- Page 1 DL-AP KIT INSTALLATION GUIDE...
- Page 2 DISCLAIMER: This installation guide is demonstrated based on DL-AP Kit. You may refer to the following instructions if you have a new DL-A in hand with other existing accessories needed in place. Safety Instructions: • To install this product: installer must have basic drilling and wiring skills.
- Page 3 C: Electromagnetic Lock 1 x Door Exit Button • • 1 x Manual Booklet (Device Manual and Kit Installation Guide)
- Page 4 • 1 x USB Flash Drive (software pre-loaded) 5 x Proximity Card • • 1 x 12v AC DC Adapter • 2 x Flat Cable...
- Page 5 • 1 x Installation Pack for Magnetic Lock: o 8 x 1” Mounting Screws (Part #: 1001) o 1 x 1”1/2 Mating Screws (Part #: 1002) o 1 x 1”1/2 Sex Bolt (Part #: 1003) o 2 x Washers (Part #: 1005) o 1 x Hex Key for Mounting Plate (Part #: 1006) o 1 x Hex Key for Armature Plate (Part #: 1007)
- Page 6 o 2 x Armature Pin (Part #: 1008) • 1 x Installation Pack for DL-A: o 3 x 1”Mounting Screws (Part #: 1004) o 1 x Socket Head Screw (Part #: 1009) o 3 x Plastic Anchors (part #: 1010) o 1 x Hex Key for Device Mounting Head Screw (Part #: 1011) o 2 x 3/4”...
- Page 7 door frame. Apply the self-sticking templates at the desired drilling position as shown in the example below. 2. Drill the corresponding holes into the head of the frame and door according to the drilling templates applied in step 1. BEFORE YOU START DRILLING, watch your drilling depth! The above red arrows indicate that maximum drilling depths for the two points are 1/2 inches on the armature drilling template.
- Page 8 3. Drill a 7/8” x 2 5/8” hole on the wall outside of the door where DL-A terminal is to be mounted. 4. Drill a 2/3 inch diameter hole on the wall inside of the door where the "open door" button is to be mounted.
- Page 9 5. Prepare wires for the below: a) from the electromagnetic lock to DL-A terminal; b) from DL-A terminal to “open door” button; c) from DL-A terminal to router/switch, server or computer (if necessary); d) from 12v adapter to DL-A terminal. Note: Do NOT plug in the power adapter until the installation is complete.
- Page 10 6. Start wiring. Please refer to the following sample diagram for single door installation:...
- Page 11 7. Remove the mounting plate (refer to B under electromagnetic lock in content list) from the electromagnetic lock (refer to C under electromagnetic lock in content list). 8. Screw the mounting plate (refer to B under electromagnetic lock in content list) into appropriate holes on the door frame using six (6) 1”...
- Page 13 9. Install DL-A mounting plate (on the back of the terminal) onto the wall according to the drilled location in step 3 using three (3) 1”Mounting Screws (Part #: 1004) provided in Installation Pack B. Also, install the "open door" button plate onto the wall inside of the door according to drilled location in step 4 using two (2) 3/4”...
- Page 14 Lock DL-A onto its mounting plate using the hex key (Part #: 1011 in Installation Pack B). Lock the "open door" button onto the wall using the Socket Head Screw (Part #: 1009 in Installation Pack B). Plug the 12v power adapter provided into the outlet to power the DL-A terminal. The system is now ready to be used.
