CREE LIGHTING ZR-MT Series Installation Instructions

Commercial specification troffers with emergency driver & smartcast technology
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should
always be followed including the following:
READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
1.
DANGER- Risk of shock- Disconnect power before installation.
DANGER - RISQUE DE CHOC - COUPER L'ALIMENTATION
AVANT L'INSTALLATION
2.
CAUTION – Installation and servicing should be performed by
qualified personnel only. De-energize before opening.
ATTENTION – L'installation et l'entretien doivent être effectués
par du personnel qualifié seulement. Mettre hors tension avant
l'ouverture
3.
To reduce the risk of electric shock, disconnect both standard
and emergency power supplies and converter connector of the
emergency driver before servicing.
Pour réduire le risque de décharge électrique, vous devez
déconnecter à la fois le disjoncteur divisionnaire ou les fusibles et
les alimentations d'urgence avant l'entretien.
4.
Do not use outdoors.
Ne pas utiliser à l'extérieur.
5.
Do not let power supply cords touch hot surfaces.
Ne laissez pas les cordons d'alimentation toucher les surfaces
chaudes.
6.
Do not mount near gas or electric heaters.
Ne montez PAS près des appareils de chauffage de gaz ou
électriques.
7.
DO NOT use this equipment for other than its intended use.
NE PAS utiliser cet équipement à d'autres fins que celle qui est
prévue.
8.
Equipment should be mounted in locations and heights where it will not readily be subjected to tampering by unauthorized
personnel.
L'équipement doit être monté dans des endroits et à des hauteurs où il ne sera pas soumis à des altérations par des personnes
non autorisées.
9.
The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
L'utilisation d'accessoires non recommandés par le fabricant peut causer une situation dangereuse.
10. Suitable for suspended ceilings.
11. Max. mounting height: 15 ft.
Hauteur de montage max.: 15 pieds.
12. Access above ceiling required. Do not install insulation within 3" (76mm) of any part of the luminaire.
Accès requis au-dessus du plafond. Ne pas mettre l'isolant à moins de 3 po (76 mm) de toute partie du luminaire
13. Suitable for suspended ceilings.
Convient aux plafonds suspendus.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
• The ZR-MT Series of specification troffers is for non-insulated
ceiling applications using T-Bar ceiling grid, drywall grid adaptors,
and suspended mount.
• Designed for use in 120-277V 50-60 Hz protected circuit (fuse
box, circuit breaker). Supply wire sized as per NEC or governing
code(s), 90C rated.
1 of 5
SmartCast
Commercial Specification Troffers with Emergency Driver
Includes: ZR14MT-SC1, ZR22MT-SC1 and ZR24MT-SC1
ZR14MT-SC1
ZR22MT-SC1
ZR24MT-SC1
• Make sure to cap off all unused leads.
•
ZR-MT Series with
Technology
®
INSTALLATION INSTRUCTIONS
INSTRUCTIONS D'INSTALLATION
LPN00696X0001A0_A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZR-MT Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CREE LIGHTING ZR-MT Series

Summary of Contents for CREE LIGHTING ZR-MT Series

  • Page 1 13. Suitable for suspended ceilings. Convient aux plafonds suspendus. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE • The ZR-MT Series of specification troffers is for non-insulated • Make sure to cap off all unused leads. ceiling applications using T-Bar ceiling grid, drywall grid adaptors, •...

  • Page 2: T- Bar Ceiling Mounting

    TO INSTALL: 1st: 90° Bend T- BAR CEILING MOUNTING STEP 1: Bring the ZR-MT troffer up into the T-Bar grid. Luminaire Hooks STEP 2: Locate the luminaire hooks and bend them out 90 degrees for installation. See Figure 1. NOTE: The luminaire hooks ship bent in and need to be bent out for installation.

  • Page 3: Cleaning Lens

    RESET STEP 1: Actuate RESET button through the access hole. Press and hold Test/Reset button until the LED flashes fast Reset Button (approximately 5 seconds). See Figure 4. STEP 2: Motion Sensor Release the Test/Reset button for 1 second (Fast flashing continues).

  • Page 4: Troubleshooting

    (2) this device must accept any interference received, section). including interference that may cause undesired operation. • If Blue LED is on solid or off, call Cree Lighting Customer The LED in the front of this device operates within Risk Group 1 levels Service. per IEC 62471.

  • Page 5: Electrical Connections

    4 EMERGENCY OPERATION: 90 MINUTES. CAUTION - SEE INSTRUCTION MANUAL FOR INSTALLATION, OPERATING, AND MAINTENANCE © 2020 Cree Lighting, A company of IDEAL INDUSTRIES. All rights reserved. For informational purposes only. Content is subject to change. See www.creelighting.com/warranty for warranty and specifications. Cree and the Cree logo ®...

This manual is also suitable for:

Zr14mt-sc1Zr22mt-sc1Zr24mt-sc1
