- Page 1 Technical Information Manual Revision n. 1 27 September 2002 MOD. V560 series 16 CHANNEL SCALERS...
- Page 2 User. It is strongly recommended to read thoroughly the CAEN User's Manual before any kind of operation. CAEN reserves the right to change partially or entirely the contents of this Manual at any time and without giving any notice.
-
Page 3: Table Of Contents
27/09/2002 V560 User Manual TABLE OF CONTENTS TABLE OF CONTENTS ....................3 DESCRIPTION ....................... 4 1.1. FUNCTIONAL DESCRIPTION................4 SPECIFICATIONS......................6 2.1. PACKAGING ..................... 6 2.2. EXTERNAL COMPONENTS................6 2.3. INTERNAL COMPONENTS ................7 2.4. POWER REQUIREMENTS ................7 2.5. CHARACTERISTICS OF THE SIGNALS............ -
Page 4: Description
27/09/2002 V560 User Manual 1. DESCRIPTION 1.1. FUNCTIONAL DESCRIPTION The model V560 is a 1-unit wide VME module provided with 16 independent 32-bit counting channels operating at the guaranteed input frequency of 100 MHz. The channels are grouped in 8 section of two channels; for each section it is possible: •... - Page 5 27/09/2002 V560 User Manual IDENTIFIER MAN CLR Clear scales VME VETO CLEAR Increase scales INTERFACE rd counter 2n rd counter 2n+1 VETO SCALE STATUS TEST REQUEST REG. Enable n clock inhibit clear COUNTER 2n Req n INPUT 2n clock inhibit INPUT 2n+1 clear COUNTER 2n+1...
-
Page 6: Specifications
27/09/2002 V560 User Manual 2. SPECIFICATIONS 2.1. PACKAGING 1-unit wide VME unit. Height: 6U. 2.2. EXTERNAL COMPONENTS CONNECTORS - No.2, "IN 0..7", "IN 8..15", 16 pin lead flat cable connector, 110Ω impedance; for the 16 input channels. - No.2, "TEST", LEMO 00 type, 50Ω impedance; two bridge connectors (for daisy chaining) for the TEST input signal. -
Page 7: Internal Components
27/09/2002 V560 User Manual 2.3. INTERNAL COMPONENTS (refer to fig.2.2 and Appendix C - components location) JUMPERS - No.1, jumper "JP2"; for the -5 V power selection. SWITCHES - No.8, changeover switches (group "JP3..JP10"). For connect the two channels of each section to obtain a single 64 bit scale. - Page 8 27/09/2002 V560 User Manual Mod. V560E Mod. V560E Inputs 8..15 TEST input VME selected LED VETO input Inputs 0..7 CLEAR input Manual Clear pushbutton 16 CH SCALER 16 CH SCALER Fig. 2.1: Mod. V560 Front panel...
- Page 9 27/09/2002 V560 User Manual VME P1 connector JP8:sect. 7 JP10:sect. 6 Rotary switches for Base address selection JP9:sect. 5 Paux connector JP7:sect. 4 for CERN VMEbus crate type V430 JP4:sect. 3 JP6:sect. 2 JP5:sect. 1 POWER SELECTION JP3:sect. 0 VME P2 connector Component side of the board Fig.
-
Page 10: Operating Modes
27/09/2002 V560 User Manual 3. OPERATING MODES 3.1. COUNTING SCALES The module V560 houses 16 independent 32-bit channels that are grouped in 8 sections of two channels. For each section the two channels can be cascaded by internal changeover switches in order to obtain a single 64-bit scale. -
Page 11: Interrupt Generation
27/09/2002 V560 User Manual JP8:sect. 7 JP10:sect. 6 JP9:sect. 5 JP7:sect. 4 JP4:sect. 3 JP6:sect. 2 JP5:sect. 1 JP3:sect. 0 Component side of the board Section n single 64 bit scale configuration Section n two 32 bit scales configuration Fig. 3.1: Mod. V560 jumper settings Section 64-bit scale External Input... -
Page 12: Front Panel Signals
27/09/2002 V560 User Manual The operations of the V560 VME INTERRUPTER are fully software programmable; via VME it is possible: • to enable /disable the VME interrupt generation; • to set the VME interrupt level; • to program the VME interrupt vector (STATUS/ID). Moreover for each section it is possible to enable/disable the scales interrupt generation (see §... -
Page 13: Scale Inhibit
27/09/2002 V560 User Manual 3.4. SCALE INHIBIT It is possible to inhibit the scales count in this way: • by sending a NIM signal through one of the two "VETO" connectors located on the front panel. • by setting the VME VETO (access to the address Base +%52; see § 4.6). The VME VETO is cleared: •... -
Page 14: Module Configuration
27/09/2002 V560 User Manual 3.7. MODULE CONFIGURATION The module is supplied by CAEN with the internal jumpers as shown in Figure 2.2. In this arrangement each section is configured with two independent 32bit counting scales At power-on: • all the scales are cleared;... - Page 15 27/09/2002 V560 User Manual Component side of the board JP2 (POWER SELECTION) settings: (-5 INT) VMEbus crate type V430 position (-5 EXT) Standard crates position (-5 INT) (-5 EXT) Fig. 3.1: Mod. V560 JP2 settings...
