Prescitech X12 Get Started

Ac 1200 high power dual band wi-fi range extender
Hide thumbs Also See for X12:
Table of Contents

Advertisement

Quick Links

GET STARTED
AC 1200 High Power Dual Band Wi-Fi Range Extender

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X12 and is the answer not in the manual?

Questions and answers

Related Manuals for Prescitech X12

Summary of Contents for Prescitech X12

  • Page 1 GET STARTED AC 1200 High Power Dual Band Wi-Fi Range Extender...

  • Page 2: Table Of Contents

    Quick Installation Guide Preparing ..............Web-Browser Method ..........WPS - Method ............User Manual Overview ..............Using as a Extender..........When to Use Your Extender........How the Extender Works........Power on the Extender.......... Connect to an Existing WiFi Network ....Method 1: Connect with a web browser ...
  • Page 3 1) Place your extender in the same room as your WiFi router. 2) Use your Smart-Phone to connect with the extender (find "Prescitech X12_2.4G or Prescitech X12_5G" and connect with it, if password request try PIN number of the rear panel.) 3) Visit http://extenderlogin.com/ or the IP address...

  • Page 4: Wps - Method

    8) If the internet works, unplug Prescitech X12 and plug it halfway between your Router and the Device intended for the internet usage/dead zones in your home where you were getting low to no WIFI signals.

  • Page 5: Overview

    User Manual Overview The Prescitech X12 WiFi Range Extender is a network device with multifunction, which can be using for in- creasing the distance of a WiFi network by boosting the existing WiFi signal and enhancing the overall signal quality over long distances. An extender repeats the sig- nals from an existing WiFi router or access point.

  • Page 6: Rear Panel

    Wan/Wlan Reset LED Descriptions Power LED Lit amber. The Prescitech X12 is starting. Off. Power is not supplied to the router. WPS LED Blinking. Press and hold the WPS 3 seconds on the Rear Panel lets you use WPS to join the WiFi network without typing the WiFi password.

  • Page 7: Using As A Extender

    Using as a Extender When to Use Your Extender We recommend that you connect through the extender network only when the WiFi device is in a “dead zone” where connection from the existing network is poor or nonexistent. Data traffic routed through the extender is inherently slower than traffic routed directly from the net- work.

  • Page 8: Power On The Extender

    Existing WiFi WiFi Range Extender sometimes your router Boosts the range of your does not provide the existing WiFi and creates WiFi coverage you need. a stronger signal in hard to reach areas. 1 Power on the Extender Turn the Power On/Off button to “On” and Mode Switch Button to “Extender”...

  • Page 9: Connect To An Existing Wifi Network

    Method 2: Connect with WPS. For more page 11. Method 1: Connect with a web browser 1) Use a WiFi network manager on a computer or mobile device (recommended) to find and connect to the ex- tender WiFi network “Prescitech X12_2.4G or Presci- tech X12_5G”...
  • Page 10 6) Find and connect to the new extended WiFi network on your computer or WiFi device. The extender creates a new extended WiFi network. The extender’s new WiFi network name is “Prescitech X12_2.4G_EXT or Prescitech X12_5G_EXT”, use the same WiFi pass- word that you use for your WiFi router.
  • Page 11 “Prescitech X12_2.4G_EXT or Prescitech X12_5G_EXT”, you might type the incorrect password during on step 5. 7) Unplug the extender and move it to a new location that is about halfway between your router and the area with a poor router WiFi signal.

  • Page 12: Method 2: Connect With Wps

    When the extender connects to your existing WiFi network successful, the extender's new WiFi network name will change to “Prescitech X12_2.4G_EXT or Prescitech X12_5G_EXT", and the Status LED will light blue or amber (check the WLAN LED Descriptions on Page ?), confirm it on your comput- er or WiFi device.
  • Page 13 6) Find and connect to the new extended WiFi network on your computer or WiFi device. The extender creates a new extended WiFi network. The extender’s new WiFi network name is “Prescitech X12_2.4G_EXT or Prescitech X12_5G_EXT”, use the same WiFi password that you use for your WiFi router.

