- Page 1 STATIC SOLO ANCHOR User Manual Instructions for fitting and use...
- Page 2 If you have any questions about your equipment, please contact us. Once again, thank you for placing your confidence in our products! Safe vehicle adaptation solutions For your safety BraunAbility products are designed and tested according to current directives and standards.
- Page 3 Safety information General guidance Installation planning Fit and use Fitting the static floor anchorage After care Equipment storage and maintenance Warranty “Declaration of conformity” at the end of the manual.
-
Page 4: Safety Information
• The installer is responsible for ensuring that the fitting meets all applicable regulations. If in doubt about the method of installation or use please contact BraunAbility. • Ensure that the wheelchair is correctly maintained and that the settings of any adjustable parts are made according to ‘Instructions for Use in Transport’. - Page 5 Plastic Bolt Cap M10 x 60 ISO Grade 12.9 Socket Head Cap Screw Solo Anchor 50mm Diameter Under Floor Spreader Plate M10 Nyloc Nut...
-
Page 6: Installation Planning
Safety Information Installation planning • Position the wheelchair facing forward - centrally in the designated region of the vehicle. • To minimise the potential for head injuries in an impact, allow a clear space of at least 400mm behind and 650mm, (FCZ, front clear zone), in front of the head of the wheelchair user (Fig 1). - Page 7 Figure 1 Figure 2...
- Page 8 Fit and use Fitting the static floor anchorage Mark out the chosen floor anchor positions. Drill an 11mm diameter hole through the finished floor, ply and steel flooring. From the top surface of the floor, counter bore the 11mm dia. hole to a diameter of 35mm and a depth of 13mm.
- Page 9 Floor decking or carpet Vehicle floor Figure 4 Figure 3...
-
Page 10: Warranty
BraunAbility have also participated in test programs with other manufacturers anchorage products and will support warranty on the BraunAbility products when used in conjunction with such jointly tested systems. For further details on specific applications please contact the Sales Office. In other situations, using BraunAbility products, for which BraunAbility has not participated in a joint test program, a limited BraunAbility warranty will apply. -
Page 11: Declaration Of Conformity
Accredited by URS as testing laboratory in accordance with ISO/IEC 17025:2005 Quality system certified in accordance with ISO 9001:2008 Illustrations, descriptions and specifications in the user manual are based on current product information. BraunAbility UK Ltd reserves the right to make alterations without previous notice. © 2019 BraunAbility UK Ltd... - Page 12 BraunAbility UK Ltd BraunAbility UK Ltd Unwin House Unwin House Phone: +44 1935 827 740 Phone: +44 1935 827 740 The Horseshoe, Coat Road The Horseshoe, Coat Road E-mail: info@braunability.eu E-mail: info@braunability.eu Martock, Somerset, TA12 6EY Martock, Somerset, TA12 6EY www.braunability.eu...
