D. Control interface
There are five buttons and four LED indicators on the faceplate. Each LED indicates the activation
status or mode of operation of the unit.
1. To select Voltage, Current or Time
2. To switch blue light ON or OFF
3. Increase select
4. Decrease select
5. Start / stop the program
a. Setup Mode (before pressing RUN/Start)
Each LED light indicates each activated parameter. For example, the Voltage LED will be activated
when selecting the desired voltage. Use
Use or to adjust the value to the desired setting.
b. Operation Mode
Press to start electrophoresis. The LED light next to the Start/Stop button will light up to
indicate the unit is in operation. Use
voltage.
c. Blue light
There are two modes of blue light illumination for visualisation of nucleic acid bands during
electrophoresis.
1. Press the once to activate the blue light source for 10 seconds, to monitor the extent of
band migration.
2. Press the button for 3 seconds for continuous blue light illumination and real-time
visualisation of band migration.
to alternatebetween Voltage, Current and Time.
to monitor the remaining time and changes in current and
