- Page 1 SECTION BENDING MACHINE MC400 INSTRUCTIONS BOOK PRADA NARGESA, S.L Ctra. de Garrigàs a Sant Miquel s/n · 17476 Palau de Santa Eulàlia (Girona) SPAIN Tel. +34 972568085 · nargesa@nargesa.com · www.nargesa.com...
- Page 2 Thank you for choosing our machines www.nargesa.com...
-
Page 3: Table Of Contents
4.6 Mounting the rollers....................8 5. ASSEMBLING THE ROLLERS................... 10 5.1 Axes traction of the machine..................10 5.2 Rollers for standard pipes..................10 5.3 Capacidad de curvado..................... 11 5.4 Different samples of bending .................. 12 TECHNICAL ANNEX MC400 BENDING MACHINE INSTRUCTION BOOK... -
Page 4: Machine Information
Delring rollers to avoid damaging the works in inox or aluminium. If an accident occurs due to a negligent use on the operative’s side, for not following the safety ru- les exposed on this book, PRADA NARGESA S.L will not accept any resposibility. 1.3. Contraindications of use Every use different from the one for bending of materials. -
Page 5: Descripción De Los Accesorios
230 v, as it is indicated below: Star connection, when the line tension is 400v (preset): Star connection, when the line tension is 400v (preset) MC400 BENDING MACHINE INSTRUCTION BOOK... - Page 6 As well, it is necessary to change the input terminals of the inverter for the change of tension. Input 400V. (Terminals “0”and “400”). Input to 230 V. (Terminals “0” and “230”). In order to detail the procedure, please see the sketch. MC400 BENDING MACHINE INSTRUCTION BOOK...
-
Page 7: Transport, Maintenance And Storage
- It is advisable not to pile up machines nor heavy objects on top of them. - Do not dismantle for storage. 2.2. Transport Transportation must be carried out by using a forklift truck. 2.3. Dimensions Weight: 365 Kg MC400 BENDING MACHINE INSTRUCTION BOOK... -
Page 8: Installment And Starting Up
Never touch the rollers when they are bending material for the damage they can caus, there might be risk of hands smashing. The place to locate the machine must be selected taking into account the room it will occupy the metal bar during the performance of the operation. MC400 BENDING MACHINE INSTRUCTION BOOK... -
Page 9: Instructions For The Usage
There will be a white PVC box where the electric handling and the protection fuse. In case you need to substitute one, it is advisable to put one of the same value. MC400 BENDING MACHINE INSTRUCTION BOOK... -
Page 10: Principles For Bending
It is advisable to put some oil in the up and down threads of the rollers whenever necessary to avoid them from getting any hardness. 4.6. Assembling of rollers MC400 BENDING MACHINE INSTRUCTION BOOK... - Page 11 Nomenclature of the rollers and assembly IMPORTANT NOTE: The clamping nut of the rollers should never be tightened with a wrench and only by hand. If pipe rollers are being used, the nuts must be loose. MC400 BENDING MACHINE INSTRUCTION BOOK...
-
Page 12: Axes Traction Of The Machine
2.5 mm. For pipe in mm. (25+30) - (20+35) - 33 - 40 - 43 - 50 - 50,8 - 60 For any other size or profile please ask the manufacturer. MC400 BENDING MACHINE INSTRUCTION BOOK... -
Page 13: Capacidad De Curvado
50,8 x 3 63,5 x 3 63,5 x 3 76,2 x 2 101,6 x 3 = 2” x 3 = 2”1/2 x 3 =2”1/2 x 3 = 3” x 2 = 4” x 3 Optional rollers MC400 BENDING MACHINE INSTRUCTION BOOK... -
Page 14: Different Samples Of Bending
5.4. Different samples of bending MC400 BENDING MACHINE INSTRUCTION BOOK... -
Page 15: Technical Annex
Technical annex MC200 Bending Machine General Parts Diagram Elcetric map... - Page 16 A1 General parts diagram MC400 BENDING MACHINE INSTRUCTION BOOK...
- Page 17 230V socket the terminals of the engine MOTOR must be changed and the wire to the 415V input must be put into the input for 230V of the inverter. PROTECTION FUSE PEDALS AND EMERGENCY STOP MC400 BENDING MACHINE INSTRUCTION BOOK...
- Page 18 3. Complete the form with your details and press Message Sent: confirms your data has been successfully sent to Prada Nargesa SL. Your machine has been registered and has a warranty of three years in total. Your request has been sent correctly. We will contact you right...
