- Page 1 Rails User Manual Instructions for fitting and use...
- Page 2 If you have any questions about your equipment, please contact us. Once again, thank you for placing your confidence in our products! Safe vehicle adaptation solutions For your safety BraunAbility products are designed and tested according to current directives and standards.
- Page 3 Rails Safety information Limitations of use Fit and use Fitting Low Profile Rail Fitting Surface Rail Fitting Low Profile & Surface Rails -Importance Notice Fitting Heavy Duty Rail Rail Accessories After care Equipment storage and maintenance Warranty “Declaration of conformity” at the end of the manual.
-
Page 4: Safety Information
Rails Safety information Limitation of use LOW PROFILE RAIL SURFACE RAIL HEAVY DUTY RAIL... - Page 5 Rails Fit and use Fitting Low Profile Rail Standard low profile rail is produced in a 3.66 metre lengths. There are 145 x 20 mm “scallops” in the top face and the base has 37 x M8 countersunk holes at 101.6 mm pitch for the fasteners.
- Page 6 All fasteners must be torque loaded to 11 Nm (8 foot pounds). Specific end caps are available for surface rail. Recess in rail should be kept clear of debris to allow equipment to fit and move freely along the rails.
- Page 7 It is critical that the installed rail is flat along its length and correctly positioned relative to any other rail lengths fitted in the vehicle floor. Elements within a pattern of rails must also be parallel to one another. This is particularly important if fitting Unwin “Fixed Base Equipment” or manufacturing removable seats, to ensure they will fit universally along the rails.
- Page 8 Bolts:- M8 steel, hexagon headed grade 8.8, plated, guide length 40 - 50 mm. Nuts:- M8 steel, nyloc, grade 8, plated. Washers:- M8 steel, plain, plated. Torque settings:- 20 nm (15 lbs/ft). Under Floor Reinforcement Contact BraunAbility for specific recommendations.
- Page 9 Rails Fit and use Accessories M8 Fasteners M8 Underfloor End Caps Rail Jib Rail Trim Rail Insert Spreader Plate (RF10 sets of 10, (RJ) (LPEC, RECLY,RECLG, (RT04, RT25) (INS) RF100 set of 100) SEC, RECSY, RECSG) (USP) The standard fixing...
-
Page 10: Equipment Storage And Maintenance
• If you intend to use a proprietary cleaner on or near the rails, advice should be sought from its manufacturer to ensure it does not degrade the appearance and strength of the rail sections. -
Page 11: Declaration Of Conformity
Accredited by URS as testing laboratory in accordance with ISO/IEC 17025:2005 Quality system certified in accordance with ISO 9001:2008 Illustrations, descriptions and specifications in the user manual are based on current product information. BraunAbility UK Ltd reserves the right to make alterations without previous notice. © 2019 BraunAbility UK Ltd... - Page 12 BraunAbility UK Ltd Unwin House Phone: +44 1935 827 740 The Horseshoe, Coat Road E-mail: info@braunability.eu Martock, Somerset, TA12 6EY www.braunability.eu UK ..
