GET STARTED
AC 1200 High Power Dual Band Wi-Fi Range Extender

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RX12 and is the answer not in the manual?

Questions and answers

Related Manuals for Prescitech RX12

Summary of Contents for Prescitech RX12

  • Page 1 GET STARTED AC 1200 High Power Dual Band Wi-Fi Range Extender...

  • Page 2: Table Of Contents

    Acts as an access point for WIFI devices.... Download the APP before setup......Power on & login the APP........Method 1: Connect by APP....... Method 2: Connect with WPS......Connect an Ethernet-enabled Device....Using as an Access Point Other Settings Self- Configuration of Prescitech RX12....

  • Page 3: Overview

    Overview The Prescitech RX12 Dual Band WIFI Range Extender is the second-generation network signal booster for in- creasing the distance of a WIFI network signal. The latest technology, Seamless Roaming could merge all WIFI signal into one in the whole house no matter how many RX12 installed.

  • Page 4: Front Panel

    Front Panel Before you install your extender, familiarize yourself with its LEDs, buttons, and port. LED Light WPS Button Reset Button Wan/Lan Port Lan Port...

  • Page 5: Led Descriptions

    LED Descriptions A WPS connection is ready Green Blinking Slowly established. Green Blinking Fast Self-Configuration is starting. Circle Blinking Ready to connect/ Fail to connect / Incorrect password. (Red/Blue/Green) Best Connection. Lit Blue Under processing Lit Red / Poor Connection.

  • Page 6: Using As An Extender

    Using as an Extender The extender works like a bridge between a WIFI router (or an access point) and a WIFI device out of the range from WIFI router. The extender performs two main jobs: Connects to a WIFI network When the extender connects over WIFI to an existing network, it functions as a network client, similar to one WIFI device connects to a network.

  • Page 7: Download The App Before Setup

    Download the APP before setup Visit the official website www.prescitech.com/download/app for download the APP named “TenbayWiFi”. Plug the extender into an electrical outlet which next to your WIFI router. And wait the LED lights turn to the Circle Blinking. Tenbay WiFi...

  • Page 8: Power On & Login The App

    1. Find and connect to the extender WIFI network “RX12”. 2. Once connected, open the “TenbayWiFi” APP. 3. Click the “search” for finding out the RX12 repeat er, click the repeater you want to setup. Note: If your smartphone does not connect the RX12, the list could not show up any devices, click “Connect WiFi”...
  • Page 9 4. Fillin the “admin” to login the setting page. 5. Custom the RX12 password & its name or leave it as default. Click “Next”.
  • Page 10 6. Choose “Repeater Mode”, click “Next”.
  • Page 11 7. After scanning finish, choose your target WIFI network, fill in the WIFI passwork. Click ”Next”.

  • Page 12: Method 2: Connect With Wps

    8. Check the all setting of your repeater, Click “Save”. 9. The Prescitech RX12 needs around half one minute to reboot & the LED turns to Lit. Blue. You can connect back the extender by using the new SSIDs. Note: If the extender fails to connect the router, the Status LED still show Circle Blinking, that may you give the wrong password.

  • Page 13: Connect An Ethernet-Enabled Device

    Lit Blue. If the RX12 fails to connect, the Status LED would turn to Circle Blinking. Try to setup once again. 3. After setup successful, you can connect back the RX12 with new SSID. You can login the “TendayWiFi”...

  • Page 14: Using As An Access Point

    Using as an Access Point The Prescitech RX12 WIFI Range Extender also can be used as an Access Point. An access point receives in- ter-net data by wired Ethernet (such as hotel’s wired Ether-net), and converts into a 2.4GHz and 5GHz wire- less sig-nals.
  • Page 15 1. Find and connect to the extender WIFI network “RX12” 2. Once connected, open the “TenbayWiFi” APP. 3. Click the “search” for finding out the RX12 repeater, click the repeater you want to setup. Note: If your smartphone does not connect the RX12, the list could not show up any devices, click “Connect WiFi”...
  • Page 16 4. Fillin the “admin” to login the setting page. 5. Custom the RX12 password & its name or leave it as default. Click “Next”.
  • Page 17 7. Give names for your 2.4G & 5G signal & the password of RX12. Click “Next”. 8. Check the details of RX12 details & Click “Save”. Till the LED light turn to Lit. blue. 9. Connect the WAN/LAN port of RX12 to your wired Ethernet port with Ethernet cable.

  • Page 18: Other Settings

    Self-Configuration for the second one as below steps: Press the WPS button around 6 seconds till LED turns to Blinking Green Fast, then press the second one RX12 around 6 seconds till LED turns to Blinking Green Fast. And the Self-Configuration is processing. The both LEDs will turn to Lit Blue once finish configuration.
  • Page 19 Model: RX12 AC 1200 High Power Dual Band Wi-Fi Range Extender US COST FREE Tech Support: 800-213-1134 (PST Mon-Sun 06:00-24:00) UK COST FREE Tech Support: 800-970-3063 (GMT Mon-Sun 14:00-08:00) Website: www.prescitech.com E-Mail:support@prescitech.com V1.0...