-
Page 16: Vme Interface
27/09/2002 V560 User Manual 4. VME INTERFACE 4.1. ADDRESSING CAPABILITY The module works in A32/A24 mode. This means that the module address must be specified in a field of 32 or 24 bits. The Address Modifiers code recognized by the module are: AM=%39: standard user data access AM=%3D:... - Page 17 27/09/2002 V560 User Manual Base address bit <11..8> Base address bit <15..12> Base address bit <19..16> Base address bit <23..20> Base address bit <27..24> Base address bit <31..28> Fig. 4.1: Mod. V560 Base address setting.
- Page 18 27/09/2002 V560 User Manual Table 4.1: Address Map for the Mod. V 560 ADDRESS REGISTER/CONTENT TYPE Base + %FE Version & Series read only Base + %FC Manufacturer & Module Type read only Base + %FA Fixed code read only Base + %5A...Base + %F8 Not used Base + %58...
-
Page 19: Module Identifier Words
27/09/2002 V560 User Manual 4.3. MODULE IDENTIFIER WORDS (Base address + %FA ,+%FC, +%FE read only) The Three words located at the highest address on the page are used to identify the module as shown in figure 4.1: Address Base + % FE V e r s i o n M o d u l e ' s s e r i a l... -
Page 20: Scale Increment
27/09/2002 V560 User Manual Fig. 4.3: Scale Status register 4.5. SCALE INCREMENT (Base address + %56 r/w) If the module is configured with 16 independent channels, a VME access (read or write) to this location increases all the channels (same as the TEST signal). 4.6. -
Page 21: Counters
27/09/2002 V560 User Manual 4.8. COUNTERS (Base address + %10 ... Base address + % 4C read only) There are sixteen 32 bit read only registers. They contain the 32 bit value of the corresponding counting channels These registers can be read in D16/D32 mode. When the D16 mode is used (word cycles), the register content is located on the 16 bit data bus following Motorola standard, i.e., the most significant word is located at the lowest VME address. -
Page 22: Request Register
27/09/2002 V560 User Manual 4.9. REQUEST REGISTER (Base address + %0E r/w) This register allows to control the VME interrupt generation for each section. • Request register<n> =1 section n scales are able to generate a VME interrupt • Request register<n> =0 section n scales are not able to generate a VME interrupt (Bits 8 to 15 are unused and are read as "one"... -
Page 23: Interrupt Level & Veto Register
27/09/2002 V560 User Manual 4.12. INTERRUPT LEVEL & VETO REGISTER (Base address + %06 r/w) This register contains the value of the interrupt level set (bit <0..2>) and the status of the VETO latched during the last read counter operation (bit<8>). Bits <7..3> and bits <15..8> are unused and are read as "one"... -
Page 24: Mod. V560 Interrupter
27/09/2002 V560 User Manual 5. MOD. V560 INTERRUPTER 5.1. INTERRUPTER CAPABILITY The Mod. V560 houses a VME RORA INTERRUPTER D08(o) type. This means that: • it responds to 8 bit, 16 bit and 32 bit interrupt acknowledge cycles providing an 8-bit STATUS/ID on the VME data lines D00..D07;... - Page 25 27/09/2002 V560 User Manual - if the MSB of an enabled scale becomes true and the value of the interrupt level different from 0: - it requests interrupt by driving an interrupt request line IRQ1..7 low according to the LEV<2..0> value; - during the following acknowledge cycle it places on the VME data lines D00..D07 the STATUS/ID;...
-
Page 26: References
27/09/2002 V560 User Manual 6. REFERENCES [1] VMEbus Specification Manual Revision C.1 October 1985 G. Bianchetti et al., Specification for VMEbus CRATE Type V430, CERN-EP, January 1990.
