- Page 1 Stove Guard 300 User Manual Safety for Your Kitchen www.innohome.com...
- Page 2 Stove Guard 300 User Manual...
- Page 3 Stove Guard 300 User Manual Congratulations! You now own one of the most intelligent cooker safety products in the world.
-
Page 4: Table Of Contents
Stove Guard 300 User Manual 1. Innohome Stove Guard and how to use it 1.1. Structure of the Stove Guard 1.2. Use of the Stove Guard 1.3. Automatic fault diagnostics 1.4. Meaning of alarm signals 2. Monthly Maintenance 3. Low battery alarm 4. -
Page 5: Innohome Stove Guard And How To Use It
1. Innohome Stove Guard and how to use it 1.1 Structure of the Stove Guard The Innohome Stove Guard is composed of an Intelligent Heat Sensor, a Control Unit, and optional Remote Alarm Units. The Intelligent Heat Sensor, the Control Unit and the Remote Alarm Units communicate via radio connection. Using Remote Alarm Units, additional signalling devices can be linked to the system. -
Page 6: Use Of The Stove Guard
Stove Guard 300 User Manual 1. Innohome Stove Guard and how to use it 1.2 Use of the Stove Guard Features depending on cooker type Electrical cooker; mechanical knobs Overheating Monitor Intelligent Timer Alarm Signal Detection (fire, carbon monoxide and gas alarms) Cooker knob Safety Lock Electrical cooker;... - Page 7 1. Innohome Stove Guard and how to use it The Overheating Monitor alarm also resets automatically in two minutes (approx.), when the gas/electricity to the cooker has been cut off and the cooker temperature starts to fall (given that the oven is not in use). The automatic alarm reset will not affect the sensitivity level of the Intelligent Heat Sensor.
-
Page 8: Automatic Fault Diagnostics
Stove Guard 300 User Manual 1. Innohome Stove Guard and how to use it be deactivated using the jumper on the Intelligent Heat Sensor (see section 4 ‘Options’). All fire/CO/gas alarms should be located within 16.5ft (5 metres) of the Control Unit to ensure accurate detection. See table in section 1.4 for description of the Stove Guard signals. -
Page 9: Meaning Of Alarm Signals
1. Innohome Stove Guard and how to use it 1.4 Meaning of alarm signals The Intelligent Heat Sensor signal has a higher tone than the Control Unit signal. Sound Meaning Course of Action Intelligent Heat Sensor: a The Intelligent Heat Sensor has detected a Reset the pre-alarm signal by pushing the short ‘beep’... -
Page 10: Monthly Maintenance
Stove Guard 300 User Manual 1. Innohome Stove Guard and how to use it Sound Meaning Course of Action Control Unit: two short The Safety Lock has been turned off and the The cooker can now be used. beeps (after turning the electricity reconnected to the cooker. -
Page 11: Intelligent Heat Sensor Installation
4. Intelligent Heat Sensor Installation 1. Remove the Intelligent Heat Sensor from its packaging and allow it to reach room temperature, waiting around 15 min- utes. 2. Remove the protective plastic strip from the Intelligent Heat Sensor. The Sensor will emit a signal when the power is con- nected. -
Page 12: Control Unit Installation And Setup
Stove Guard 300 User Manual 5. Control Unit Installation and Setup 5.1 Installation and setup If the cooker is connected to the mains electricity via a plug and a socket, the Control Unit can be installed by the user. Otherwise, the installation needs to be carried out by a qualified electrician. -
Page 13: Testing After Installation
6. Testing after Installation 6.1 Alarm Signal Detection test Turn the smallest hotplate to medium heat and test the fire, carbon monoxide and gas alarms, one at a time. When detect- ing an alarm signal the Control Unit will cut the gas/electricity supply to the cooker and emit a short signal at approximately 5 second intervals. -
Page 14: Setting The Sensitivity Level Of The Intelligent Heat Sensor
Stove Guard 300 User Manual 8. Setting the sensitivity level of the Intelligent Heat Sensor The sensitivity level determines the level of heat or the rate of temperature change required to activate the Intelligent Heat Sensor. The Intelligent Heat Sensor responds to the user resetting the Overheating Monitor pre-alarm signal (see section 1.2) by reducing its sensitivity. -
Page 15: Alarm Output
9. Alarm output The alarm output is a 3.5 mm stereo jack found on the Con- C N 1 trol Unit. The alarm output is a ‘normally open’ type (opto) Alarm and it closes for one second when the Control Unit cuts the gas or electricity supply. -
Page 16: Troubleshooting
Stove Guard 300 User Manual 10. Troubleshooting • Occasionally, in some cookers that are operated by touch, this procedure will not resolve the problem. In this case, un- plug the cooker from the Control Unit, keeping the Control Unit connected to the electricity outlet. Now carry out the setup procedure described in section 5.1, as for a gas cooker. -
Page 17: Technical Information
11. Technical Information Certification: CE, Casing IP20 Patent FI 117526, FI 117878, PCT pending Unit Connection Power Cut-off time Features SGC500 1-3 phase 240V AC 0,5 - 3 h (Intelligent Timer) Alarm Signal Detection 16 - 32A Intelligent Timer Safety Lock Alarm output Overheating and overload protection... -
Page 18: Warranty
Stove Guard 300 User Manual 12. Warranty This product has a 24-month warranty that covers defects in material or workmanship, starting from the date of purchase. The warranty does not cover any indirect damage caused by a malfunctioning ap- pliance, damage caused by negligence, or damage caused by failure to follow the instructions properly. - Page 20 Stove Guard 300 User Manual Safety for Your Kitchen Innohome Ltd Tel: +358 9 4114 3359 Web: http:// www.innohome.com Email: info@innohome.com Metsänpojankuja 3 02130 Espoo Finland Stove Guard 300 User manual - 10.05.2013...
