UFH4ZW – Polypipe 230v Thermostat Wiring
UFM UNDER FLOOR MANIFOLD
LIVE
SWITCH LIVE
NEUTRAL
EARTH
END SWITCH AND
BOILER ENABLE
This equipment should be installed by an appropriately
quali ed/registered electrician.
Fully read the instructions for proper wiring before applying power.
The warranty does not cover damage from improper wiring
or installation.
8
THREE CORE AND
EARTH 1.5 CABLE
MAINS
SUPPLY
5A FUSE
HEAT ENABLE
LS E
LS AND LR IS
VOLT FREE
BOILER
ENABLE
Wiring Centre
MAINS L
E N
L
BOILER
POWER
MANIFOLD PUMP
OR VALVE
L
LR L E N
ZONE 1
ACTUATORS
230V
UFH PUMP
UFH UFH
UFHDIALW UFHDIALW
L N SL L N SL
E N SL L E N SL
ZONE 1 ZONE 2
ZONE 1 ZONE 2
L N N L L N N
L N L N
ZONE 2
ACTUATORS
230V
