- Page 1 MANUFACTURING LLC Please Read This Manual Carefully Before Using This Product 360SLT2 SMARTLINK TPMS TABLET USER MANUAL...
-
Page 2: Table Of Contents
3.4. APP SETTINGS ..........................12 3.5. YARDCHECK360 WEB PORTAL ....................12 FAQS AND TIPS..........................14 SPECIFICATIONS ..........................15 CERTIFICATIONS ..........................16 LIMITED WARRANTY ........................16 Doran Mfg. LLC – 2851 Massachusetts Ave – Cincinnati, OH 45225 – 866-816-7233 – Doranmfg.com... -
Page 3: Introduction
• Power Adapter • USB OTG Adapter • Quick Reference Guide • Operation Manual (On the tablet as an e-copy or downloaded from Doranmfg.com) 1.2. TABLET COMPONENTS Doran Mfg. LLC – 2851 Massachusetts Ave – Cincinnati, OH 45225 – 866-816-7233 – Doranmfg.com... -
Page 4: Initial Power Up
The device can be connected to a computer with a USB-C cable to transfer stored data. To connect the tablet and computer, insert the USB-C cable into the tablet and the USB end to the computer. Doran Mfg. LLC – 2851 Massachusetts Ave – Cincinnati, OH 45225 – 866-816-7233 – Doranmfg.com... - Page 5 The tablet will now be accessible on the computer it is connected to. The folder named Doran TPMS Data will have all exported data. Doran Mfg. LLC – 2851 Massachusetts Ave – Cincinnati, OH 45225 – 866-816-7233 – Doranmfg.com...
-
Page 6: Functions And Applications
(In order to have reliable communication, the tablet should be less than 35ft (10m) away from the transceivers) Doran Mfg. LLC – 2851 Massachusetts Ave – Cincinnati, OH 45225 – 866-816-7233 – Doranmfg.com... - Page 7 After confirming the ID and alarm levels are correct, the data can be sent to the transceiver and saved by pressing the “SEND DATA TO TRANSCEIVER” button. Doran Mfg. LLC – 2851 Massachusetts Ave – Cincinnati, OH 45225 – 866-816-7233 – Doranmfg.com...
-
Page 8: Read Tire Sensor Data
3.2. READ TIRE SENSOR DATA After clicking the Read Tire Sensor Data on the home screen, the user is presented with three different options. Doran Mfg. LLC – 2851 Massachusetts Ave – Cincinnati, OH 45225 – 866-816-7233 – Doranmfg.com... -
Page 9: Read One-Click Transceivers
ID, tread depth, and photos. After information is added, simply press “CONFIRM” and then the Save button to save the data to the tablet. Doran Mfg. LLC – 2851 Massachusetts Ave – Cincinnati, OH 45225 – 866-816-7233 – Doranmfg.com... -
Page 10: Read Individual Tire Sensor
Using the + and – buttons, the user can add or subtract axels to match the configuration of the vehicle. Doran Mfg. LLC – 2851 Massachusetts Ave – Cincinnati, OH 45225 – 866-816-7233 – Doranmfg.com... -
Page 11: Saved Files
A red tire indicates an alarm condition has been recorded. A blue dot indicates that all tires on the asset are at correct pressures and temperatures. Pressing the Export button will save all of the data to a file located in the Doran TPMS Data folder of the tablet. -
Page 12: App Settings
If YardCheck360 hardware is being used, the YardCheck360 web portal can be accessed by the tablet. Please visit http://doranmfg.com/yardcheck-360-wireless-gate-reader- tire-pressure-monitoring-system/ for more details regarding the YardCheck360 product line. Doran Mfg. LLC – 2851 Massachusetts Ave – Cincinnati, OH 45225 – 866-816-7233 – Doranmfg.com... - Page 13 360SLT2 SMARTLINK TPMS Tablet User Manual (v1) Doran Mfg. LLC – 2851 Massachusetts Ave – Cincinnati, OH 45225 – 866-816-7233 – Doranmfg.com...
-
Page 14: Faqs And Tips
Only LFA sensors can be read by the tablet, verify the sensor has the LFA marking on it. Why doesn’t my tablet turn on? Press and hold the power button for a few seconds until the Doran logo appears on a white screen. If the tablet does not power on, check if the battery needs charged. -
Page 15: Specifications
Power consumption <8W Working Temperature 0~55 ℃ Storage Temperature -20~60 ℃ Dimensions 250Lx130Wx23H mm Weight 0.56 kg USB (Type C) Connection USB (OTG) Micro SD card Doran Mfg. LLC – 2851 Massachusetts Ave – Cincinnati, OH 45225 – 866-816-7233 – Doranmfg.com... -
Page 16: Certifications
The exposure standard for wireless transmitter employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the IC is 1.6W/kg. rted to the IC when on the body, as described in this user guide, is The highest SAR value for the EUT as repo 0,17W/kg. Doran Mfg. LLC – 2851 Massachusetts Ave – Cincinnati, OH 45225 – 866-816-7233 – Doranmfg.com... -
Page 17: Limited Warranty
The exclusive remedy for any product determined by DORAN MFG. LLC to be defective within such period shall, at the sole option of DORAN MFG. LLC, be the or the refund o... - Page 18 DORAN 360SLT. There are no expressed or implied warranties beyond those expressly stated above. No employee, agent, dealer or other Person is authorized to give any warranties on behalf of DORAN MFG. LLC, except as authorized in writing.
- Page 19 360SLT2 SMARTLINK TPMS Tablet User Manual (v1) DORAN MANUFACTURING CO. LLC 2851 Massachusetts Avenue Cincinnati, OH 45225 Tel: 866-816-7233 Fax: 513-681-5604 Website: www.Doranmfg.com Doran Mfg. LLC – 2851 Massachusetts Ave – Cincinnati, OH 45225 – 866-816-7233 – Doranmfg.com...
