  • Page 1 Positioning axis DMES Operating instructions 8075175 2017-07e [8075177]...
  • Page 2 Text designations: • Activities that may be carried out in any order 1. Activities that should be carried out in the order stated – General lists è Result of an action/References to more detailed information Festo – DMES – 2017-07e...
  • Page 3: Table Of Contents

    ............Festo – DMES – 2017-07e English...
  • Page 4: Operating Elements And Connections

    DMES Operating elements and connections For all available product documentation è www.festo.com/pk Fig. 1 Drive shaft Corner profile for central supports (DMES-18, -25) Mounting thread for motor mounting kit (DMES-25...-63) Mounting thread for switch lug Slide screws Motor mounting kit (è 11 Accessories)
  • Page 5: Function

    A cover strip covers the slot in the profile. Note The DMES is self-braking: When the input torque is not applied, the slide will be braked. The slide, however, can move slowly if – the DMES is mounted vertically, –...
  • Page 6: Transport And Storage

    DMES Transport and storage • Consider the weight of the product. The DMES weighs up to 85 kg depending on the design. • The following should be observed with regard to storage: – Short storage times – Cool, dry, shaded and corrosion-resistant locations.
  • Page 7: Installation

    0.2 mm. For gantry applications, attention must also be paid to parallel alignment or product heights in alignment of the axes. Fig. 5 For additional information, contact your local Festo Service. Festo – DMES – 2017-07e English...
  • Page 8 • Place the central supports on the DMES in accordance with 18, 25 Fig. 6. For DMES-40/63: If the device is tilted, the slot nuts of the central supports will slide into the slot at any point on the profile.
  • Page 9: Installation Of The Payload

    Centring hole [mm] Ø 5 Ø 9 Ø 4 Ø 9 Ø 25 Ø 9 Ø 25 Tab. 2 3. For DMES without a slide: On the through-holes of the driver (“N” in Fig. 11). Festo – DMES – 2017-07e English...
  • Page 10 DMES For payloads with their own guide: • Adjust the guides of the payload and DMES so that they are exactly parallel. You will then avoid overloading the guide (wear). For hard and stiff payloads (steel): Note If the aluminium slide is bent against a curved payload, the service life of the guide will be re­...
  • Page 11: Installing The External Accessories

    If proximity sensors are used as limit switches: • Use proximity sensors with normally-closed function. These protect a DMES with a fractured proximity sensor cable from overrunning the end position. If proximity sensors are used as reference switches: • Use proximity sensors that correspond to the input of the controller being used.
  • Page 12: Commissioning

    – there are no foreign objects in the path of the moving components. It should not be possible to touch the DMES until the load has come to a complete standstill. Note Incorrect specification values for the braking ramp in STOP statuses (e.g. EMERGENCY OFF, Quick Stop) result in an overloading of the linear axis and can destroy it or drastic­...
  • Page 13 In spite of equal control, even motors of the same type sometimes turn in the opposite direction due to the circuitry. The spindle of the DMES turns in a clockwise direction. When the drive trunnion is turned clockwise, the slide moves in the direction of the motor.
  • Page 14: Operation

    Warning Injury to people and material damage! In the event of a spindle nut fracture (e.g. due to wear) inside the DMES, the work load will slide down. • Check whether additional external safety measures to protect against spindle nut fracture are necessary (e.g.
  • Page 15: Maintenance And Care

    1.5 mm If the maximum permitted axial play is exceeded: Warning If a worn spindle nut breaks on a vertical or sloping DMES, the work load will fall. Uncontrolled payloads can cause personal injury and material damage (risk of crushing).
  • Page 16: Repair

    DMES 4. Grease the DMES via the lubricating hole (grease gun, lubrication adapter and lubricating grease: è 11 Accessories). 5. Move the slide along the complete positioning path in order to distribute the grease evenly. Lubrication of the linear roller bearing DMES-...-KF: DMES-18-KF The roller bearings do not need to be relubricated under nor­...
  • Page 17: Troubleshooting

    1) Nominal value: Varies due to component tolerances. 2) Based on DIN 230 T2. 3) Elastic deformation of the DMES in an axial direction when in a blocked position (automatic locking or blocked drive trunnion); the value is to be multiplied by the respective load Fx (payload).
  • Page 18 20 Nm 80 Nm 0.7 Nm 1.6 Nm 4.6 Nm 22 Nm Variant DMES-...-KF with roller bearing guide (GA Z GK) 930 N = 2600 N (GK) = 4300 N (GK) = 6600 N (GK) 7 Nm = 3080 N (GV)
  • Page 19 DMES Characteristic curves 14.1 Maximum axial forces F and speeds v F [N] F [N] DMES-40 DMES-25 DMES-63 DMES-18 Recommended Permitted Permitted with low switch-on duration with adequate cooling phases. Festo – DMES – 2017-07e...
  • Page 20 • EN: Reading example for the following diagrams With a loading of 1000 N and a distance of 700 mm be­ 1000 N tween supports the DMES-... will bend 0.45 mm. Fstat : In the “F ” range only static loadings are per­...
  • Page 21 450 N 600 N 750 N 900 N l [mm] DMES-18-KF (Fz) 150 N 300 N 450 N 600 N 750 N 900 N l [mm] not permitted Load is only permissible during standstill stat Festo – DMES – 2017-07e...
  • Page 22 500 N 1000 N 1500 N 2000 N 2500 N l [mm] DMES-25-KF (Fz) 500 N 1000 N 1500 N 2000 N 2500 N l [mm] not permitted Load is only permissible during standstill stat Festo – DMES – 2017-07e...
  • Page 23 DMES DMES-40-KF (Fy) 1000 N 2000 N 3000 N 4000 N l [mm] DMES-40-KF (Fz) 1000 N 2000 N 3000 N 4000 N l [mm] not permitted Load is only permissible during standstill stat Festo – DMES – 2017-07e...
  • Page 24 5000 N 6000 N 6500 N l [mm] DMES-63-KF (Fz) 1000 N 2000 N 3000 N 4000 N 5000 N 6000 N 6500 N l [mm] not permitted Load is only permissible during standstill stat Festo – DMES – 2017-07e...
  • Page 25 DMES Festo – DMES – 2017-07e...
  • Page 26 Copyright: Festo SE & Co. KG Ruiter Straße 82 73734 Esslingen Germany Phone: +49 711 347-0 Fax: +49 711 347-2144 Reproduction, distribution or sale of this document or communica­ E-mail: tion of its contents to others without express authorization is service_international@festo.com...
