- Page 1 Freeplay FHRM Fetal Doppler/Monitor Operating Manual Issue 1.08...
-
Page 2: Table Of Contents
Electromagnetic Compatibility Tables 12.5.1 Manufacturers Declaration and Guidance : Emissions 12.5.2 Manufacturers Declaration and Guidance : Immunity 12.5.3 Manufacturers Declaration and Guidance : Separation Distances 13. WARRANTY 13.1 Terms and Conditions NOTES Freeplay FHRM Operating Instructions Copyright © UTL. 2018... -
Page 3: About This Manual
1. ABOUT THIS MANUAL This user manual provides instructions for the operation of the Freeplay FHRM Fetal Doppler/Monitor, hereafter refered to generically as the FHRM. It is recommended that personnel study this manual before attempting to operate the FHRM Fetal Doppler. The safe and effective use of this equipment requires understanding of, and compliance with, all warnings, cautionary notices, and instructions marked on the product, and included in this manual. -
Page 4: About The Fhrm
It should not be used for any other application or patient examination procedure. If its use is in doubt, contact your local distributor or authorised Freeplay Representative directly. Accessories The following accessories are supplied with every FHRM series Doppler: AC Mains Adapter Operating Manual Freeplay FHRM Operating Instructions Copyright © UTL. 2018... -
Page 5: Ac Mains Adaptor
Ensure that the plug head clips into place and is securely attached before use. WARNING: The device must only be used with the supplied power supply unit. Freeplay FHRM Operating Instructions Copyright © UTL. 2018... -
Page 6: Safety
It is recommended that exposure to ultrasound should be kept As Low As Reasonably Acheivable (ALARA guidelines). Avoid unnecessary prolonged exposure. This is considered to be good practice and should be observed at all times. Freeplay FHRM Operating Instructions Copyright © UTL. 2018... -
Page 7: Labelling
Fetal Pulse Indicator Product Manufacturer. Direct Current Connector Polarity (Tip Positive) Product Serial Number The product serial number can be found on the rear label of the product, beneath the winding handle. Freeplay FHRM Operating Instructions Copyright © UTL. 2018... -
Page 8: Controls And Indicators
5. CONTROLS AND INDICATORS DC Input Socket (C) Fetal Heart Rate Display (D) Fetal Pulse Battery Low Icon (B) Indicator (E) Unit On / Off Control (A) 2MHz Fetal Probe (F) Freeplay FHRM Operating Instructions Copyright © UTL. 2018... - Page 9 On the rear of the unit there is the charging handle and a green LED that indicates when the unit is charging. The fetal probe (F) is permanently attached to the unit and no attempt must be made to disconnect it. Freeplay FHRM Operating Instructions Copyright © UTL. 2018...
-
Page 10: Charging The Fhrm
The longer and faster you wind the longer the fetal monitor will function without the need for further winding. You can store wind-up power by winding for any length of time. All power created by winding is stored in the batteries. Freeplay FHRM Operating Instructions Copyright © UTL. 2018... -
Page 11: Operating Procedure
The power source must be disconnected from the monitor before it can be used. You will not be able to switch the monitor on if it is still attached to the power. Freeplay FHRM Operating Instructions Copyright © UTL. 2018... -
Page 12: Fetal Heart Detection
There is no distinct beat pattern to the sound. The vessels of the umbilical cord give rise to a higher pitched sound than the normal fetal heart, with pulsations at the fetal rate. Freeplay FHRM Operating Instructions Copyright © UTL. 2018... -
Page 13: Frequently Asked Questions
A self-learning programme for professionals on fetal heart rate monitoring during intrapartum care can be accessed free on: http://bettercare.co.za/learning-programmes/intrapartum-care/ Freeplay FHRM Operating Instructions Copyright © UTL. 2018... -
Page 14: Preventative Maintenance
• The probe face is very delicate and may be damaged by dropping. Always store the unit carefully and protect the probe. • Regularly inspect the unit for damage. Pay particular attention to the probe and probe cable. • Refer damaged units to your local distributor or authorised Freeplay Representative as soon as any damage is identified. Milton is a solution of 2% Sodium Hypochlorite. Freeplay FHRM Operating Instructions Copyright © UTL. 2018... -
Page 15: Troubleshooting
NOTE: Be ready to provide the model, serial number and the nature of the problem. The serial number can be found on the rear of the unit beneath the charging handle. There are no user serviceable parts inside the FHRM. Freeplay FHRM Operating Instructions Copyright © UTL. 2018... -
Page 16: Equipment Specification
Relative Humidity 30 – 70% non-condensing. Ambient Pressure 700 kPa to 1060 kPa. Transit and Storage Ambient Temperature -40°C to +70°C. Relative Humidity 10% to 100%, including condensation. Ambient Pressure 500kPa to 1060kPa. Freeplay FHRM Operating Instructions Copyright © UTL. 2018... -
Page 17: Ultrasound Output Specification
Harmonic Emissions Not Applicable and those directly connected to the public IEC 61000-3-4 low-voltage power supply network that supplies Voltage Fluctuations / Not Applicable buildings used for domestic purposes. Flicker Emissions IEC61000-3-3 Freeplay FHRM Operating Instructions Copyright © UTL. 2018... -
Page 18: Manufacturers Declaration And Guidance : Immunity
FHRM device should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting or relocating the device. b. Over the frequency range 150kHz to 80MHz, field strengths should be less than 3 V/m. Freeplay FHRM Operating Instructions Copyright © UTL. 2018... -
Page 19: Manufacturers Declaration And Guidance : Separation Distances
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects, and/or people. This equipment complies with the essential requirements of the European Council Directive 93/42/EEC + 2007/47/EC relating to Medical Devices. Freeplay FHRM Operating Instructions Copyright © UTL. 2018... -
Page 20: Warranty
Terms and Conditions 1. The Warranty Ultrasound Technologies Ltd. warrants the product, when new, to be free of defects in material and workmanship and to perform in accordance with the manufacturer’s specification for a minimum period of three years from the date of purchase from Ultrasound Technologies Ltd. - Page 21 8. Commencement of Warranty Period The purchase date determines the period of the warranty. 9. Limitation of Warranty No other express or implied warranty is given. Ultrasound Technologies Ltd. will under no circumstances be liable for loss from any indirect or consequential damage.
- Page 22 Ultrasound Technologies Ltd., with all transport and importation costs paid, and where a replacement product is being supplied by Ultrasound Technologies Ltd. Where a replacement product is not being supplied, recycling services may be provided on request at additional cost.
-
Page 23: Notes
NOTES Freeplay FHRM Operating Instructions Copyright © UTL. 2018... - Page 24 +44 (0) 1291 427093 e-mail service@doppler.co.uk Printed in United Kingdom Ultrasound Technologies Ltd. reserves the right to modify this product specification without prior notice. Note that some options and functionalities might not be available on product release. Please confirm availability with our representative.
