- Page 1 OFFSET UMBRELLA TABLE - WICKER 08808305-0 8-48681-03666-2...
-
Page 2: Table Of Contents
Thank you for your purchase Thank you for your purchase! We are pleased that you have chosen Sears for your outdoor furniture purchase. We hope that you enjoy the unmatched quality, comfort, and style of your new patio set. Every piece is meticulously considered all the way down to the smallest details, exclusively for you, by our world class design team. -
Page 3: Safety Information
Safety Information Furniture Set Up Ensure that all parts are assembled properly and fully tightened as per the instructions. When placing in the desired location, ensure that all legs are resting on the same surface. You may adjust the legs levelers as required to ensure that the item stands in a rigid position. -
Page 4: Care And Maintenance
Warranty Frames are warranted to be free from defects in material or workmanship for a period of one (1) year. Exclusions: items used for commercial, contract, or other non- residential purposes, or items damaged due to acts of Nature, vandalism, misuse, or improper assembly is not covered. -
Page 5: Pre-Assembly
Pre-Assembly PLANING ASSEMBLY To prevent damage, place all parts on a soft surface during assembly. Remove all protective caps before beginning assembly. It takes about 60 minutes for two person to complete all the assembly. WEIGHT LIMIT The recommended weight limit for the following product is listed below: Side Table: 200 lbs CAUTION Furniture overload may... -
Page 6: Package Contents
Pre-Assembly (continued) Package Contents PART QUANTITY DESCRIPTION POLY WOOD TABLE TOP RIGHT SIDE PANEL LEFT SIDE PANEL LARGE SIDE PANEL Safety Information 1. EVERY SCREW NEEDS TO BE USED WITH A WASHER. 2. DO NOT FULLY TIGHTEN SCREW UNTIL INDICATED IN STEP 3. -
Page 7: Assembly Instruction
Assembly Instruction Attaching the large side panel and the left panel to the poly wood table top ATTACH THE LARGE SIDE PANEL “D” TO THE POLY WOOD TABLE TOP “A”. FASTEN WITH SCREW “AA” AND WASHER “BB”. TIGHTEN HALF WAY USING THE ALLEN WRENCH “CC”. - Page 8 Assembly Instruction (continued) Attaching the right side panel and the left side panel to the table top and to the large side panel ATTACH THE RIGHT SIDE PANEL “B” AND LEFT SIDE PANEL TO TABLE TOP “A” AND LARGE SIDE PANEL “B”. FASTEN WITH SCREW “AA” AND WASHER “BB”. TIGHTEN HALF WAY USING THE ALLEN WRENCH “CC”.
- Page 9 Assembly Instruction (continued) Tightening all the screws and locking the two parts of the table CHECK AND MAKE ADJUSTMENTS AS NEEDED. USING THE ALLEN WRENCH “CC” FULLY TIGHTEN ALL THE SCREWS. REPEAT ABOVE STEPS 1 AND 2 FOR THE OTHER HALF OF THE TABLE. AS SHOWN BELOW, USE LOCKING MECHANISM TO LOCK THE TWO PARTS.
-
Page 10: Customer Service
Customer Service YOTRIO CORPORATION 1100 Coiner Ct., City of Industry, CA 91748 1-626-269-6399 1-866-905-4107 SEVICE HOURS: MONDAY-FRIDAY 8:30 AM TO 5:00 PM PST / 11:30 AM TO 8:00PM EST E-MAIL: customerservice@yotrious.com... - Page 11 Email: customerservice@yotrious.com or Call toll-free: 1-866-905-4107 Made in CHINA / Hecho en CHINA...
