Fast 307500 Instructions Manual

#307500 and #307501 FAST™ Fuel System Kits
Thank you for choosing FAST™ products; we are proud to be your manufacturer of choice. Please
read this instruction sheet carefully before beginning the installation.
Kit Contents:
1 ea fuel pump wiring kit
1 ea 3ft length of 10 ga. Black wire
1 ea 25ft length of 10 ga. Red wire
1 ea 30 amp circuit breaker
1 ea 30 amp automotive relay
2 ea blue female blade connector
2 ea yellow female blade connector
5 ea yellow #10 stud ring connector
1 ea yellow 3/8" stud ring connector
6 ea tie-wraps
1 ea AN-06 cutoff union
3 ea AN-10 cutoff union
3 ea AN-10 cutoff to AN-08 union
Caution: Installation of this product requires detailed knowledge of automotive systems and
repair procedures. We recommend that this installation be carried out by a qualified automotive
technician. Installation of this product requires handling of gasoline. Ensure you are working in
a well ventilated area with an approved fire extinguisher nearby. Extinguish all open flames,
prohibit smoking and eliminate all sources of ignition in the area of the vehicle before proceeding
with the installation. When installing this product, wear eye goggles and other safety apparel as
needed to protect yourself from debris and sprayed gasoline.
Warning: The fuel system is under pressure. Do not open the fuel system until the pressure has
been relieved. Refer to the appropriate vehicle service manual for the procedure and precautions
for relieving the fuel system pressure. FAST™ fuel system components are not legal for sale or
use on emission controlled motor vehicles. The included FAST™ fuel pump is not compatible
with alcohol based fuels or fuel additives!
This kit assumes you have a sumped fuel tank or fuel cell with accommodations for an AN-10 supply
line and an AN-06 return line. Fuel tank pickups will not work properly with FAST™ fuel systems and
will be detrimental to your fuel systems life. If your fuel tank is not sumped, we recommend having
your fuel tank sumped by a qualified professional. No fuel rails are provided with this kit, your fuel
rails must have accommodations to accept AN-08 hose ends in order to install this kit properly.
1 ea
1 ea
1 ea
1 ea
1 ea
2 ea
2 ea
1 ea
1 ea
12 ea
1 ea
8 ea
