- Page 1 Technical Information Manual Revision n. 3 4 July 2017 MOD. A3484/A3485 AC/DC CONVERTER 400 V 3-PHASE 48 V 2.5/5 KW MANUAL REV. 3 NPO: 00120/04:A348x.MUTx/03...
- Page 2 User. It is strongly recommended to read thoroughly the CAEN User's Manual before any kind of operation. CAEN reserves the right to change partially or entirely the contents of this Manual at any time and without giving any notice. Disposal of the Product The product must never be dumped in the Municipal Waste.
-
Page 3: Table Of Contents
Document type: Title: Revision date: Revision: User's Manual (MUT) A3484-A3485 AC/DC Converter 400 V 3-phase 48 V 2.5/5kW 04/07/2017 TABLE OF CONTENTS EASY EMBEDDED ASSEMBLY SYSTEM ....................5 ........................5 UNCTIONAL DESCRIPTION CAEN M ............6 ULTICHANNEL OWER UPPLY YSTEM VERVIEW . -
Page 4: List Of Tables
Document type: Title: Revision date: Revision: User's Manual (MUT) A3484-A3485 AC/DC Converter 400 V 3-phase 48 V 2.5/5kW 04/07/2017 LIST OF TABLES 1.1 – T SY 1527 ..............7 ABLE ECHNICAL SPECIFICATIONS OF THE MAINFRAME 2.1 – T A3484 A3485 48 V P ........ -
Page 5: Easy Embedded Assembly System
1. EASY Embedded Assembly System Functional description EASY (Embedded Assembly SYstem) is the new CAEN power supply solution for operation in magnetic field and radioactive environment. CAEN has been involved for more than a decade in developing different solutions for the main LHC experiments, where the electronic equipment of the experiment is dealing with high dose radiation and intense magnetic field. -
Page 6: The Caen Multichannel Power Supply System Overview
The SY1527 system is the fully equipped experiment version of a new line of power supply systems which represent CAEN's latest proposal in the matter of High Voltage and Low Voltage Power Supplying. This system outlines a completely new approach to power... -
Page 7: Table 1.1 - Technical Specifications Of The Sy 1527 Mainframe
Revision date: Revision: User's Manual (MUT) A3484-A3485 AC/DC Converter 400 V 3-phase 48 V 2.5/5kW 04/07/2017 Power Supply Unit and one board. The system allows also to deal with power supply solutions composed by “branch controllers” (housed in the system main frame) and on- detector “remote boards”... -
Page 8: The Mod. A1676A Branch Controller Overview
Title: Revision date: Revision: User's Manual (MUT) A3484-A3485 AC/DC Converter 400 V 3-phase 48 V 2.5/5kW 04/07/2017 The Mod. A1676A Branch Controller overview The Mod. A1676A EASY Branch Controller is implemented in a single width SY1527/SY2527 board. Once plugged in, the Branch Controller must be linked to the EASY crates (placed in the “hostile area”), via front panel connectors (Control and Power... -
Page 9: Mod. A3484 And A3485 Ac/Dc Converters
2. Mod. A3484 and A3485 AC/DC Converters Fig. 2.1 – Mod. A348x Front panel The Mod. A3484 is a 400 Vac – 48 Vdc converter, which allows to integrate into the EASY channels control also the management of the 48 V power supplies. Features include local or remote control (Mod. -
Page 10: Front Panel Components
Document type: Title: Revision date: Revision: User's Manual (MUT) A3484-A3485 AC/DC Converter 400 V 3-phase 48 V 2.5/5kW 04/07/2017 Front panel components 2.1.1 OUTPUT± Fig. 2.2 – OUTPUT± section These sections provide the channels output and includes (for each channel): 2 Hexagonal bolt type connectors: ±48V power... -
Page 11: Easy Bus
Document type: Title: Revision date: Revision: User's Manual (MUT) A3484-A3485 AC/DC Converter 400 V 3-phase 48 V 2.5/5kW 04/07/2017 2 AMP 280372-2 type connector (MONITOR +/-) 1 Trimmer (Vout adjustment) 1 Bistable switch (CHANNEL ON/OFF) 1 green LED (CHANNEL ON) 2.1.3... -
