EMC DATA DOMAIN DD620 Installation And Setup Manual page 3

Define the Data Domain System Information for Your Site
2
SYSTEM SETUP WORKSHEET
An installation requires information unique to your site. Before starting the
installation, provide values for the system information listed below.
1. A fully qualified host name for the system:
2. The DNS domain name:
3. Enter the Ethernet connectivity information in Table 1 below.
4. A routing gateway IP address (if no DHCP):
5. DNS server IP addresses (if no DHCP):
Primary Secondary
6. Select the CIFS authentication method:
Workgroup
Workgroup name:
WINS servers:
Backup user
name:
Password:
7. Backup servers (or * for all):
8. Administrator's password:
TABLE 1:
Ethernet Connectivity
Enable (circle one)
Use DHCP (circle one)
IP address (if no DHCP)
Netmask (if no DHCP)
3 Perform Initial System Configuration
NOTE: Refer to the NVRAM Battery Charging Instructions for information on battery
charge time at initial system installation.
Log into the system with the user name of sysadmin. The password is the
system's serial number. A Configuration Wizard is provided. There are six
sections to the configuration: Licenses, Network, File System, System, CIFS,
and NFS.
Complete each of the six sections.
Tertiary
Active Directory
Realm name:
WINS servers:
Domain admin
name:
Password:
eth0a
Yes / No
Yes / No
9. Host name from which to administer the system:
10. Administrator's email address (or admin group alias):
11. (Optional) Description of the system's physical location:
12. Mail server (SMTP) host name:
13. Time zone name (default is US/Pacific):
14. System Controller ID from the License Code document provided in the
accessory kit. Use this ID to obtain the unique WWPN for this controller
using the WWPN tool at
https://my.datadomain.com/US/en/wwpn.jsp.
15. License Code(s) - Refer to License Code document(s) provided in the
accessory kit. License characters, including dashes, are entered for each
licensed feature; for example ABCD-ABCD-ABCD-ABCD.
16. Record the serial number (SN) found on the back of the chassis.
eth0b eth3a (optional)
Yes / No Yes / No
Yes / No Yes / No
USING THE CLI CONFIGURATION WIZARD
At the first login, the configuration wizard starts. The list entries in the utility can
be separated by a comma, a space, or both.
4 At each prompt, enter a value, OR
4 Enter a question mark (?) for more details, OR
4 Press Enter to accept the value displayed in braces.
The Configuration Wizard guides you through the configuration steps, one
section at a time. Follow the Configuration Wizard instructions for entering
appropriate values.
At the end of each configuration section, you can choose to:
4 Save – Save the displayed configuration.
4 Cancel – Delete all new values and go to the next section.
4 Retry – Restart the input entry at the beginning of the current section.
The value entered previously appears as the default value at each prompt.
EMC DATA DOMAIN DD620 INSTALLATION AND SETUP GUIDE | SIDE 1
eth3b (optional)
Yes / No
Yes / No
