Summary of Contents for Viavi GS-2P40-576T
- Page 1 GS-2P40-576T Hardware Installation 7 Apr 2020...
- Page 2 1. If applicable, mounted weight includes any rail kits. 2. SFP may be any of Copper 10/100/1000, 1Gb SX/LX. SFP+ may be any of 10Gb SR/LR. QSPF+ may be any 40Gb SR/LR/BiDi/Universal. 2 — © 2020 Viavi Solutions (7 Apr 2020)
- Page 3 Quick start for experienced installers First time installers should use the information on the next page. 3 — Quick start for experienced installers...
- Page 4 Link A port on the TAP. Connect the TX port from your other switch to the Link B port on the TAP. 1. SFP, SFP+, QSFP+, and QSFP28 transceivers are sold separately. 4 — © 2020 Viavi Solutions (7 Apr 2020)
- Page 5 Installing the drives in your Observer Platform appliance Failure to install the drives in the proper location will result in poor read and How to handle hard drives properly write performance until the RAID array volume is rebuilt. Be especially careful when handling and installing the hard drives. Proper Follow these instructions to install the drives correctly before starting the handling is paramount to the longevity of the drive.
- Page 6 You interact with the hardware appliance through the Apex UI. Navigate to https://hostname where hostname is the IP address or DNS name for the appliance. Log into the interface using the username admin and default password admin. 6 — © 2020 Viavi Solutions (7 Apr 2020)
- Page 7 Configuring the LOM or IPMI port Your appliance comes with an on-board LOM or IPMI port that provides you a dedicated management channel for device maintenance. It allows you to monitor, start, stop, and manage your appliance remotely regardless of whether the appliance is powered on.
- Page 8 If there are still errors, then it is likely that the operating system drive is corrupted. Continue. Is the operating system drive corrupted? Follow the instructions in perform a factory reset. 8 — © 2020 Viavi Solutions (7 Apr 2020)