Page 12: Fig . 2.6 - Interlock Diagram
Document type: Title: Revision date: Revision: User's Manual (MUT) A3484-A3485 AC/DC Converter 400 V 3-phase 48 V 2.5/5kW 04/07/2017 330 Ohm ~10 mA Fig. 2.6 – Interlock diagram 2.1.5 48V IN Fig. 2.7 – 48V IN section This section provides the input of 48 V supply for local and remote auxiliary low voltages... -
Page 13: Safety Information And Installation Requirements
Title: Revision date: Revision: User's Manual (MUT) A3484-A3485 AC/DC Converter 400 V 3-phase 48 V 2.5/5kW 04/07/2017 3. Safety information and installation requirements General safety information This section contains the fundamental safety rules for the installation and operation of the boards. -
Page 14: Installation
Document type: Title: Revision date: Revision: User's Manual (MUT) A3484-A3485 AC/DC Converter 400 V 3-phase 48 V 2.5/5kW 04/07/2017 DANGER ATTENTION High Voltage Refer to Manual Installation The Mod. A1676A is a single-width board for the SY1527/2527/3527 systems. At power ON the SY1527 system processor will scan all the slots in the crate to find out where the module is plugged and what kind of module it is. -
Page 15: Operating Modes
Document type: Title: Revision date: Revision: User's Manual (MUT) A3484-A3485 AC/DC Converter 400 V 3-phase 48 V 2.5/5kW 04/07/2017 4. Operating modes The Mod. A3484S/A3485S can be controlled, either locally or remotely, through the SY 1527 software interface. For details on the EASY3000 System, please refer to the User's Manual of the A1676A Branch Controller. -
Page 16: Table 4.2 - Ch1
Document type: Title: Revision date: Revision: User's Manual (MUT) A3484-A3485 AC/DC Converter 400 V 3-phase 48 V 2.5/5kW 04/07/2017 If HVSync = Fail the 625KHz signal is generated by the board itself. StatusIn allows to readout the back panel STATUS IN signal. -
Page 17: Internal Channel Opc Items
Document type: Title: Revision date: Revision: User's Manual (MUT) A3484-A3485 AC/DC Converter 400 V 3-phase 48 V 2.5/5kW 04/07/2017 allows to send the ON/OFF command to the channel. Trip allows to set the Trip time. If the channel Over Current (Imon >= I0set) lasts more than the Trip time, the channel is turned OFF. -
Page 18: Output Channel Opc Items
Title: Revision date: Revision: User's Manual (MUT) A3484-A3485 AC/DC Converter 400 V 3-phase 48 V 2.5/5kW 04/07/2017 A read access to the 12VPwS#CoClose item returns back the label “On” associated to 12VPwS=OK. A read access to the StatusIn item returns the StatusIn connector signal. - Page 19 Revision date: Revision: User's Manual (MUT) A3484-A3485 AC/DC Converter 400 V 3-phase 48 V 2.5/5kW 04/07/2017 A read access to the V0set#HighEU item returns the highest possible V0set value. A read access to the V0set#LowEU item returns the lowest possible V0set value.
-
Page 20: Table 4.5 - Output Channel Items
Revision date: Revision: User's Manual (MUT) A3484-A3485 AC/DC Converter 400 V 3-phase 48 V 2.5/5kW 04/07/2017 A read access to the RemIlk#CoOpen returns back the label “Off” associated to RemIlk A read access to the RemIlk#CoClose returns back the label “On” associated to RemIlk The IntFail item returns back the Internal Failure value. - Page 21 Document type: Title: Revision date: Revision: User's Manual (MUT) A3484-A3485 AC/DC Converter 400 V 3-phase 48 V 2.5/5kW 04/07/2017 ItemID Data Type Access Description PowerSupplyName.BoardXX.ChanYYY.SVMax#LowEU 8-byte real SVMax lower limit PowerSupplyName.BoardXX.ChanYYY.VMon 4-byte real VMon PowerSupplyName.BoardXX.ChanYYY.Vmon#EU String VMon EU PowerSupplyName.BoardXX.ChanYYY.Vmon#HighU 8-byte real VMon upper limit PowerSupplyName.BoardXX.ChanYYY.Vmon#LowEU...
