OWNERS MANUAL
WB-300VB-IP-5
SURGE
PROTECTOR
$50,000
REMOTE
TRIGGER
WELCOME TO WATTBOX
™
WattBox power products are designed specifically to provide customers with advanced protection for their valuable electronics and
custom integrators with maximum flexibility for installation. Rest assured that WattBox products will deliver the protection and safety for
your customers' needs. All WattBox products are UL certified and built with the highest quality components available.
KEY FEATURES
Surge Protection with Fireproof MOVs - Advanced Ceramic MOV technology reduces risk of fire from surges.
Surge Disconnect - In the event of a catastrophic surge event, this Wattbox™ component will sacrifice itself and permanently
disconnect AC Power.
Noise Filtration - Eliminates AC noise to improve picture and sound quality.
Flexible Power Cords - Wattbox™ power cords are both flexible and durable and designed for ease of installation.
Flexible Mounting - Flat, compact design for easy mounting in a VersaBox™ structured wiring enclosure, on a wall, or behind a
desk or TV.
IP Control - Provides control of outlets over an IP network. Turn outlets On or Off through a web browser or set them to power-cycle
when devices lose communication.
Auto Reboot - Monitors network activity and resets power to outlets when programmable conditions are met.
Outlet Control Scheduling - Configure outlets to turn Off or On at a specific date or time.
System Notifications - Programmable email notifications keep you informed of System Status Changes.
pg.1
© 2020 WattBox
™
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for watt box WB-300VB-IP-5
Summary of Contents for watt box WB-300VB-IP-5
- Page 1 ™ OWNERS MANUAL WB-300VB-IP-5 SURGE PROTECTOR $50,000 REMOTE TRIGGER WELCOME TO WATTBOX ™ WattBox power products are designed specifically to provide customers with advanced protection for their valuable electronics and custom integrators with maximum flexibility for installation. Rest assured that WattBox products will deliver the protection and safety for your customers’...
-
Page 2: Package Contents
WATTBOX™ WB-300VB-IP-5 Owners Manual PACKAGE CONTENTS (1) WB-300VB-IP-5 (4) Rubber feet (1) Owner’s Manual (1) 4 foot power cord with 360° swiveling head (1) OvrC Quick Start Guide (1) 6 inch power cord (for use in enclosures and structured wiring cans) -
Page 3: Led Operation
MOUNTING OPTIONS Wirepath™ and Strong® Metal Structured Wiring Enclosures The WB-300VB-IP-5 can be installed in some Wirepath™ and Strong® structured wiring enclosures that are equipped with a bottom knockout. Check the WattBox product page for a complete list of compatible enclosures. -
Page 4: Surface Mounting
To install: 1. Attach the brackets to the WattBox in the desired fashion. Use 3 screws to secure each bracket. 2. Slide the WB-300VB-IP-5 into the cutout until the brackets seat into the keyholes of the Plastic enclosure. To uninstall: Note: Two flathead screwdrivers are needed to remove the WB-300VB-IP-5 from the plastic enclosure cutout. - Page 5 WATTBOX™ WB-300VB-IP-5 Owners Manual IP CONNECTIONS AND SETUP Internet Mobile Apps Web Browser Access OvrC Web Server Use OvrC Web and smartphone apps to monitor the WattBox remotely WB-300VB-IP-5 Router REMOTE TRIGGER pqrs CALL MODE/ MENU/ESC BACK PAGE wxyz ＊...
-
Page 6: Important Safety Instructions
WATTBOX™ WB-300VB-IP-5 Owners Manual IMPORTANT SAFETY INSTRUCTIONS Read and observe the following safety points at all times. WARNING – Power Sources Do not plug this Component into a power outlet that differs from the source indicated for safe use on the Component. If you don’t know the type of electrical power that is supplied to your home, consult your local power company or a qualified electrician. -
Page 7: Troubleshooting
WATTBOX™ WB-300VB-IP-5 Owners Manual TROUBLESHOOTING Symptom Possible Cause Remedy Wattbox is not receiving power. Wattbox is not turned On. • Turn Wattbox switch on. ™ ™ ™ Make sure AC power plug is plugged into a properly grounded 120 volts (nominal) wall outlet. -
Page 8: Specifications
WATTBOX™ WB-300VB-IP-5 Owners Manual SPECIFICATIONS Outlets Type NEMA 5-15 Number of Outlets 5 (separately controlled) AC Power Line Voltage 120V, 60Hz AC Input Connection IEC C-14 Circuit Breaker Rating UL Current Rating Voltage Protection Rating (UL 1449 3rd Edition) 500V... -
Page 9: Warranty
WATTBOX™ WB-300VB-IP-5 Owners Manual WARRANTY 5-Year Limited Warranty Find details of this product’s 5-Year Limited Warranty at snapav.com/warranty, or request a paper copy from Customer Service at (866) 424-4489. Find other legal resources, such as regulatory notices and patent information, at snapav.com/legal. - Page 10 WATTBOX™ WB-300VB-IP-5 Owners Manual If connected equipment damage was indicated on your RA request, WattBox will request the make and model of all connected equipment, a connection diagram of your system, as well as other requests based on the extent of the request for product placement or payment for connected equipment damage.
- Page 11 WATTBOX™ WB-300VB-IP-5 Owners Manual pg.11 © 2020 WattBox ™...
- Page 12 Copyright ©2020, Wirepath Home Systems, LLC. All rights reserved. Control4 and Snap AV and their respective logos are registered trademarks or trademarks of Wirepath Home Systems, LLC, dba “Control4” and/or dba “SnapAV” in the United States and/or other countries. 4Store, 4Sight, Control4 My Home, Snap AV, Araknis, Autonomic, BakPak, Binary, Dragonfly, Episode, Luma, Mockupancy, Nearus, NEEO, OvrC, Pakedge, Sense, Strong, SunbriteTV, Triad, Visualint, WattBox, and Wirepath are also registered trademarks or trademarks of Wirepath Home Systems, LLC.
