Summary of Contents for Lennox ECOLEAN EAC Series

  • Page 1 Installation, operating and maintenance ECOLEAN - EAC/EAR Providing indoor climate comfort Revision 2 MIL85E-0907 09-2007...
  • Page 2: Table Of Contents

    All the technical and technological information contained in this manual, including any drawing and technical descriptions provided by us, remain the property of Lennox and must not be utilised (except in the operation of this product), reproduced, issued to or made available to third parties without the prior written agreement of Lennox.
  • Page 3: Preface

    Please consult Lennox on the options available in this field. Please do not hesitate to contact one of our employees should you require further information on specific chiller It is important that this manual be stored in a permanent subjects.
  • Page 4: Data Page For Unit Commissioning

    DATA PAGE FOR UNIT COMMISSIONING UNIT: SERIAL No.: CONTROL PANEL IDENTIFICATION CODE INSTALLATION ADDRESS: INSTALLER: INSTALLER TEL.: INSTALLER ADDRESS: DATE OF COMMISSIONING: CHECKS: SUPPLY VOLTAGE: RATED VOLTAGE OF THE UNIT: UNIT ON RUBBER ANTIVIBRATION MOUNTS GENERAL POWER SUPPLY CONNECTION CONTROL PANEL CONNECTION (OPTION) COMPRESSOR OIL LEVEL INDICATOR HYDRAULIC CONNECTION PURGED OF THE INSTALLATION...
  • Page 5: General Characteristics Page

    1.- GENERAL CHARACTERISTICS 1.1.- TECHNICAL DATA EA C 035 1 S M 2 HY FP1 Type of unit High static pressure models: EcoLean FP1: Version models 0251 to 1804. FP2: Version models 0251 to 1804. C: Cooling only units R: Heat pump units --- : Standard version HY: Hydraulic version Approximately capacity in kW...
  • Page 6 1.- GENERAL CHARACTERISTICS 1.1.- TECHNICAL DATA STANDARD FAN UNITS MODELS 0251SM 0291SM 0351SM 0431SM 0472SM 0552SM 0672SM 0812SM Fan type Axial - Direct coupling 900 rpm 1~230V Fan number Air flow rate 9750 11500 11300 11000 9750+9750 11500+11500 11300+11300 11000+11000 Power input 0,69 0,84...
  • Page 7: Electrical Data

    1.- GENERAL CHARACTERISTICS 1.2.- ELECTRICAL DATA STANDARD FAN UNITS MODELS 0251SM 0291SM 0351SM 0431SM 0472SM 0552SzM 0672SM 0812SM Maximum power (kW) 10,79 12,64 16,39 17,74 21,58 25,28 32,78 35,48 Maximum Current (A) 3N~400V 24,00 25,40 29,00 34,40 48,00 50,80 58,00 68,80 LRC (A) 3N~400V...
  • Page 8: Component

    1.- GENERAL CHARACTERISTICS 1.3.- COMPONENTS The EcoLean system comprises a water cooler or air/water pump combined with a series of hydraulic accessories obtaining the Hydraulic or Hydronic version. COMPONENTS: 1.- Detachable water filter 7.- Water pump 2.- Water tank 8.- Air purge valve HYDRONIC VERSION: 3.- Water tank heater 9.- Plate exchanger...
  • Page 9: Operation Limits

    1.- GENERAL CHARACTERISTICS 1.4.- OPERATION LIMITS STANDARD FAN UNITS WITHOUT AIR DUCTS 0251SM to 0431SM 0472SM to 0812SM 1003SM to 1804SM COOLING MODE MODELS EAC / EAR MINIMUM MAXIMUM MINIMUM MAXIMUM MINIMUM MAXIMUM Outlet chilled water temperature +5ºC +14ºC +5ºC +14ºC +5ºC +14ºC...
  • Page 10 1.- GENERAL CHARACTERISTICS 1.4.- OPERATION LIMITS FAN UNITS WITH AIR DUCTS COOLING MODE HEATING MODE Available Maximum Minimum Available Minimum static ambient ambient static ambient VERSION MODELS VERSION MODELS pressure temperature temperature pressure temperature ºC ºC ºC (2) 0251SM 0251SM 50Pa 50Pa STANDARD...
  • Page 11: Pressure Drop In The Water System

