Specifications - Adcom GTP-830 Owner's Manual

Input Impedance
Audio
Video
Output Impedance
Audio
Video
Frequency Response
20Hz to 20kHz
THD+N@ Rated Output
20Hz to 20kHz
IM Distortion
CCIF @ 15kHz and 16kHz
Signal to Noise Ratio (@ 1kHz "A" weighted)
Ref. to 1V input, max output voltage
Sensitivity 1 volt output
Subwoofer Crossover Frequency
Crosstalk (@ 1kHz)
Maximum Output Voltage
Bass effective below
Bass Max Gain/Cut
Treble effective above
Treble Max Gain/Cut
Usable Mono Sensitivity
50 dB Mono Quieting Sensitivity
50 dB Stereo Quieting Sensitivity
A-wtd. Signal to Noise Ratio
Mono
Stereo
Stereo Separation (1 kHz)
Alternate Channel Selectivity
Capture Ratio
Power (available in 230V on special order)
Chassis Dimensions
Maximum Dimension
Weight
Weight, Packed

SPECIFICATIONS

Preamplifier Section
Tone Controls (L and R front only)
FM Tuner
General
5 3/16"(132mm) x 17"(432mm) x 13 3/4"(349mm)
5 6/16"(137mm) x 17"(432mm) x 15"(381mm)
50k Ohms
75 Ohms
320 Ohms
75 Ohms
± 0.5dB
≤ 0.01%
≤ 0.009%
> 95dB
220mV
100Hz
>80dB
4.6V
200Hz
± 10dB @ 20Hz
6.3kHz
± 10dB @ 20kHz
15dBµ
22dBµ
39dBµ
75dB
70dB
43dB
>50dB
2dB
120VAC/50-60Hz
16.5lbs. (7.5kg)
19.5lbs. (8.8kg)
ADCOM OWNER'S MANUAL | 39
