The AP505i is a next generation, indoor ceiling mount model enterprise-class 802.11ax access point (AP). The “i” in AP505i indicates that it comes with internal antennas. The AP features two simultaneous 4 x 4 radios, eight WiFi internal antennas, and one Bluetooth Low Energy (BLE) antenna. The AP505i can be mounted on a dry or wood wall, solid-flat ceiling, junction/ gang box, and on a suspended or drop ceiling.
Page 8
Overview Figure 1: Top view of AP505i Figure 2: Side view of AP505i Figure 3: AP505i side ports ExtremeMobility™ AP505i FCC/WR...
Console Port (Yellow) LAN2 (GE) (Black) LAN1 (5GE) (Purple) LED Indicators AP505i access points have LED indicators on the front of the unit. The LEDs are not visibly marked. Figure 4: AP505i LED Icons Table 4: AP505i LEDs LED Icon...
Power over Ethernet (PoE) Power is provided through the RJ45 Ethernet port (GE1 port) to the right of the 12V DC port of AP505i, compliant to be powered by 802.3af and 802.3at. This is the preferred method of powering the AP on ceiling and high wall installations.
Connect the power supply to the AP505i access point. Verifying the Box Contents Before you install the AP505i access point, make sure you have all the necessary parts for installation. Verify that the box contains the following items: Table 6: AP505i Box Contents...
Extreme Networks there are any signs of damage. Note Before mounting the AP505i, read the Safety Guidelines. Mounting Brackets and Accessories Usage The access point comes with the Main Mounting Bracket (#37201). The AP can also be used with various other brackets and accessories that can be purchased separately.
Page 13
Requires mount #37201 with bracket single width. mounting 30518 9/16", 1.5", Protrude WS-MBI- 15/16" d ceiling DCMTR01 mount ; Bracket with warying widths. 30516 Wall WS-MBI- mount WALL04; with Bracket single width. Junction/ Gang box mounting ExtremeMobility™ AP505i FCC/WR...
The AP can be mounted to a suspended/drop ceiling using: #37201, Main Mounting Bracket to a Flat T-bar. 2 #37201, Main Mounting Bracket with adaptor KT-135628-01 to a Flat T-bar. 3 #37211, WS-MBI-DCFLUSH bracket to a Flat T-bar. ExtremeMobility™ AP505i FCC/WR...
Page 15
T-bar bottom must be flat all the way across. • T-bar minimum base thickness: N/A; must be structurally sound. • T-bar width must be 15/16” (24mm). • Ceiling tile must be flat all the way across. Attach the main mounting bracket to the AP. ExtremeMobility™ AP505i FCC/WR...
Page 16
Mounting the AP to a suspended or drop ceiling requires the optional adaptor (Universal Mounting Kit for WLAN APs; # KT- 135628-01). The adapter requires a flat t-bar and fits a ceiling tile with up to a 0.35” protrusion from the bar. Pre-Installation cheklist: ExtremeMobility™ AP505i FCC/WR...
Page 17
The optional WS-MBI-DCFLUSH (#37211) bracket can also be used for T-bar installations without the mounting bracket. Pre-Installation checklist: • T-bar width must be 9/16” (15mm), 15/16” (24mm), 1.5” (38mm).T-bar bottom must be flat all the way across. • T-bar minimum base thickness: N/A; must be structurally sound. ExtremeMobility™ AP505i FCC/WR...
Page 18
7 Attach the Ethernet cable’s RJ45 connector to the LAN1 port and place the ceiling tile back in place. Mounting the AP using the WS-MBI-DCMTR01 Bracket The optional WS-MBI-DCMTR01 (#30518) bracket can also be used for T-bar installations without the mounting bracket. ExtremeMobility™ AP505i FCC/WR...
