- Page 1 ™ ExtremeMobility AP510i FCC/WR Installation Guide 9035994 Published March 2019...
- Page 2 Copyright © 2019 Extreme Networks, Inc. All rights reserved. Legal Notice Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.
-
Page 3: Table Of Contents
Brazil Anatel..................................36 Hazardous Substances..............................36 Supplement to Product Instructions.........................36 NCC Statement..................................37 CE Information..................................37 European Waste Electrical and Electronic Equipment (WEEE) Notice..........38 Declaration of Conformity in Languages of the European Community..........38 Index............................40 ExtremeMobility™ AP510i FCC/WR Installation Guide... -
Page 4: Preface
Before contacting Extreme Networks for technical support, have the following information ready: • Your Extreme Networks service contract number and/or serial numbers for all involved Extreme Networks products • A description of the failure • A description of any action(s) already taken to resolve the problem ExtremeMobility™ AP510i FCC/WR Installation Guide... -
Page 5: Documentation And Training
Hardware/Software Compatibility Matrices https://www.extremenetworks.com/support/compatibility-matrices/ White papers, data sheets, case studies, https://www.extremenetworks.com/resources/ and other product resources Training Extreme Networks offers product training courses, both online and in person, as well as specialized certifications. For more information, visit www.extremenetworks.com/education/. ExtremeMobility™ AP510i FCC/WR Installation Guide... -
Page 6: Chapter 1: Overview
“i” in AP510i indicates that it comes with internal antennas. The AP features a dual-band radio and comes with eight WiFi internal antennas and one Bluetooth Low Energy (BLE) antenna. The AP510i can be mounted on a dry or wood wall, solid flat ceiling, junction/ gang box, and on a suspended or drop ceiling. - Page 7 Overview Figure 1: Top view of AP510i Figure 2: Side view of AP510i Figure 3: AP510i back ports ExtremeMobility™ AP510i FCC/WR Installation Guide...
-
Page 8: Ap510I Led Status
The Kensington lock can use a 3mm diameter safety hangar cable and the rear hole can accommodate a 2.9mm diameter safety hangar cable. AP510i LED Status LED Status The AP510i LEDs are located on the front face of the AP but are not visibly marked. Figure 4: AP510i LEDs ExtremeMobility™ AP510i FCC/WR Installation Guide... -
Page 9: Ap510I Powering Methods
If you need to power the AP510i with an external 12V DC power supply, you can plug the power cord into the power connector on the back of the AP. There is no wall mount bracket for the 12V DC power supply. - Page 10 Overview The following configuration will allow you to bring up the access point in 802.11af power mode. AP510i 802.11af profile: • 2x2 (16dBm for both 2.4G and 5G at u.fl connector) • Only dual band (mode 1), doesn’t support dual 5G (mode 3) •...
-
Page 11: Chapter 2: Installation Process
Verifying the Box Contents Before you install the AP3915i access point, make sure that you have all the necessary parts. Verify that the box contains the following items: Table 4: AP510i Box Contents Quantity Items AP510i Quick Reference Mounting bracket for 802.11ax access point (Main... -
Page 12: Mounting Brackets And Accessories Usage
Use these instructions as guidelines for mounting and connecting the AP510i easily and safely. The AP510i comes with a Mounting Bracket (#37201) that can be used to mount the AP on a flat t-bar with flat ceiling tiles, flat surfaces, beams, and some junction/gang boxes. An adaptor and brackets are available for mounting the AP to non-flat ceiling tiles and t-bars. - Page 13 #37201 with bracket single width. mounting 30518 9/16", 1.5", Protrude WS-MBI- 15/16" d ceiling DCMTR01 mount ; Bracket with warying widths. 30516 Wall WS-MBI- mount WALL04; with Bracket single width. Junction/ Gang box mounting ExtremeMobility™ AP510i FCC/WR Installation Guide...
