching the AP onto a beam, verify that: • Beam attachment area is at least 0.5” (12.7 mm) wide and as long as the access point's largest dimension. • Beam mounting surface is less than 0.650” (16.5 mm) thick. ExtremeMobility AP510e FCC/WR...
  • Page 31 2 Using a twisting motion between the main mounting bracket hinges, attach the beam clip accessory Figure 18: Attaching the beam clip accessory to the main mounting bracket 3 Attach the main mounting bracket with the beam clip accessory to the access point. ExtremeMobility AP510e FCC/WR...
  • Page 32 Figure 19: Attaching the beam clip accessory to the beam 5 Use the screw and clamp on the top of the beam clip accessory to secure the access point in place on the beam. 6 Insert the Ethernet plug into the LAN port. ExtremeMobility AP510e FCC/WR...

  • Page 33: Chapter 3: Operational Description Of Antenna Configuration And Rf Output Power Setting

    2.4G/5G Omni ML-2452- PTA4M4-0 2.4G/5G Omni WS-AO- DQ04360 2.4G/5G Panel ML-2452- 6.92 7.23 5.92 5.23 SEC6M4-0 2.4G/5G Panel WS-AI- 7.23 5.92 5.23 DQ05120 2.4G(BT/ Panel ML-2452- 10.7 Thread)/5 PNA7-01R 2.4G(BT/ Omni ML-2499- Thread) HPA8-01 2.4G/5G Omni DQ04360S ExtremeMobility AP510e FCC/WR...

  • Page 34: Chapter 4: Antenna Information

    Antenna Information Antenna configurations for external antenna models AP510e Antenna Information Antenna configurations for external antenna models Figure 20: AP510e external antenna configuration Table 11: AP510e antenna configuration Software mode Radio 1 Radio 2 Antenna ports 1,2,3,4 Antenna ports 5,6,7,8 Mode 1 2.4 GHz...

  • Page 35: Ap510E Antenna Information

    Antenna Information AP510e Antenna Information AP510e BLE Antenna Information Note The BLE internal antenna is used if no BLE antenna connector is attached to the port. Wi-Fi Part number Brand Model name Description Panel ML-2452-PNA7-01R Extreme ML-2452-PNA7-01R 2.4G omni and...
  • Page 36 Antenna: 2.4/5 GHz, outdoor, panel, 8/12dBi Beam width: • E-plane: 66 degrees • H-plane: 68 degrees Connector type: N- male AP510e Bluetooth Antenna Information Wi-Fi Part number Brand Model name Description Dipole ML-2499-HPA8-01 Extreme ML-2499-HPA8-01 Outdoor, 8dBi, 2.4 Panel ML-2452-PNA7-01R...

  • Page 37: Chapter 5: Specifications

    -4° F to + 131° F (-20 ° C to +55 ° C) @ Sea Level Humidity 0 - 95% (non-condensing) Storage and transportation temperature -40 ° F to + 158° F (-40 ° C to +70 ° C) ExtremeMobility AP510e FCC/WR...

  • Page 38: Chapter 6: Regulatory Information

    If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: ExtremeMobility AP510e FCC/WR...

  • Page 39: Fcc Radiation Exposure Statement

    Le présent appareil est conforme aux CNR d’ ISED applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) le dispositif ne doit pas produire de ExtremeMobility AP510e FCC/WR...

  • Page 40: Detachable Antenna Usage

    Le présent émetteur radio [4141B-AP510E] a été approuvé par Innovation, Sciences et Développement économique Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal d'antenne.

  • Page 41: Korea Ble Antennas Support

    Regulatory Information Figure 21: AP510e approved antenna list This device and its antenna(s) must not be co-located with any other transmitters except in accordance with IC multi-transmitter product procedures. Referring to the multitransmitter policy, multiple- transmitter(s) and module(s) can be operated simultaneously without reassessment permissive change.

  • Page 42: Supplement To Product Instructions

    Regulatory Information Supplement to Product Instructions NCC Statement Brazil Anatel Statement Este produto está homologado pela ANATEL, de acordo com os procedimentos regulamentados pela Resolução n°. 242/2000 e atende aos requisitos técnicos aplicados. ExtremeMobility AP510e FCC/WR...

  • Page 43: Mpe Distance - Mobile Devices

    The frequency and the maximum transmitted power in EU are listed below: • 2412-2472MHz: 20 dBm • 2402-2480MHz (BR/EDR): 6 dBm • 2402-2480MHz (LE): 8 dBm • 5180-5240MHz: 23 dBm • 5260-5320MHz: 23 dBm • 5500-5700MHz: 30 dBm ExtremeMobility AP510e FCC/WR...

  • Page 44: European Waste Electrical And Electronic Equipment (Weee) Notice

    Declaration of Conformity in Languages of the European Community English Hereby, Extreme Networks, declares that the radio equipment type (AP510e) is in compliance with Directive 2014/53/EU. For full text of the EU Declaration of Conformity, please contact Extreme Regulatory Compliance at compliancerequest@extremenetworks.com...
  • Page 45 Regulatory Information Dutch Hierbij verklaart Extreme Networks dat het toestel Radio LAN device (AP510e) in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 2014/53/EU. Neem voor een volledige tekst van de EU Deceleration of Conformity contact op met Extreme Regulatory Compliance op compliancerequest@extremenetworks.com...
  • Page 46 Spanish Por medio de la presente Extreme Networks declara que el Radio LAN device (AP510e) cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 2014/53/EU. Para obtener el texto completo de la desaceleración de la conformidad de la UE, comuníquese con Extreme...

  • Page 47: Index

    Antenna List, RF Output Power Setting 33 AP510e Regulatory Information 42 Feature List 7 Regulatory Information, Hazardous Substances 44 AP510e Box Contents, Contents of AP510e, Contents 12 AP510e Installation, Installation Process, How-to-Install AP510e 12 AP510e Mounting Bracket, Accessories, Mounting Brackets safety guidelines 38 Usage, Accessories Usage, Mounting, Brackets 13...