    1.- GENERAL CHARACTERISTICS 1.5.- PRESSURE DROP IN THE WATER SYSTEM INSTALLATION ADVISE The units MUST be fitted with a water filter at the inlet to the unit (trapping any particles with a diameter greater than 1 mm.) MODELS EAC / EAR 0251SM TO 0812SM PRESSURE DROP WITHOUT FILTER EAC/R 0812 EAC/R 0672...
  • Page 12 1.- GENERAL CHARACTERISTICS 1.5.- PRESSURE DROP IN THE WATER SYSTEM INSTALLATION ADVISE The units MUST be fitted with a water filter at the inlet to the unit (trapping any particles with a diameter greater than 1 mm.) MODELS EAC / EAR 1003SM TO 1804SM PRESSURE DROP WITHOUT FILTER EAC/R 1804 EAC/R 1604...
  • Page 13: Hydraulic System Data

    1.- GENERAL CHARACTERISTICS 1.5.- HYDRAULIC SYSTEM DATA WATER FLOW AND AVAILABLE STATIC PRESSURE ( Factory supplied; standard water pump and filter). EAC / EAR 0251SM EAC / EAR 0291SM EAC / EAR 0351SM MODELS 0,88 0,99 1,06 1,22 1,37 1,03 1,16 1,24 1,43...
  • Page 14: Safety Devices

    1.- GENERAL CHARACTERISTICS 1.7.- SAFETY DEVICES 0251SM TO 0812SM UNITS COOLING ONLY 6 F = 2F + 3F 7 F = 2F + 4F 8 F = 2F + 5F UNIT UNIT KIT LOW WATER Tª KIT LOW WATER Tª KIT LOW WATER Tª...
  • Page 15 1.- GENERAL CHARACTERISTICS 1.7.- SAFETY DEVICES 1003SM TO 1804SM UNITS COOLING ONLY COOLING LOW COOLING LOW UNIT KIT LOW WATER Tª KIT LOW WATER Tª KIT LOW WATER Tª AMBIENT KIT -15ºC AMBIENT KIT -15ºC COOLING STD/FP1/FP2 0ºC (STD/FP1/FP2) -5ºC (STD/FP1/FP2) -10ºC (STD/FP1/FP2) (STD) (FP1/FP2)
  • Page 16 1.- GENERAL CHARACTERISTICS 1.7.- SAFETY DEVICES 1003SM TO 1804SM UNITS HEAT PUMP 6 B = 2B + 5B 7 B = 3B + 5B 8 B = 4B + 5B HEATING LOW KIT LOW WATER Tª KIT LOW WATER Tª KIT LOW WATER Tª...
  • Page 17: Piping Drawings

    1.- GENERAL CHARACTERISTICS 1.8.- PIPING DRAWINGS COOLING ONLY UNITS EAC 0251SM TO 0431SM Pressure transducer Version (option) Scroll compressor Coil Water inlet Water Fan motor outlet Plate exchanger Hot gas injection valve (option) Expansion Liquid solenoid Filter drier valve valve(option) Pressure gauge Flow switch (option in standard version) Water inlet probe (water inlet regulation)
  • Page 18 1.- GENERAL CHARACTERISTICS 1.8.- PIPING DRAWINGS COOLING ONLY UNITS EAC 1003SM TO 1403SM Pressure transducer Coils Scroll compressor (option) HPR11 HPR12 Scroll compressor Fan motor Hot gas injection valve SVL1 (option) Filter drier Water inlet Expansion Liquid solenoid valve valve (option) Pressure transducer Water...
  • Page 19 1.- GENERAL CHARACTERISTICS 1.8.- PIPING DRAWINGS HEAT PUMP UNITS EAR 0251SM TO 0431SM 4 - way valve Water inlet Scroll Water Discharge Thermostat compressor Coil outlet (option) Fan motor Plate exchanger Solenoid valve-Heating Hot gas injection valve (option) cooling (option) mode Expansion valve...
  • Page 20 1.- GENERAL CHARACTERISTICS 1.8.- PIPING DRAWINGS HEAT PUMP UNITS EAR 1003SM TO 1403SM Coils Scroll compressor HPR12 Discharge Thermostat Scroll compressor (option) Hot gas injection valve SVR1 Fan motor (option) cooling mode Solenoid valve-Heating (option) Expansion valve Filter drier Water inlet Liquid receiver Check valve Restrictor...
  • Page 21: Dimensions