-
Page 14: Mounting The Ap On A Dry Or Wood Wall/Solid Flat Ceiling
2 #30516, WS-MBI-WALL04 bracket, two Philips pan-head screws, and screw-in anchors, which must be purchased separately. Note The WALL04 bracket and screw-in anchors are used only for wall mounting. 3 #37201, Main bracket with #37210, Flat Metal-Easy Attach Adaptor. ExtremeMobility™ AP510i FCC/WR Installation Guide... - Page 15 3 Insert the Ethernet cable’s RJ45 connector into the LAN1/GE1 port. 4 Insert the AP onto the bracket’s four feet and slide it down to lock it in place. Note The feet of the bracket must be pointing up. ExtremeMobility™ AP510i FCC/WR Installation Guide...
- Page 16 Note When using the "A" or "B" holes, if the holes are not near the corners of the bracket, you can break off the corner to decrease the bracket's visibility once the AP is installed. ExtremeMobility™ AP510i FCC/WR Installation Guide...
- Page 17 Attach Adaptor The AP can also be mounted onto a wall or solid ceiling by attaching a flat metal easy-attach adaptor to the mian mounting bracket. The flat metal easy-attach adaptor (#37210) must be purchased separately. ExtremeMobility™ AP510i FCC/WR Installation Guide...
- Page 18 2 Hold the AP to the surface to which it needs to be attached and use the optional bracket’s end holes as a template to mark the attachment holes. 3 Drill two holes on the wall where you want to mount the AP. 4 Connect the LAN/Ethernet cable to the back of the AP. ExtremeMobility™ AP510i FCC/WR Installation Guide...
- Page 19 4 Align the AP against the screw heads and slide it down. Ensure that the AP is secured in place and tightened. If the AP is loose, unmount the AP and decrease the distance between the screw head and the wall. Remount the AP. ExtremeMobility™ AP510i FCC/WR Installation Guide...
-
Page 20: Mounting To A Suspended/Drop Ceiling
T-bar bottom must be flat all the way across. • T-bar minimum base thickness: N/A; must be structurally sound. • T-bar maximum base thickness: 0.055”. • Ceiling Tile must be flat all the way across. ExtremeMobility™ AP510i FCC/WR Installation Guide... - Page 21 Mounting the AP to a suspended or drop ceiling requires the optional adaptor (Universal Mounting Kit for WLAN APs; # KT- 135628-01). The adaptor requires a flat t-bar and fits a ceiling tile with up to a 0.35” protrusion from the bar. ExtremeMobility™ AP510i FCC/WR Installation Guide...
- Page 22 Maximum ceiling tile protrusion allowed is 0.015” (0.38mm). Remove the ceiling panels around the drop ceiling T-bar rail. 2 Open the movable sliding part of the bracket to give the stationary and slider T-bar more space. Figure 11: Installing the WS-MBI-DCFLUSH bracket ExtremeMobility™ AP510i FCC/WR Installation Guide...
- Page 23 8 Attach the Ethernet cable’s RJ45 connector to the LAN1 port and place the ceiling tile back in place. Mounting the AP using the WS-MBI-DCMTR01 Bracket The optional WS-MBI-DCMTR01 (#30518) bracket can also be used for T-bar installations without the mounting bracket. ExtremeMobility™ AP510i FCC/WR Installation Guide...
- Page 24 4 Tilt the T-bar up slightly in such a way that you are holding the stationary and movable sides of the bracket. 5 Squeeze the bracket parts together until you hear the T-bar locking tab click into place. ExtremeMobility™ AP510i FCC/WR Installation Guide...
