Xtra.Mini Remote Control
Our Xtra.Mini Remote Control gives you the possibility to
further extend the safety on your track in a cost effective
way. This mini remote has 6 buttons which have a
dedicated function.
The Xtra.Mini Remote Control is supplied with a key cord
making it very easy to carry around the track.
Usage
The Xtra.Mini Remote Control can be used in fuel or EV mode. See configuration for more
information.
By default the Xtra.Mini Remote Control is configured for fuel karts.
The speed buttons have fixed RPM values for fuel karts:
Button Function in fuel mode
SPD1 All fuel karts 2100 RPM (speed 1)
SPD2 All fuel karts 3000 RPM (speed 2)
SPD3 All fuel karts 4000 RPM (speed 3)
SPD4 All fuel karts unlimited
STOP All karts STOP
For EV karts the Xtra.Mini Remote Control can set speeds 1 to 4. The actual speed depends
on the switch table configuration and the settings of the motor controller. These settings are
outside the scope of this manual and cannot be configured by the Xtra.Mini Remote Control.
The speed buttons have fixed speed value for EV karts:
Button Function in EV mode
SPD1 All EV karts Speed 1
SPD2 All EV karts Speed 2
SPD3 All EV karts Speed 3
SPD4 All EV karts Speed 4
STOP All karts STOP
After successfully sending the speed or stop command, the indication LED of the Xtra.Mini
Remote Control will flash briefly.
When the battery of the Xtra.Mini Remote Control is low, the indication LED will flash 4
times after trying to send the speed or stop command. Correct transmission of the command
is not guaranteed when the battery is low.
User Manual Xtra.Mini Remote Control V2.1
- 1 -