  • Page 14: Connect An Ethernet-Enabled Device

    Connect an Ethernet-Enabled Device After the extender is connected to your existing WiFi net- work, you can connect a wired device to the extender using an Ethernet cable. That device can then access your existing network through the WiFi connection. WLAN WAN LAN1 LAN2 LAN3 LAN4 WPS...

  • Page 15: Using As A Access Point

    Using as a Access Point The Prescitech X12 WiFi Range Extender also can be used as an Access Point, An access point receives data by wired Ethernet (such as hotel’s wired Ethernet), and converts to a 2.4Gig Hz and 5Gig Hz wireless signal. It sends and receives wireless traffic to and from nearby wireless clients.

  • Page 16: Cable Your Ap

    2) Connect the AP to your wired Ethernet port with the Ethernet cable came with your AP. 3) Use a WiFi network manager on a computer or mobile device (recommended) to find and connect to the AP WiFi network “Prescitech X12_2.4G or Prescitech X12_5G”.
  • Page 17 MAC:80:3F:5D:8A:7E:AA PIN:XXXXXXXX 4) Launch a web browser, enter http://extenderlogin.com or http://192.168.19.252/ in the address field of the web browser, when prompted, Launch a web browser. 5) Setup the AP’s SSID and Password, click APPLY button. the AP will take 1 minute to reboot.
  • Page 18 2.4GHz Network Extender SSID Prescitech X12_2.4G_XXXX Password 5GHz Network Extender SSID Prescitech X12_5G_XXXX Password Consistent with 2.4G password APPLY 6) Find and connect to the new converted WiFi network on your computer or WiFi device that you set.

  • Page 19: Setting

    Setting 1. To change the admin password 1) Launch a web browser. 2) Enter http://extenderlogin.com or http://192.168.19.252/ in the address field of the browser login screen displays. 3) Enter the admin password you set. The BASIC Home screen displays. 4) Select “Setting ->System Tools -> Admin Account” 5) Type your current password and new password twice.

  • Page 20: Hide Extender's Wireless Network

    3. Update the Extender Firmware The extender firmware (routing software) is stored in flash memory. You might check if new firmware is avail- able at www.coredytech.com and to update your prod- uct. 1) Launch a web browser. 2) Enter http://extenderlogin.com or http://192.168.19.252/ in the address field of the browser login screen displays.
  • Page 21 1) Launch a web browser. 2) Enter http://extenderlogin.com or http://192.168.19.252/ in the address field of the browser login screen displays. 3) Enter the admin password you set. The BASIC Home screen displays. “Setting ->Wireless Setting” 4) Select the Disable check box to hide the wireless net- work.

  • Page 22: Troubleshooting

    Troubleshooting How to reset Prescitech X12 to factory settings? 1) Using a reset pin come with package to press and hold the Factory Reset button on the extender at least three seconds untill Power Leds lights blue. 2) Release the Factory Reset button and wait for the ex- tender to reboot.
  • Page 23 Host Wi-Fi The location that you choose must be within the range of your existing WiFi router network. 2) Using a smart phone to help you choose a spot where the extender-to-router connection is optimal. 3) If there is not full WiFi signal on your smart phone , plug the extender into an outlet closer to the router and try again.

  • Page 24: Troubleshoot Internet Browsing

    DNS, con- tact technical support at www.prescitech.com or Google “how to manually set DNS windows 7” . Cannot Join a WiFi Network and Receive an Error...
  • Page 25 The passphrase or key is case-sensitive. For example, PASSWORD25 is not the same as Password25 or pass- word25. If the extender cannot detect your WiFi network, check to see if your WiFi network is still working. Make sure that the WiFi router is turned on. If possible, move the extender closer to the WiFi router.
  • Page 26 Model: X12 AC 1200 High Power Dual Band Wi-Fi Range Extender US COST FREE Tech Support: 800-999-8470 Mon-Fri 10:00-19:00 (CST) Website: www.prescitech.com V1.1...
