Safety Instruction - CAUTION Any operation that is inconsistent with the contents of the instructions may cause serious personal injury or damage to the product itself. Do not stare at the UV lamp directly at any time to avoid injury. If you have a sensitive skin complaint then do not use without consulting your doctor.
Index I. Product Safety Issues page 2 II. Product Name & Diagram page 4 III. Parts Name & Diagram page 5 IV. Product Technical Data page 5 V. Replacement parts and Service page 5 VI. Operating Instructions page 6 VII. Cleaning and Maintenance page 8 VIII.
4 Unique features: The UV-C sterilizing lamp will kill 99.9% of bacteria and help eradicate the Dust Mites and germs that may cause asthma, ill health and in some cases, lead to more serious illnesses such as pneumonia. The vibrating pad will release the millions of Dust Mites which have hooked themselves into the mattress/pillows to enable deep down cleaning.
1. 6 Pack sleep enhancer cartridges, item number EB0999 2. UVEE replacement UV-C bulb/lamp, item number EB1000 3. UVEE cartridge filter, item number EB1001 For queries relating to service and repair issues please contact Ewbank service department at the address listed at the back of this manual.
Operating Instruction 1. Insert the hand held cleaner into the UV unit head (as the direction shown in the figure) and, when it is in place, press the button on the back of the vacuum cleaner to make sure this is securely in place 2.
Page 7
6. Sleep enhancer/ disc assembly / use To enhance your sleeping experience Ewbank lavender sleep enhancer cards are available for your UVEE. Lavender is accepted as helping the body to relax and we have specially designed cartridges to deliver the aroma of lavender whilst cleaning. Simply remove the lavender sleep enhancer card from the plastic sleeve and insert as directed into the plastic basket filter before refitting the assembled dust chamber.
Cleaning your mattress with the UVEE The age of your mattress determines how often you need to use your UVEE. The cleaning routine below is recommended to produce the best results. New mattress – use the UVEE once a month ...
Page 9
Hold the filter following the illustration below, rotate the HEPA assembly in the unlocking direction, and then take the HEPA assembly outwards to clean the dust. The HEPA filter is suitable for hand washing in water, but must be completely dry before re-use. Install the filter assembly by aligning the symbols and rotate the filter to lock in place.
Page 10
Lamp holder Contact pin After the lamp is wiped clean or a new lamp is being inserted, then place the lamp into the lamp holder, adjust the length of the cable into the mounting groove carefully replace the UV lamp and secure the lamp cover with a screw. 6.
Trouble Shooting If the unit develops a problem during use, switch off for your safety and consult the list of common faults below. If the problem detected is not shown please call your sales and service department for advice. Problem symptom Possible cause Solution Stop working...
UV bulb/tube. While every possible care is taken by Ewbank LLC. to ensure that our products leave the factory in good working order, Ewbank LLC. cannot under any circumstances accept liability for problems or damage caused by their subsequent use.
