Summary of Contents for TES TDS-43
- Page 1 User Manual Version 01 2018/06 TDS-43 Touch Monitor TDS-43 standard version...
- Page 2 TES reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of TES to notify any person of such revisions or changes.
- Page 3 Compliance Information For FCC (USA) This equipment has been tested and fund to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. There limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 Usage Notice Warning - To prevent the risk of fire or shock hazards, and do not expose the product to moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Precautions follow all warnings, precautions and maintenance as recommended in this user’s Please manual to maximize the life of your unit.
-
Page 5: Table Of Contents
Table of Contents Chapter 1 ........................5 1.1 Overview ........................6 1.2 Feature ........................6 1.3 Specifications ......................6 1.4 Block Diagram......................7 1.5 Interface Connectors ....................8 1.5.1 Power Connector ....................8 1.5.2 Video Signal Connector ..................8 1.5.3 Signal Connector ....................10 1.6 Package Overview .................... -
Page 6: Chapter 1
Chapter 1 Product Introduction... -
Page 7: Overview
1.1 Overview TDS-43 series not only supports portrait and landscape two ways suitable for all solutions, but also provides dynamic touch sensitivity technology supports up to 6mm thickness glass. TDS-43 series is designed for retail, KIOSK, digital signage etc. 1.2 Feature ... -
Page 8: Block Diagram
1.4 Block Diagram This section describes the electrical requirements of the monitor. The block diagram in figure 1 illustrates the various electrical sub-systems. -
Page 9: Interface Connectors
1.5 Interface Connectors 1.5.1 Power Connector The AC converter shall have an IEC320 type male power receptacle for connection to AC mains power. The power cord, exact type to be supplied in the appropriate Option Kit, shall be length of 1.80.05 meters, and PC99 compliant. 1.5.2 Video Signal Connector The video signal input via D-type 15-pin female connector. - Page 10 HDMI(1.4) The video signal input via HDMI female connector. Connector Pin Assignment: Signal Signal TMDS Data2+ TMDS Clock Shield TMDS Data2 Shield TMDS Clock– TMDS Data2– TMDS Data1+ Reserved (N.C. on device) TMDS Data1 Shield TMDS Data1– TMDS Data0+ DDC/CEC Ground TMDS Data0 Shield +5V Power TMDS Data0–...
-
Page 11: Signal Connector
Display Port(1.2a) Signal Signal ML_Lane 3(n) Data3 - Signal ground Signal ground ML_Lane 0(p) Data0 + ML_Lane 3(p) Data3 + Signal ground ML_Lane 2(n) Data2 - Signal ground AUX_CH(p) AUX + Signal for Signal ground Auxiliary Channel ML_Lane 2(p) Data2 + Signal ground AUX_CH(n) AUX - Signal for ML_Lane 1(n) Data1 -... - Page 12 RJ11 Connector (Remote Key) Signal MENU DOWN SELECT POWER Line-in Connector Signal LEFT RIGHT LEFT RIGHT...
-
Page 13: Package Overview
= 3048m minimum. If it needs further assistance with 100V~240V, 2.0A 50/60Hz minimum, Tma = 40 degree C minimum, and the purchasing the power source, please contact to TES for further information. altitude of operation = 3048m minimum. If it needs further assistance with... -
Page 14: Chapter 2
Chapter 2 Product Installation... -
Page 15: About Vesa Mount
2.1 About VESA Mount “VESA Flat Display Mounting Interface The TDS-43 series conform to the Standard” which defines a physical mounting interface for touch monitor and corresponding with the standards of touch monitor mounting devices. The VESA mount is located on the back of this unit. -
Page 16: Install The Vesa Screw
2.1.1 Install the VESA screw Note: Please install/ dismantle the product when the device is in the shutdown state. Step 1: Fasten two M6 screws into the VESA hole Step 2: Fasten four M6 screws into the VESA hole... -
Page 17: About General Mounting Information
2.2 About General Mounting Information The following two mounting orientations are supported: Landscape and portrait mode. For optimal touch performance, ensure that the monitor is supported fully and is as flat as possible. 2.2.1 Landscape 2.2.2 Portrait... -
Page 18: On-Screen Display
2.3 On-Screen Display The TDS-43 series provide side panel controls. And the following is OSD function table: Menu off status Menu on status Menu disappear/ return to main MENU Menu appear item ▲ Brightness Main item select up/ Adjust up Main item select down/ Adjust ▼... - Page 19 To Lock the OSD / Power menu buttons, please follow the instructions below. (Please note: the monitor has to be turned ON with a valid signal pre-set) a. Without the OSD menu on screen, press and hold “Menu” key ,and press “POWER”...
-
Page 20: Osd Function Description
2.3.1 OSD Function Description ITEM CONTENT Default Contrast The monitor luminance level control. Brightness The monitor backlight level control. Auto Adjust Fine-tune the image to full screen automatically. Left/Right Moving screen image horizontal position to left or right. Up/Down Moving screen image vertical position to up or down. Horizontal The screen image horizontal dot clock adjustment. -
Page 21: Timing Table Chart
2.3.2 Timing Table Chart Polarity Bandwidth MODE Resolution H-Freq. (KHz) (MHz) 31.47 25.175 VGA 640x480@ 60Hz 35.16 VESA 800x600@ 56Hz 37.88 VESA 800x600@ 60Hz 48.36 VESA 1024x768@ 60Hz 44.772 74.5 VESA 1280x720@ 60Hz 47.776 79.5 VESA 1280x768@ 60Hz VESA 1280x1024@ 60Hz VESA 1280x960@ 60Hz 106.5 VESA 1440x900@ 60Hz... -
Page 22: Dimension
2.4 Dimension 2.4.1 Front View 2.4.2 Side View... -
Page 23: Rear View
2.4.3 Rear View... -
Page 24: Appendix
Appendix... - Page 25 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱：觸控螢幕 型號（型式）：TDS-43 Type designation (Type) ：TDS-43 Equipment name：Touch Monitor 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 Unit 六價鉻 多溴聯苯 多溴二苯醚 鉛 汞 鎘 Cadmium Hexavalent Polybrominated Polybrominated Lead Mercury...
