- Page 1 Installation Guide Ideal Workstations , Work&WashStations ™, ® Workstations/WashStations with DryDock ™ ™ BarStations and WashStations ™ ®...
- Page 2 Center hole diameters 2" behind cutout Note: Galley Hot and Cold Water dispenser requires a minimum 8" clearance center to center if installed to the right of the Galley Tap Note: For installation where the drain is on the left side, simply reverse placements of Tap and Tap Accessories...
- Page 3 Center hole diameters 2" behind cutout Note: Galley Hot and Cold Water dispenser requires a minimum 8" clearance center to center if installed to the right of the Galley Tap Note: For installation where the drain is on the left side, simply reverse placements of Tap and Tap Accessories...
- Page 4 Center hole diameters 2" behind cutout Note: Galley Hot and Cold Water dispenser requires a minimum 8" clearance center to center if installed to the right of the Galley Tap Note: For installation where the drain is on the left side, simply reverse placements of Tap and Tap Accessories...
- Page 5 Center hole diameters 2" behind cutout Note: Galley Hot and Cold Water dispenser requires a minimum 8" clearance center to center if installed to the right of the Galley Tap Note: For installation where the drain is on the left side, simply reverse placements of Tap and Tap Accessories...
-
Page 6: Before You Begin
IMPORTANT 1. Please note: Unlike typical undermount kitchen sink installations, The Galley is installed in the cabinet prior to the counter being templated. A support structure, (wood frame cleat system), will need to be constructed and mounted inside the base cabinet(s) and recessed 1/16"... - Page 7 Support frame must be installed 1/16" lower than the top of the cabinet. Use a level to ensure that the support frame is installed level in the cabinet. Once installed, the top of the Galley Basin Flanges will be flush with the top of the cabinet. OVERHEAD VIEW 3.
-
Page 8: Countertop Installation
FOR THE COUNTERTOP FABRICATOR Countertop Installation Use the white template tray affixed to The Galley 1. Cover 1/2” of the front and back flanges that are flanges as your guide for the front to back cutout. Refer closest to the basin, and the 1/4” of the side flanges... - Page 9 The Galley Workstation Limited Lifetime Warranty 1. GALLEY WORKSTATION LIMITED LIFETIME WARRANTY - Seller provides a Limited Lifetime Warranty. Seller warrants its stainless steel sink, installed in a residential application, to be free from manufacturing defects in materials and workmanship under normal residential usage.
