- Page 1 Multi-function valve PENTABLOC Operating instructions Read the operating manual! The user is responsible for installation and operation related mistakes! Dosing Original operating instructions BA-12604-02-V02 Liquids Conveying Gases © Lutz-Jesco GmbH 2018 Control Systems...
-
Page 3: Table Of Contents
Multi-function valve PENTABLOC Operating instructions Table of Contents 1 Notes for the Reader ............4 1.1 General non-discrimination ............1.2 Explanation of the signal words ..........1.3 Explanation of the warning signs ..........1.4 Identification of warnings ............1.5 Instruction for action identification ........... -
Page 4: Notes For The Reader
Multi-function valve PENTABLOC Operating instructions 1 Notes for the Reader 1.3 Explanation of the warning signs This operating manual contains information and rules of conduct to en- sure the safe and intended operation of the product. Warning signs represent the type and source of a danger: Observe the following principles: Read the entire operating manual prior to commissioning the product. -
Page 5: General
Multi-function valve PENTABLOC Operating instructions 2 General 2.1 General warnings 2.3 Personal protective equipment The following warnings are intended to help you to eliminate the dangers Based on the degree of risk posed by the dosing medium and the type of that can arise while handling the product. -
Page 6: Intended Use
Multi-function valve PENTABLOC Operating instructions 3 Intended use 4 Product description The Multi-function valve PENTABLOC includes various functions and ful- 4.1 Scope of delivery fils the following tasks: The pressure retaining function to optimise dosing accuracy. Please compare the delivery note with the scope of delivery. The follow- The anti-siphon function avoids undesired siphoning. -
Page 7: Functions
Fig. 4: Function as a pressure-relief valve The back-pressure function is achieved when a medium entering at in- The Pentabloc serves as a safety valve, if the system pressure exceeds 5 put (A) presses against the diaphragm (M). The spring(F) of the left-hand or 11 bar. -
Page 8: Technical Data
Multi-function valve PENTABLOC Operating instructions 5 Technical data 6 Operation Description Value 6.1 Installation Housing material PVC / PP / PVDF / PMMA Precondition for action: Seal material FPM or CSM / EPDM ü All devices have been deactivated and pressure-free. -
Page 9: Declaration Of No Objection
Multi-function valve PENTABLOC Operating instructions 7 Declaration of no objection Please copy this declaration, stick it to the outside of the packaging and return it with the unit. Declaration of no objection Please fill out a separate form for each appliance! We forward the following device for repairs: Device and device type: .............. -
Page 10: Warranty Claim
Multi-function valve PENTABLOC Operating instructions 8 Warranty claim Warranty claim Please copy and send it back with the unit! If the device breaks down within the period of warranty, please return it in a cleaned condition with the complete warranty claim. -
Page 11: Notes To Eu Conformity
Multi-function valve PENTABLOC Operating instructions 9 Notes to EU conformity The device falls under the purview of the pressure equipment directive 2014/68/EU. The values stated below do not exceed the limit values in according to ar- ticle 4, paragraph 1. Therefore, it is designed and manufactured in ac-...
