CPU Installation
1.
Pull the lever sideways away from the socket then raise the lever up
to 90-degree angle.
2.
Locate Pin A in the socket and lock for the white dot or cut edge in
the CPU. Match Pin A with the white dot/cut edge then insert the
CPU.
3.
Press the lever down. Then Put the fan on the CPU and buckle it
and put the fan's power port into the JCFAN1, then to complete the
installation.
CPU/ System Fan Headers: JCFAN1/ JSFAN1
12V
Sense
Ground
JSFAN1
t
h
e
r
b
o
a
r
d
D
e
s
c
r
t
h
e
r
b
o
a
r
d
D
e
s
c
r
o
t
h
e
r
b
o
a
r
d
D
e
s
c
r
Ground
1
3
i
p
t
i
o
n
i
p
t
i
o
n
i
p
t
i
o
n
12V
Sense
1
JCFAN1
