Page 1: User Manual
MANUFACTURING LLC Please read this manual carefully before using this product. 360SLT SMARTLINK TPMS TABLET USER MANUAL... -
Page 2: Table Of Contents
INDEX INTRODUCTION ......................1 PACKAGE AND ACCESSORIES ....................... 1 START TO USE ..........................2 CONNECT TO THE COMPUTER ..................... 3 FUNCTIONS AND APPLICATIONS ..................4 INTRODUCTION ........................... 4 OPERATION ..........................5 2.1 READ SENSOR (TIRE) DATA ....................5 2.2 PROGRAMMING ......................10 2.3 ACCESS SAVED FILE ....................... -
Page 3: Introduction
Quick reference guide Operation manual (included in the tablet with e-copy or can be downloaded from www.doranmfg.com for latest version) Tablet Description Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com... -
Page 4: Start To Use
The tablet can setup the scheduled ON or OFF time by following the device system setting menu: SETTINGS/Scheduled power on & off. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com... -
Page 5: Connect To The Computer
The below screen will open up once the connection is completed successfully. Press “Turn on the USB storage” to enable the tablet to be a USB disk of the computer. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com... -
Page 6: Functions And Applications
FUNCTIONS AND APPLICATIONS 1. INTRODUCTION DORAN 360SLT SMARTLINK™ TPMS TABLET is an all-in-one tool that can be used for all the DORAN TPMS products. To enable the user to follow each application easily and clearly, the tool is designed by the principle of application scenario. Customers can select the right application by clicking the sub-menu in the main menu list. -
Page 7: Operation
Current tire pressure • Current tire temperature To read an individual sensor, click the menu “INDIVIDUAL SENSORS” to access the screen shown on the next page. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com... - Page 8 WALK AROUND enables a customer to access the tire data of a truck, trailer, or other equipment with a Doran TPMS sensor that has LF capability by walking around the vehicle. The data received from the sensor will be recorded and can be saved in the accordant wheel position.
- Page 9 Repeat the above operation for all the sensors (tires) and retrieve tire information. Before selecting SAVE, enter the TRUCK# which will be used as the default file name in the data folder. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com...
- Page 10 ID or trailer/unit number. This helps access a specific transceiver if there is more than one transceiver available. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com...
- Page 11 Pressing the wheel image will open a window that shows more detailed information and gives the option to input the tire serial number, tire position ID, and tread depth. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com...
-
Page 12: Programming
STEP1: Read and select the transceiver to be programmed Press READ button to open a window that shows all available transceivers with ID and trailer number. Select the one to be programmed. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com... - Page 13 Low Pressure Level 1 – The default value is set to 12.5% below baseline pressure (blue number in the square shows the current alarm level pressure). It can be changed by manually entering the pressure value. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com...
- Page 14 STEP3: Transfer data to the transceiver Press TRANSFER TO TRANSCEIVER to complete the programming by successfully transferring the data. The transceiver is now configured to function correctly. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com...
-
Page 15: Access Saved File
(usually it is the truck or trailer #). Select the file to open and it will show the data stored. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com... - Page 16 The screen will show the truck #, date, and time saved and all the tire positions with tire pressure and temperature information. Pressing the tire will open a window displaying detailed information as shown below. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com...
-
Page 17: Settings
On this screen, customers can select the units of measure including temperature, pressure, and tread depth. Temperature unit Select Fahrenheit or Celsius Pressure unit Select KPA, PSI or Bar Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com... -
Page 18: Set Passcode
Once the passcode is set, when starting the tablet, it will require the passcode before the main menu can be accessed. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com... -
Page 19: Version
（WIFI connection to the Internet is required） Choose CONFIRM to upgrade immediately or CANCEL to upgrade later. After pressing CONFIRM, it will start to download the latest version of software. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com... -
Page 20: Transfer Data To Computer
Step 1: Connect tablet to PC (Refer to part 3 of INTRODUCTION) Step2: Find the folder named “SMARTLINK TPMS TABLET” in the file system. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com... -
Page 21: Faq And Tips
But if the data is from an individual sensor or read by WALK AROUND, the tire status is not able to be determined and displayed. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com... -
Page 22: Tips
Internet through WIFI connection. You can also manually set the date and time in Android system settings. What should I do if can’t remember the passcode ? If you forget the passcode to enter the menu, please call Doran customer service: 1-866-816-7233 (toll free) for support. 2. TIPS WIFI Connection: As a smart tablet, the device is allowed to connect to a secure WIFI for data communication and system upgrade. -
Page 23: Certificates
The exclusive remedy for any product determined by DORAN MFG. LLC to be defective within such period shall, at the sole option of DORAN MFG. LLC, be the repair or replacement of such defective product, or the refund of the purchase price therefore. - Page 24 Warranty, and the exclusive venue for any dispute in connection with the purchase or use of the product shall be the state and federal courts of general jurisdiction located in Hamilton County, Ohio U.S.A. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com...
- Page 25 Limited Warranty may not apply to you; (3) This Limited Warranty gives you specific legal rights and you may have other rights that vary from state to state. Doran Mfg. LLC • 2851 Massachusetts Ave • Cincinnati, OH 45225 • 866-816-7233 • Doranmfg.com...
- Page 26 DORAN MANUFACTURING CO. LLC 2851 Massachusetts Avenue Cincinnati, OH 45225 Tel: 866-816-7233 Fax: 513-681-5604 Website: www.doranmfg.com #3675-SLT DORAN #360SLT USER MANUAL VERSION 1.01...
