Office Star Products 24/7 ELITE 54666 Operating Instructions

TM
5
3
2
1
LIMITED WARRANTY
24/7 ELITE™ chairs are warranted* from the date of purchase against failure due to material and workmanship as follows:
• 5 Years on component parts including pneumatic cylinder, control mechanism, base and casters.
• 2 Years on upholstery fabric and foam against wear and deterioration.
To make a warranty claim, contact Parts Department. Provide model number and description of the problem and obtain return authorization.
At it's option Office Star Products will:
(a) Supply compatible components of current manufacture.
(b) Repair the customer's component. The customer must prepay freight on any components returned to the factory.
Return freight on components still in warranty will be paid by Office Star Products.
*All warranties are limited to the original purchaser for normal commercial usage defined as a standard forty hour work week by persons weighing 300 lbs. or
less. This warranty will not cover labor, freight or damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other
event beyond the control of Office Star Products. The warranty does not cover cosmetic damage that may result from normal use. Liability for incidental or
consequential damages is excluded. The user assumes all risk of injury resulting from use of this product. This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state.
Our quality standards are among the highest in the industry. Sometimes, no matter how hard we try, there are times when parts
are damaged or missing. Our Parts Department will do everything possible to promptly remedy the problem. Contact us via e-mail
parts@officestar.net, by Fax 1-909-930-5629, or toll free parts number 1-800-950-7262, Monday through Friday 8:00 a.m. - 5:00
p.m. Pacific Time.
24/7 HIGH INTENSITY USE CHAIR
OPERATING INSTRUCTIONS
4
54666
FEATURES
• PNEUMATIC SEAT HEIGHT ADJUSTMENT
To raise seat height, remove pressure from seat and lift lever (1)
up. To lower seat height, sit on chair and lift lever (1) up.
• TILT TENSION ADJUSTMENT
To adjust title tension, turn knob (4) clockwise to increase
tension and counter-clockwise to decrease or ease the tension.
NOTE: Be careful not to completely loosen knob (4).
• BACK TILT ANGLE ADJUSTMENT
To adjust the back tilt angle, apply pressure to backrest and pull
lever (3) out for free float. To lock backrest into position push
lever (3) in.
• SEAT SLIDER ADJUSTMENT
To slide seat forward or backward, pull lever (2) out. Release
lever (2) to lock desired seat position.
• ARM HEIGHT ADJUSTMENT
To adjust arm height, push button (5) to allow the arms to move
up or down freely. Release button (5) once the desired
height is reached.
WARNING
1. Use this product only one person at a time.
2. Do not use this chair unless all bolts screws and
knobs are securely tightened.
3. Check that all bolts screws and knobs are tight every
three months or as needed.
4. Do not overturn back tilt knob when decreasing
tension.
5. Dispose of packing material properly. Do not use
plastic cover as head covering. It may cause
suffocation.
6. Do not use chair as a stepladder.
7. Use this chair for its intended purpose only.
8. Use mild detergent only for cleaning.