-
Page 25: Mounting To A Junction/Gang Box
The Junction/Gang box models are limited to USA box models when using the #37201 main mounting bracket. Remove the screws holding the junction/gang box coverplate and remove the LAN cable from the coverplate if necessary. ExtremeMobility™ AP510i FCC/WR Installation Guide... -
Page 26: Mounting The Ap To A Beam
3 Place the adapter on a beam in such a way that there is enough space between the screw and clamp to be tightened. 4 Use the screw and clamp on the top of the adapter to secure the AP in place on the beam. 5 Insert the Ethernet plug into the AP. ExtremeMobility™ AP510i FCC/WR Installation Guide... -
Page 27: Chapter 3: Specifications
Specifications This section lists the specifications for the ExtremeMobility ™ Indoor Access Point AP510i. AP510i Specifications Part Number: AP510i-FCC Cloud-ready, Dual 5GHz, Dual Band, Sensor radio, Dual Radio 802.11ax/ac/abgn, 4x4:4 MIMO Indoor 11ax access point. Internal Antenna. Domain: US, Peurto Rico, and Columbia... -
Page 28: Chapter 4: Antenna Information
Antenna Information Internal Antenna access point The AP510i is an indoor access point with eight WiFi internal antennas and one BLE internal antenna. Table 11: AP510i Internal Antenna Access point Application Description Gain (dBi) Frequency (GHz) Connector model AP510i Indoor... - Page 29 Antenna Information Figure 16: Vertical Radiation Pattern 2.4 GHz ExtremeMobility™ AP510i FCC/WR Installation Guide...
- Page 30 Antenna Information Antenna Patterns - 5 GHz Figure 17: Horizontal Radiation Pattern 5GHz - Radio 1 ExtremeMobility™ AP510i FCC/WR Installation Guide...
- Page 31 Antenna Information Figure 18: Vertical Radiation Pattern 5GHz - Radio 1 ExtremeMobility™ AP510i FCC/WR Installation Guide...
- Page 32 Antenna Information Figure 19: Horizontal Radiation Pattern 5 GHz - Radio 2 ExtremeMobility™ AP510i FCC/WR Installation Guide...
- Page 33 Table 12: Maximum Antenna Gain for Integrated Antenna Software Mode Radio 1 Radio 2 IoT Radio Mode 1 4dBi; 2.4GHz 6dBi; 5GHz 5dBi Mode 2 4dBi; 2.4GHz 6dBi; 5GHz 5dBi 5dBi; 5 GHz Mode 3 4dBi; 5GHz 6dBi; 5GHz 5dBi ExtremeMobility™ AP510i FCC/WR Installation Guide...
-
Page 34: Chapter 5: Regulatory Information
• Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. ExtremeMobility™ AP510i FCC/WR Installation Guide... -
Page 35: Industry Canada Notice
IC Radiation Exposure Statement: This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 26cm between the radiator & your body. ExtremeMobility™ AP510i FCC/WR Installation Guide... -
Page 36: Brazil Anatel
This product complies with the requirements of Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment. Supplement to Product Instructions ExtremeMobility™ AP510i FCC/WR Installation Guide... -
Page 37: Ncc Statement
The frequency and the maximum transmitted power in EU are listed below: • 2412-2472MHz: 19.98 dBm • 2402-2480MHz (LE): 6.23 dBm • 5180-5240MHz: 22.98 dBm • 5260-5320MHz: 22.98 dBm • 5500-5700MHz: 29.98 dBm • 2405-2480MHz: 6.48 dBm ExtremeMobility™ AP510i FCC/WR Installation Guide... -
Page 38: European Waste Electrical And Electronic Equipment (Weee) Notice
Declaration of Conformity in Languages of the European Community English Hereby, Extreme Networks, declares that the radio equipment type (AP510i) is in compliance with Directive 2014/53/EU. For full text of the EU Deceleration of Conformity, please contact Extreme Regulatory Compliance at compliancerequest@extremenetworks.com... - Page 39 2014/53/EU. Spanish Por medio de la presente Extreme Networks declara que el Radio LAN device (AP510i) cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 2014/53/EU. Portuguese Extreme Networks declara que este Radio LAN device (AP510i) está...
-
Page 40: Index
Power Supply 9 AP510i, Suspended Ceiling Installation, Drop Ceiling Installation, AP510i Installation Procedure, Ceiling Mount 20 technical support AP510i, Wall Mount, Wall Mounting, Wall Mount contacting 4, 5 Instructions, Dry Wall, Wood Wall, Solid Flat Ceiling 14 Brazil Anatel, Regulatory Information 36 CE Information, Regulatory 37 Decleration of Conformity, Regulatory Information 38...