    1.- GENERAL CHARACTERISTICS COMPONENT POSITION STANDARD VERSION UNIT 1.9.- DIMENSIONS WATER EXCHANGER ELECTRICAL COIL EAC/EAR 0251SM-0291SM-0351SM-0431SM DISPLAY CONTROL MAIN SWITCH (OPTION) 1195 COMPRESSOR 1375 WATER INLET COMPONENT POSITION POWER SUPPLY WATER OUTLET HYDRAULIC VERSION UNIT CABLE ENTRY COIL WATER PUMP 1 1/2"G 1 1 9 WATER...
  • Page 22 1.- GENERAL CHARACTERISTICS 1.9.- DIMENSIONS COMPONENT POSITION STANDARD VERSION UNIT COILS WATER EXCHANGER EAC/EAR 1003SM-1103SM-1203SM-1303SM-1403SM DISPLAY CONTROL MAIN SWITCH (OPTION) 2250 ELECTRICAL BOX ELECTRICAL BOX COMPRESSORS 1875 WATER INLET WATER OUTLET 2 2 5 COMPONENT POSITION 1 4 2 HYDRAULIC VERSION UNIT POWER SUPPLY CABLE ENTRY 308 207...
  • Page 23 1.- GENERAL CHARACTERISTICS 1.9.- DIMENSIONS EAC/EAR 1604SM COMPONENT POSITION STANDARD VERSION UNIT DISPLAY CONTROL COILS WATER EXCHANGER MAIN SWITCH (OPTION) A VIEW 1975 ELECTRICAL POWER SUPPLY 2 2 5 2 3 0 CABLE ENTRY EAC/EAR 1804SM 2250 ELECTRICAL BOX DISPLAY COMPRESSORS CONTROL WATER INLET...
  • Page 24 1.- GENERAL CHARACTERISTICS 1.10.- AVAILABLE OPTIONS Standard version unit Hydraulic version unit Hydronic (1) version unit COIL TREATMENT Epoxy coated al fins coils treated ELECTRICAL Main ON/OFF switch (400V/III) Soft starter Three phase protection Evaporator antifreeze protection Tank antifreeze heater (400V/III) Not available Not available Water tank electrical heater (400V/III) (3)
  • Page 25: Options

    1.- GENERAL CHARACTERISTICS 1.10.- AVAILABLE OPTIONS TANK ANTI-FREEZE HEATER AND WATER TANK ELECTRICAL HEATER (available only for Hydronic version) An immersion heater can be supplied complete with safety thermostat and pressure switch fitted in the buffer tank, or an anti-freeze and supplementary heater (heat pump units only).
  • Page 26 1.- GENERAL CHARACTERISTICS 1.10.- AVAILABLE OPTIONS 1.10.6.- OTHER OPTIONS COIL PROTECTION GUARDS The condenser coil protection grill prevents light damage to the coil when shipping and when installed. It cannot protect against very heavy impacts. COMPRESSOR NOISE INSULATION JACKET Each compressor is fitted with a compressor acoustic jacket this provides attenuation of the compressor noise that radiates from the unit when in operation. ANTI-VIBRATION To install under the unit, to avoid transmission of vibrations, to the floor where unit is installed, while unit is operating.
  • Page 27: Site And Shipping Guidance

    When the unit is received, it should be checked to assure that there are no bumps or other damage, following the instructions on the packaging. If there is damage, the unit may be rejected by notifying the LENNOX Distribution Department and reporting why the machine is unacceptable on the transport agent’s delivery notice.
  • Page 28: Antivibration Mounting

    2.- INSTALLATION 2.3.- ANTIVIBRATION MOUNTING Unit Flexible connection Rubber mounting 1.- Mounting on a low sensibility zone Unit Flexible connection with loop Damping spring Metallic structure Support Rubber mounting 2.- Mounting on a medium sensibility zone Unit Flexible connection with loop Metallic and concrete structure Support Damping spring...
  • Page 29: Installation Clearances

    2.- INSTALLATION 2.4.- INSTALLATION CLEARANCES (*) Clearance around the unit, for all unit versions. Failure to install the units as shown will impact performance and reliability. INSTALLATION CLEARANCES DETAILING AVM POSITIONS EAC/EAR 0251SM-0291SM-0351SM-0431SM 1195 1145 3 meters (*) ∅14 1 meter (*) 1 meter (*) 1 meter (*) EAC/EAR...
  • Page 30: Detailing Spring Anti-Vibration Position

