Quick start guide to set Max and Min Alert Temperatures
Digital Thermocouple Grill Thermometer
Set Maximum Temperature –
1. Press MAX button to view the Maximum Alert Temperature
2. While viewing the MAX temperature, Press and hold MAX button for 2 seconds. MAX will flash
on the thermometer LCD
3. While MAX is blinking on the thermometer LCD, use the UP & DOWN arrow buttons to raise or
lower your MAX alert temperature (press and hold the arrow key buttons to raise/lower the
temperature quickly)
4.
Not pressing any buttons for 10 seconds will lock these temperature settings
Set Minimum Temperature –
1. Press MIN to view the Minimum Alert Temperature
2. While viewing the MIN temperature, press and hold the MIN button for 2 seconds . MIN Will
flash on the thermometer LCD
3. While MIN is blinking on the thermometer LCD, use the UP & DOWN arrow buttons to raise or
lower your MIN alert temperature (press and hold the arrow key buttons to raise/lower the
temperature quickly)
4. Not pressing any buttons for 10 seconds will lock these temperature settings
Model No. DGT-160
Advertisement
Related Manuals for Maverick DGT-160
Summary of Contents for Maverick DGT-160
- Page 1 Quick start guide to set Max and Min Alert Temperatures Model No. DGT-160 Digital Thermocouple Grill Thermometer Set Maximum Temperature – 1. Press MAX button to view the Maximum Alert Temperature 2. While viewing the MAX temperature, Press and hold MAX button for 2 seconds. MAX will flash on the thermometer LCD 3.
- Page 2 Digital Thermocouple Grill Thermometer Instructions Model # DGT-160 (Rev 3: July 19,2020) C/F & RESET buttons inside Battery Compartment Thermometer buttons POWER On/Off (BACKLIGHT) Up /MAX Down /MIN C / F (RE-CALIBRATION) RESET...
-
Page 3: Installing Batteries
INSTALLING BATTERIES Use a screwdriver to remove the screw of the battery door. Insert two AAA batteries noting the polarity. The (-) side goes on the spring. Install the battery cover and secure with screw. Do not over tighten. Note the water resistance features require maintaining the rubber gasket evenly within the groove around the battery compartment. - Page 4 Press once to turn on the thermometer and show Current Temperature Pressing the power button while the unit is on will activate the backlight for 5 seconds Press and hold 3 seconds to turn off the thermometer #2. UP /MAXIMUM TEMPERATURE ALERT Memory Set (Set at the factory at 400 F) ...
- Page 5 Within 5 seconds Press again to toggle Min Temp Alert & Current Temperature screen. In Min Temp Alert Screen, press and hold for 2 seconds to enter the set mode. The MIN icon will blink for 10 seconds, while MIN is blinking, use the same DOWN button to decrease temperature, use UP button to increase temperature setting.
- Page 6 Make sure the thermometer is back to current temperature screen to activate the Temperature Alerts. Thermometer is designed to measures grill temperature from ~842 ~450 °F °F °C °C When current Temperature measured is higher than 842 /450 , The display °F °C will show ‘HI’...
-
Page 7: Low Battery Indicator
temperature. #6. Power Saving Feature The Thermometer will automatically turn off if no buttons are pressed for 30 minutes and when the temperature measured is below 150°F /65.5°C Press Power button once to turn on LCD. #7. RESET Press RESET button inside the battery compartment of the unit when abnormal operation occurs such as the unit continues to beep despite turning off the alerts. - Page 8 SPECIFICATIONS Operating Range : 32°F to 842°F / 0°C to +450°C Display Range : 32°F to 842°F / 0°C to +450°C Power : 2 x AAA batteries (Included) CARE OF YOUR PRODUCT Don’t touch the probe tip with bare fingers after use, to avoid burning fingers. Although this thermometer is water resistance, do not submerge the unit into water.
- Page 9 Hours: Weekdays 8:30 AM - 4:30 PM Do not send any parts or product to Maverick without obtaining a Return Authorization Number and instructions. This warranty is VOID if instructions for use are not followed; for accidental damage; for commercial use;...
