Quick Guide
mBot Ranger is a three-in-one STEM educational robot kit which supports three building forms: a robot tank, a
three-wheeled racing car, and a self-balance car. Program and control mBot Ranger via smartphone, tablets, or com-
puter to start your exploration in the world of robotics.
3
2
Control With App
1
Assembly Manual

Basic Knowledge

02
WARNING:CHOKING HAZARD - Small parts. Children should be accompanied by adults.
.
6
5
Further
Exploration
4
Advanced Learning
Arduino Programming
Further Learning -
Graphical
Programming
w w w . e k t

Parts List

2 x Beam0824-112 2 x 90T Wheel
1 x Beam0824-48 2 x 90T Tyre
2 x Plate 0324-88 2 x Track
2 x Plate 135°
4 x Plastic Spacer 4x7x10mm
1 x Plate for Battery Holder 2 x 180 Encoder Motor
1 x Plate T-type
8 x Copper Bush 4x8x4mm
1 x Bracket 3x3 4 x Bruss Stud M4*30+6
1 x Bracket U1 1 x Battery Holder
1 x Mini Caster Wheel 1 x Me Auriga
4 x 62T Wheel Without Step 1 x Ultrasonic Sensor
2 x 62T Wheel 1 x Line Follower Sensor
. c o m
2
1 x USB Cable
2 x RJ25 Cable-20cm
1 x Wrench
1 x Hex & Cross Screwdriver
22 x Screw M4*8mm
4 x Screw M4*10mm
6 x Screw M4*14mm
4 x Screw M4*25mm
2 x Screw M2.5*12mm
10 x Nut M4
2 x Encoder Motor Wire
