EO Mini Pro 2 Installation & User Guide
3.08
Connect the other end of the CT Clamp to the EO Mini Base.
© EO Charging 2020
Connector
Left or Right
CT1 (Left)
Left
CT1 (Left)
Right
CT2
Left
CT2
Right
CT3
Left
CT3
Right
CT Connection & Cable Colour
Load Management - White
Load Management - Black
DO NOT USE
DO NOT USE
Solar - White
Solar - Black
8