Page 19
Figure 8: Attaching the AP unit onto the WS-MBI-DCMTR01 bracket 7 Hold the AP and rock it back and forth to ensure that it is securely mounted. 8 Attach the Ethernet cable’s RJ45 connector to the LAN1 port and place the ceiling tile back in place. ExtremeMobility™ AP505i FCC/WR...
Installation Process Mounting the AP on a Dry or Wood Wall/Solid Flat Ceiling The AP505i can be mounted to a dry/wood wall or a solid flat ceiling using various mounting brackets listed in this section. Note The recommended method of installation is using the Main Mounting Bracket.
Page 21
Drill the holes and attach the bracket using the screws and screw-in anchors. Note When using the "A" or "B" holes, if the holes are not near the corners of the bracket, you can break off the corner to decrease the bracket's visibility once the AP is installed. ExtremeMobility™ AP505i FCC/WR...
Page 22
2 Hold the AP to the surface to which it needs to be attached and use the optional bracket’s end holes as a template to mark the attachment holes. 3 Drill two holes on the wall where you want to mount the AP. 4 Connect the LAN cable to the back of the AP. ExtremeMobility™ AP505i FCC/WR...
Page 23
The “E” logo must be in the right orientation before tightening the screws. Mounting to a wall using the Philips Pan-head screws You can mount the AP505i access point directly onto a dry/solid wall using the Philips Pan-Head screws. This is an optional installation method and not the preferred mode of installation.
5 Align the keyhole slots and posts and slide the AP onto the bracket until you hear it lock in place. Mounting the AP to a Beam The AP505i access point can be mounted onto a beam using a beam clip accessory (BRKT-000147A-01) to the main mounting bracket.
Power is provided through the RJ45 Ethernet port (LAN1 port) to the right of the 12V DC port of AP505i, compliant to be powered by 802.3af. This is the preferred method of powering the AP on ceiling and high wall installations.
Page 26
Installation Process 2 The AP505i can also be powered by an external DC power supply plugged into an AC source. Plug the supply’s input jack into the DC-In port. Table 11: AP505i Power Supply Options AP505i Port Function LAN1 Port...
Specifications This section lists the specifications for the ExtremeMobility ™ Indoor Access Point AP505i. AP505i Specifications Table 12: Physical Specifications Part Number: AP505i-FCC Cloud-ready, Dual Radio 802.11ax/ac/abgn, 4 x 4:4 MIMO Indoor 11ax access point. Intenal Antenna. Domain: US, Puerto Rico, and Colombia Part Number: AP505i-WR Cloud-ready, Dual Radio 802.11ax/ac/abgn, 4 x 4:4...
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. ExtremeMobility™ AP505i FCC/WR...
DFS Warning: Dynamic Frequency Selection (DFS) for devices operating in the bands 5250- 5350 MHz, 5470-5600 MHz and 5650-5725 MHz. Warning DFS Warning: Sélection dynamique de fréquences (DFS) pour les dispositifs fonctionnant dans les bandes 5250-5350 MHz, 5470-5600 MHz et 5650-5725 MHz. ExtremeMobility™ AP505i FCC/WR...
This product complies with the requirements of Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment. Supplement to Product Instructions ExtremeMobility™ AP505i FCC/WR...
Declaration of Conformity in Languages of the European Community English Hereby, Extreme Networks, declares that the radio equipment type (AP505i) is in compliance with Directive 2014/53/EU. For full text of the EU Deceleration of Conformity, please contact Extreme Regulatory Compliance at compliancerequest@extremenetworks.com...
Page 33
2014/53/EU. Spanish Por medio de la presente Extreme Networks declara que el Radio LAN device (AP505i) cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 2014/53/EU. Portuguese Extreme Networks declara que este Radio LAN device (AP505i) está...
Antenna Information Internal Antenna access point The AP505i is an indoor access point with eight WiFi internal antennas and one BLE internal antenna. Table 15: AP505i Internal Antenna Access point Application Description Gain (dBi) Frequency (GHz) Connector model AP505i Indoor...