    2.- INSTALLATION 2.5.- DETAILING SPRING ANTI-VIBRATION POSITION (EAC/R 1003-1804 SM) EAC/R 1604 TO 1804 SM. EAC/R 1003 TO 1403 SM. POSTITION ANTI-VIBRATION POSTITION ANTI-VIBRATION TYPE TYPE Water connection Water connection 2.6.- WEIGHT APPROXIMATE DISTRIBUTION (Kg) (EAC/R 1003-1804 SM) EAC/R 1003 SM. EAC/R 1403 SM.
  • Page 31: Unit Installation

    2.- INSTALLATION 2.7.- UNIT INSTALLATION 1.- The EcoLeanTM units could be installed outside or inside. 2.- See the minimum clearance diagrams for access - air supply to the batteries in the heating section of the unit (see page 28). 3.- Assemble the unit on a resistant base, preferably concrete. To prevent vibrations, the concrete base should not come into contact with the building’s foundations.
  • Page 32 2.- INSTALLATION 2.7.- UNIT INSTALLATION 11.- For cooling or heat pump units the hydraulic system must contain the following components pump, buffer tank, expansion device, safety valve, water filter, flow switch. 12.- To obtain the total water system pressure drop add the unit pressure drop + water pipework + fittings and terminal unit pressure drops the water pump can be selected to provide the correct water flow across the heat exchanger.
  • Page 33: Electrical Connections

    2.- INSTALLATION 2.8.-ELECTRICAL CONNECTIONS - BEFORE MAKING ANY ELECTRICAL CONNECTIONS, BE SURE THAT ALL CIRCUIT BREAKERS ARE OPEN AND SUPPLY IS OFF. - IN ORDER TO CARRY OUT THE ELECTRICAL CONNECTIONS, FOLLOW THE ELECTRICAL DIAGRAM SUPPLIED WITH THE UNIT. NUMBER OF WIRES X SECTION POWER SUPPLY UNIT MODEL WITHOUT AEH...
  • Page 34: Commissioning And Operation Page

    3.- COMMISSIONING AND OPERATION 3.1.- STEPS TO FOLLOW FOR COMMISSIONING THE UNITS Before commissioning the unit check the following: 1.- Check that the voltage is the same as the rated voltage on the specification plate. 2.- Check that the supply to the control system is connected in accordance with the electrical diagram (if incorporates) 3.- Check that the main switch is ON (if incorporates).
  • Page 35: Checking The Water Flow Rate

    3.- COMMISSIONING AND OPERATION 3.2.- CHECKING THE WATER FLOW RATE It is very important that the unit operates at the correct water flow rate. It is dangerous to leave the unit operating at a low flow rate as this could result in serious damage to components as well as the water exchanger. If the unit operates at too high a flow rate, this will also hinder optimum performance.
  • Page 36: Corrosion Resistance Of Copper And Stainless Steel Of Plates Exchanger

    3.- COMMISSIONING AND OPERATION 3.3.- CORROSION RESISTANCE OF COPPER AND STAINLESS STEEL OF PLATES EXCHANGER (WATER EXCHANGER) GUIDE TO MEASURE A ANALYSIS OF THE WATER IN THE CIRCUIT. The resistance guide below is an attempt of give a picture of the corrosion resistance of the stainless steel of the type AISI 316 and pure copper in the water, to a number of important chemical factors.
  • Page 37: Preventive Maintenance

    4.1.- PREVENTIVE MAINTENANCE EPREVENTIVE MAINTENANCE PREVENTS COSTLY REPAIRS. We recommend regular and thorough servicing of the LENNOX unit. It is therefore advisable to ask your dealer about maintenance contracts. Check maintenance of the following points (depending on the operating conditions maintenance every 6 months may be necessary).
  • Page 38: Corrective Maintenance

    4.- MAINTENANCE 4.2.- CORRECTIVE MAINTENANCE - Take very special care if 4-way check valves are to be replaced since these have internal components that are very heat- sensitive such as plastic, teflon, etc. - If a compressor must be replaced, disconnect it electrically and un-braze the suction and discharge lines. Remove the securing screws and replace the old compressor with the new one.
  • Page 39 NOTES...
  • Page 40 BELGIUM, LUXEMBOURG PORTUGAL Due to Lennox’s ongoing commitment to quality, www.lennoxbelgium.com www.lennoxportugal.com the Specifications, Ratings and Dimensions are subject to change without notice and without incurring liability. CZECH REPUBLIC RUSSIA Improper installation, adjustment, alteration, www.lennox.cz www.lennoxrussia.com service or maintenance can cause property damage or personal injury.
